- Page 1 T R A D I T I O N A L S E C U R I T Y S Y S T E M XR20 User’s Guide...
-
Page 2: Silencing An Alarm
Silencing an Alarm All/Perimeter and Home/Away Systems While the alarm bell or siren is sounding, enter your user code. The keypad displays DISARM SILENCE. Press the Select key under SILENCE to stop the bell or siren. This does NOT disarm the system. Area Systems While the alarm bell or siren is sounding, enter your user code. -
Page 3: Table Of Contents
Security Command User's Guide ® XR20 Command Processor Panels Table of Contents Section Page Section Page About Your Security System ........1 Extended Schedules ..........21 The Security Command Keypad ........2 Date and Time ............21 Special Security Command Messages ......3 Display Events ............ -
Page 4: Emergency Evacuation Plans
Emergency Evacuation Plans The National Fire Protection Association recommends that you First Floor Second Floor establish an emergency evacuation plan to safeguard lives in the event of a fire or other emergency. Use the following steps as a guide. Fire Escape Draw a floorplan of your home or business On a clean sheet of paper, draw the walls, windows, doors, and Window Ladder... -
Page 5: About Your Security System
Keypad User Menu The keypad also supplies a User Menu containing all of the functions you need to fully operate your system, such as the ability to change a personal user code number. XR20 Introduction... -
Page 6: The Security Command Keypad
Use the right Select key to raise the keypad volume. Press operate. They allow you to choose what to do by pressing the Select the Back Arrow key to exit out of the User Options. key under choices being shown in the display. XR20 Introduction... -
Page 7: Special Security Command Messages
The user code you have entered is considered invalid by the system. the problem. SYSTEM TROUBLE or SERVICE REQUIRED There is an electronic failure in your system. Contact the service department as soon as possible. XR20 Introduction... -
Page 8: Understanding Security System Terms
Perimeter, these zones sound an alarm if tripped. Often, similar devices in the same general area will share the same zone. For example, the windows on the east side of the premises can all be grouped together in a zone named E. WINDOWS. XR20 Introduction... -
Page 9: Central Station Monitoring
The system sounds the sirens for 15 seconds to alert you of the condition and allow you to close the door. The Exit Error feature allows the central station to acknowledge the arming error without dispatching the police on a false alarm. XR20 Introduction... -
Page 10: How Your System Operates
Arming Report: Your system can be programmed to send arming or one or more burglary zones the keypad displays the problem and zone bypass reports to a central station. This feature is optional and allows you to bypass those zones. can be programmed for you at any time. XR20 Introduction... -
Page 11: Area System Arming
5. If NO is selected in step 4, the display begins to list each area to which you have access followed by NO YES. Example: OFFICE NO YES. 5a. Select YES for each area you want to arm. 5b. Select NO for each area you do NOT want to arm. XR20 Arming and Disarming... -
Page 12: Area System Disarming
If your system does not have this feature, it can be communication problems that occurred during the armed programmed for you at any time. period are shown. 6. If all areas have been disarmed, the keypad displays ALL SYSTEM OFF. XR20 Arming and Disarming... -
Page 13: All/Perimeter System Arming
The keypad provided and an alarm will occur should an entry door be opened. displays INSTANT. 9. When the system is fully armed, the keypad displays PERIMETER ON for perimeter arming and ALL SYSTEM ON for perimeter XR20 Arming and Disarming... -
Page 14: All/Perimeter System Disarming
Enter your user code. 2. The keypad displays any zones that went into alarm and any communication problems that occurred during the armed period. 3. The keypad next displays ALL SYSTEM OFF to confirm the system is disarmed. XR20 Arming and Disarming... -
Page 15: Home/Away System Arming
ON for Perimeter arming, PERIM/INT ON for Perimeter and 3. Select SLEEP to arm the Perimeter and Interior. Interior arming, and ALL SYSTEM ON for all areas armed. 4. Select AWAY to arm the Perimeter, Interior, and Bedroom. XR20 Arming and Disarming... -
Page 16: Home/Away System Disarming
SILENCE to disarm and then rearm the system. to only turn off the alarm bells. XR20 Arming and Disarming... -
Page 17: Security Command User Menu
The following pages detail each User Menu item and provide condition. instructions on when and how to use them properly. OUTPUTS ON/OFF Allows you to turn on or off any of the outputs described in the System Setup section of this guide. XR20 User Menu... -
Page 18: User Check-In
Activity Check Disabled message to the central station. 3. When YES is selected, the keypad displays CHECK ENABLED for four seconds and then sends the Activity Check Enabled message to the central station. XR20 User Menu... -
Page 19: Sensor Reset
To exit the Output menu option, press the Back Arrow key until you Perimeter and Home/Away systems only.) have returned to the keypad's Status List. This also activates the door strike if your system has an Easy Entry™ access control keypad. XR20 User Menu... -
Page 20: Bypass Zones
4. To reset a zone, enter the zone number and press the Select key does not cause the keypad to beep, call the service department for under RST. assistance. 5. To Bypass a zone, enter the zone number and press the Select key under BYPS. XR20 User Menu... -
Page 21: System Test
Zone Monitor mode. This allows you to open and then close each protected door and window while listening for the keypad to beep confirming its operation. See Zone Monitor. XR20 User Menu... -
Page 22: User Codes
The table to the right lists system functions users are allowed to press COMMAND. access based on the authority level assigned to their codes at the time they are added to the system. 5. The displays changes to CODE NO:. Enter the user code and press COMMAND. XR20 User Menu... -
Page 23: Changing User Codes
7. After you have completed making your selections, the keypad display shows USER # ADDED. Press the Back Arrow key once to add another user or twice to exit the User Menu. XR20 User Menu... -
Page 24: Ambush Codes
1 unless you intend to use the Ambush function. schedule to start as SUN MON TUE WED. Press the COMMAND key to show the remaining days of the week and then press the Select key under your choice. XR20 User Menu... -
Page 25: Extended Schedules
YEAR: - Enter up to two digits for the year. Press COMMAND. The keypad displays – : AM PM. Enter in the new time for The display returns to TIME DAY DATE. Press the Back Arrow the closing schedule to expire. key to exit the User Menu. XR20 User Menu... -
Page 26: Display Events
If you select FIRST, use the COMMAND key to scroll up through the events displays. Select LAST to view events starting from the newest to the oldest. If you select LAST, use the Back Arrow key to scroll down through the event displays. XR20 User Menu... -
Page 27: Zone Bypass Event Displays
Event Types - There are 7 event type you may see here: ALR - Alarm TBL - Trouble RST - Restore LOW - Low battery MIS - Missing xmitter FLT - Zone Fault SVC - Service Smoke Detector Note: LOW and MIS are for wireless systems only. XR20 User Menu... -
Page 28: Arming And Disarming Event Displays
Press any Select key to display the area number and user number. Arming Event Types - There are 2 event type you may see here: ARM - User armed the system DIS - User disarmed the system XR20 User Menu... -
Page 29: User Code Change Event Displays
User 19 added by user 12 at 11:41 AM. US:19 BY US:1 2 User Code Event Types - There are 3 event type you may see here: ADD - User added DEL - User deleted CHG - User code or authority level has been changed. XR20 User Menu... -
Page 30: System Monitor Event Displays
System Monitor Event Names - There are 2 system monitors: assistance. AC POWER BATTERY Note: This feature is not displayed if it has not been enabled on your system. XR20 User Menu... -
Page 31: System Setup
Enter the Output number above when using the Outputs On Off User My system sends Zone Bypass reports. Menu option to manually toggle the outputs. ❏ Yes ❏ No My system sends Ambush reports. ❏ Yes ❏ No XR20 System Setup... -
Page 32: User Codes
All Areas - Does this user have the authority to arm and disarm all areas in the system? Arm Only - Is this user restricted to just arming? Refer to the User Codes section of this User's Guide for additional information. Circle Your Selections XR20 System Setup... - Page 33 All Areas - Does this user have the authority to arm and disarm all areas in the system? Arm Only - Is this user restricted to just arming? Refer to the User Codes section of this User's Guide for additional information. Circle Your Selections XR20 System Setup...
-
Page 34: Easy Entry™ User's Guide
Door Strike relay activates. Select NO to arm or disarm individual areas. Select YES, or simply wait, and the keypad will automatically arm or disarm all areas for which you are authorized. XR20 Appendix... -
Page 35: Entry Delay
You can also use a card reader to access the User Menu when the MENU? Strike relay. Area systems allow a delay for you to select only certain areas. See Arming and Disarming. NO YES display is shown. XR20 Appendix... -
Page 36: Fa113 User's Guide
Disarming a Home/Away or All/Perimeter System Press the OFF button once. The Security Command keypads emit These instructions guide you through the operation of the XR20 a single 2-second beep to confirm the disarming. Command Processor system using the FA113 Wireless Keychain Remote. -
Page 37: Pager Direct™ User's Guide
○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ Pager Direct™ Pager Direct™ Security Command Alphanumeric Paging Security Command Numeric Paging Cut along dotted lines Cut along dotted lines XR20 Appendix... -
Page 38: Account Number
Events - LATE TO CLOSE (The system was armed by the scheduled closing time) This is a 3-digit number that identifies the user. ALARM CANCELLED (An alarm has been cancelled by an authorized user) Security Command Numeric Paging Security Command Alphanumeric Paging XR20 Appendix... -
Page 39: Phoneaccess™ User's Guide
PhoneAccess™ User's Guide This exciting feature allows you to call your XR20 system from any outside touch-tone phone to arm and disarm protection areas or turn on or off the panel's relay outputs. Quick Reference Wallet Card How it works PhoneAccess™... -
Page 40: 895 Voice Module
895 Voice Module You can also use the 895 Voice Module with the XR20 Command Processor™ panel. The 895 allows you to call your security system using a touchtone telephone, and perform a variety of functions, ranging from arming and disarming to changing user codes. The 895 1. -
Page 41: Common Keypad Displays
Call your service person. The panel has attempted to communicate with the central station 10 Transmit Fail Call your service person. times and has not succeeded. Non-Polled Address The keypad has been assigned to an invalid address. Call your service person. XR20 Appendix... - Page 42 Disarming During an Alarm, SET VOLUME LEVEL, 2 COMMAND key, 2 Common Keypad Displays, 37 Setting the Date and Time, 21 Easy Exit Feature, 12 Special Security Command Date and Time, 21 Instant Arming, 9 Messages, 3 DIALING display, 6 XR20 Index...
