PhoneAccess™ User's Guide
This exciting feature allows you to call your XR20 system from any outside touch-tone phone to arm and disarm protection areas or turn
on or off the panel's relay outputs.
How it works
1. From a touchtone phone, call the XR20 system's phone number.
2. The XR20 answers and sounds a short ready tone. You now have
8 seconds to enter a valid Master user code. If the user code is
accepted by the panel, you will hear one or more beeps giving you
the current armed status of the system. (You can also find out the
armed status of the system by pressing the * key at any time.)
If
All areas are armed
Area 1 (Perimeter) is armed
Any area is armed
All areas are disarmed
If the user code is not accepted by the panel, you will hear four short
beeps. Check the user code and try again. After 3 unsuccessful
attempts to enter the code, the panel locks out PhoneAccess™ until
a valid user code is entered at a keypad.
3. Once the user code is accepted by the panel and the armed status
is given, you can enter the following commands:
Press
To do this
#, 1
Arm all areas
#, 2
Arm area 1
#, 3
Arm areas 1 & 2
#, 0
Disarm all areas*
#, 5, 4, 0, n*
Toggles the output
(* Use outputs 1, 2, 3, or 4 in place of n)
Note: Faulted zones are force armed when the area arms.
XR20
Appendix
You will hear
3 short beeps
1 short beep
2 short beeps
1 long beep
You will hear
3 short beeps
1 short beep
2 short beeps
1 long beep
1 short beep = on
1 long beep = off
4 short beeps = restricted
Quick Reference Wallet Card
PhoneAccess™ Quick Commands
Press
To do this
# then 1
Arm all areas
# then 2
Arm area 1
# then 3
Arm areas 1 & 2
Note: Zones in a bad condition are force armed when the area arms.
# then 0
Disarm all areas
#, 5, 4, 0, n*
Toggles the output
(* Use outputs 1, 2, 3, or 4 in place of n)
(Enter output descriptions below)
1. _________________________ 3. _________________________
2. _________________________ 4. _________________________
PhoneAccess™ Quick Commands
Press
To do this
# then 1
Arm all areas
# then 2
Arm area 1
# then 3
Arm areas 1 & 2
Note: Zones in a bad condition are force armed when the area arms.
# then 0
Disarm all areas
#, 5, 4, 0, n*
Toggles the output
(* Use outputs 1, 2, 3, or 4 in place of n)
(Enter output descriptions below)
1. _________________________ 3. _________________________
2. _________________________ 4. _________________________
Cut along dotted lines
You will hear
3 short beeps
1 short beep
2 short beeps
1 long beep
1 short beep = on
1 long beep = off
4 short beeps = restricted
You will hear
3 short beeps
1 short beep
2 short beeps
1 long beep
1 short beep = on
1 long beep = off
4 short beeps = restricted
35
