Zone Bypass Event Displays

This displays the bypassing of system zones.
16-Character Display Description
26 BYPS 1 2 1017 Zone 26 bypassed by user 12. Press the
left Select key for the zone name and
the right Select key for the time.
32-Character Display Description
BYP 5:18P 10 / 17 The east window zone was bypassed.
EAST W INDOW Press a Select key for the zone number
and user number.
Bypass Event Types - There are 3 event types:
BYP - Bypass RST - Restore
Note: You may sometimes see the user as SWG or SCH. These are
short for Swinger Bypass and Schedule which are automatic functions
that allow the system to bypass a zone.
XR20
User Menu
FRC - Force Arm

Zone Event Displays

This section displays alarms, troubles, and other events that could
occur on your protection zones.
16-Character Display Description
2 BURG ALR 1017 A burglary alarm occurred on zone 2.
Press the right Select key for the time
the alarm occurred.
32-Character Display Description
A LR 10: 23P 10/17 An alarm occurred at 10:23 PM on Oct.
BAS EM ENT DOOR Press any Select key to see the zone
number and zone type.
Zone Type - There are 7 possible zone types you may see here.
FIRE - Fire PANC - Panic
EMRG - Emergency SUPV - Supervisory
AUX1 - Auxiliary 1 AUX2 - Auxiliary 2
Event Types - There are 7 event type you may see here:
ALR - Alarm TBL - Trouble
LOW - Low battery MIS - Missing xmitter
FLT - Zone Fault SVC - Service Smoke Detector
Note: LOW and MIS are for wireless systems only.
BURG - Burglary
RST - Restore
