DMP Electronics XR350 Quick Reference

XR100/XR500 or XR150/XR350/XR550 Arming and Disarming
Disarming the Alarm System
1. Press CMD until ARM
2. Select DISARM, enter your user code and press CMD.
3. At ALL? NO YES, if you select NO, the keypad
displays the name of each area followed by NO
YES. Select YES or NO to disarm area(s) of your
choice.
Arming the Alarm System
1. Press CMD until ARM
2. Select ARM, enter your user code if a closing code is
required and press CMD.
3. At ALL? NO YES, if you select NO, the keypad
displays the name of each area followed by NO
YES. Select YES or NO to arm the area(s) of your
choice.
4. SYSTEM ON or ALL SYSTEM ON displays.
Note: SYSTEM ON means at least one area in the
system is armed.
ALL SYSTEM ON means all areas in the system
are armed. The keypad begins counting down
the exit time.
DISARM displays.
DISARM displays.
quick reference
32-Character Display
Power LED
Armed LED
Data Entry Digit keys
Keypad Layout and Function Keys
1
Away
All
5
Monitor
9
(Chime)
Keypad Shortcut Keys
X R 5 0 0
F R I 8 :51 AM
Select Keys
1 2 3 4
5 6 7 8
COMMAND Key
9 0 CMD
Back Arrow Key
Sensor Reset
(Fire Reset)
2 3 4
Home
6 7 8
0 CMD
Sleep
Perimeter
