DMP Electronics SecurityCommand XR10 User Manual

Executive series
Hide thumbs Also See for SecurityCommand XR10:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
User’s Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SecurityCommand XR10 and is the answer not in the manual?

Questions and answers

Related Manuals for DMP Electronics SecurityCommand XR10

Summary of Contents for DMP Electronics SecurityCommand XR10

  • Page 1 User’s Guide...
  • Page 2 Silencing an Alarm All/Perimeter and Home/Away Systems 1. While the alarm bell or siren is sounding, enter your user code. The keypad displays DISARM SILENCE. 2. Press the SELECT key under SILENCE to stop the bell or siren. This does NOT disarm the system. 3.

  • Page 3: Table Of Contents

    ® Security Command User's Guide XR6 and XR10 Command Processor Panels Table of Contents About your system Emergency Evacuation Plans ........ii Bypass Zones .............. 12 About Your Security System .......... 1 Zone Monitor ............... 13 The Security Command Keypad ........2 System Test ..............

  • Page 4: Emergency Evacuation Plans

    Emergency Evacuation Plans First Floor Second Floor The National Fire Protection Association recommends that you establish an emergency evacuation plan to safeguard lives in the event of a fire or other emergency. Use the following steps as a guide. Fire Escape Draw a floorplan of your home or business On a clean sheet of paper, draw the walls, windows, doors, and stairs.

  • Page 5: About Your Security System

    Introduction About Your Security System A Note About False Alarms One of the most important concerns facing the security industry today Your Security Command system has been designed with your safety is false alarms. The accidental dispatching of police and fire agencies and comfort in mind.

  • Page 6: The Security Command Keypad

    Data Entry keys The Security Command Keypad These keys allow you to enter your user code when arming or Your system may have one or more easy to use Security Command disarming or enter other information into the system. keypads (16 or 32 character) that allow you to properly operate the The ARROW key system.

  • Page 7: Special Security Command Messages

    Special Security Command Messages INVALID CODE The code number you've entered a second time is considered invalid As you use your system, you’ll occasionally see a keypad display that by the system. asks you to enter a code or that describes a condition on the system. Below are some examples of the displays you'll see: SYSTEM TROUBLE or SERVICE REQUIRED There is an electronic failure in your system.

  • Page 8: Understanding Security System Terms

    Understanding Security System Terms Entry or Exit Zone Almost all systems have one or more doors through which you can Throughout this guide, and in some displays on your keypad, you’ll enter or exit the premises. These doors are programmed with a delay see certain words or phrases that might be unfamiliar.
  • Page 9 Understanding Security System Terms Status List The keypad Status List displays any alarm or trouble condition on a Central Station Monitoring zone and any trouble condition that occurs with the AC power or Your system can also be programmed to automatically send alarm, battery power.

  • Page 10: How Your System Operates

    How your System Operates If the problem cannot be corrected, you can force arm or bypass the zone or wait until the zone can be repaired by a service technician. Your system has been programmed to operate in one of two modes: A force armed zone is ignored by the system until it restores to All/Perimeter, or Home/Away.

  • Page 11: Arming And Disarming

    All/Perimeter System Arming Arming an All/Perimeter System Area Assignment: Your security system is divided into two separate 1. Enter your user code. The keypad displays PERIM ALL. areas. Motion detectors, inside doors, and other interior protection 2. Select PERIM to arm the Perimeter area only. devices are assigned to the Interior area while windows and exterior 3.

  • Page 12: All/Perimeter System Disarming

    All/Perimeter System Disarming Disarming an All/Perimeter System Disarming: While the system is armed, you can only enter the 1. During the entry delay time, the keypad displays ENTER CODE: premises through an entry/exit delay door without causing an alarm. . Enter your security code number. After opening the door, the Security Command keypad sounds a 2.

  • Page 13: Home/Away System Arming

    Home/Away System Arming 3. Select SLEEP to arm the Perimeter and Interior. 4. Select AWAY to arm the Perimeter, Interior, and Bedroom. Area Assignment: Your security system is divided into two or three separate areas. Motion detectors, inside doors, and other interior 5.

  • Page 14: Home/Away System Disarming

    Home/Away System Disarming Disarming a Home/Away System Disarming: While the system is armed, you can only enter the 1. During the entry delay, the keypad displays ENTER CODE:. premises through an entry/exit delay door without causing an alarm. Enter your 4 digit security code. After opening the door, the Security Command keypad sounds a 2.

  • Page 15: User Menu Functions

    Sensor Reset Security Command User Menu User Code Level: Master or Standard Many of the features of your system have been put into a User Menu you can access from any Security Command keypad. The menu Function: Resets smoke or glassbreak detectors. Also clears Fire/ requires you to enter your user code and then only shows those Supervisory alarm and trouble keypad displays.

  • Page 16: Outputs On Off

    Outputs On Off Bypass Zones User Code Level: Master or Standard. User Code Level: Master or Standard. Function: Allows you to turn the system's outputs on and off. Function: Allows you to bypass a zone prior to arming the system. This function is used to individually turn your system’s relay outputs Bypassing is usually done when a zone cannot be restored to normal on and off.

  • Page 17: Zone Monitor

    Using the Zone Monitor Function Zone Monitor User Code Level: Master and Standard. 1. Access the User Menu. 2. Press the COMMAND key until ZONE MONITOR? displays. Function: Allows the system to monitor selected disarmed zones (doors, windows, or motion detectors) and sound a tone at the keypad 3.

  • Page 18: System Test

    User Codes System Test User Code Level: Master only. User Code Level: Master or Standard. Function: Allows you to add or delete a user from the system or Function: System Test is used to test the battery, alarm bell or siren, change their security code or authority level.

  • Page 19: Ambush Codes

    User Codes 7. The display changes to MASTER? NO YES. Select YES to continued make this a Master code level with the authority to Add, Delete, User Code Authority Levels and Change user code information. System Options Standard Master Selecting NO displays TEMP CODE NO YES. Sensor Reset Master code levels do not display TEMP CODE.
  • Page 20 User Codes Changing User Code Numbers continued Deleting User Code Numbers: 1. Access the User Menu. 2. Press the COMMAND key until USER CODES? displays. 1. Access the User Menu. 3. Press any one of the SELECT keys. The keypad displays ADD 2.

  • Page 21: Display Events

    Display Events The event display you'll see at the keypad is slightly different for each event type. User Code Level: Master or Standard. Using the Display Events Function Function: Allows you to review up to 16 past events that occurred on your system from any keypad.

  • Page 22: Zone Event Displays

    Zone Event Displays Arming and Disarming Event Displays This section displays alarms, troubles, and other events that could This displays any arming or disarming of system areas. occur on your system's protection zones. Display Description Display Description JONES RESIDENCE All areas of the system were armed by JONES RESIDENCE A burglary alarm occurred on zone 2.

  • Page 23: User Code Change Event Displays

    User Code Change Event Displays User Checkin Event Displays This displays any addition, deletion, or change to a user code. This shows when a user selected the pager CHECKIN feature from the User Menu. See page 11 for more information. Display Description Display...

  • Page 24: System Setup

    System Setup Security Command keypads We've provided this System Setup section to allow you to track the Address Locations current and future status of the programmable options on your Security Command system. If you make changes to the system, you _____________________________________________ should update the information contained on these pages.

  • Page 25: User Codes

    User Codes Your system provides you with twelve user codes you can program Area Names for individual users. As you add new users or change current user's List your system's area names and numbers below: codes, you can keep track of their name, user number, and authority Area Name Area...
  • Page 26 Numeric Pager Display 00128–301 234 Account Message Always Zone, Area, or Number Zero User Number Account Number This number has been programmed into your Security Command system as an identifier. Whenever the system sends a message to your pager, it will always send the account number first to identify itself.
  • Page 27 Notes:...
  • Page 28 2841 E. Industrial Drive Springfield, MO 65802-6310 800-641-4282 LT-0226 (4/99)

This manual is also suitable for:

Securitycommand xr6
