User Code Change Event Displays
This displays any addition, deletion, or change to a user code.
16-Character Display
Description
12 ADD 19 1017
User 12 added user 19 on Oct. 17. Press
the right Select key for the time this
occurred.
32-Character Display
Description
A DD 11: 41A 10 / 17
User 19 added by user 12 at 11:41 AM.
US:19 BY US:1 2
User Code Event Types - There are 3 event type you may see here:
ADD - User added
DEL - User deleted
CHG - User code or authority level has been changed.
XR20
User Menu
Supervisory Event Displays
This displays the date and time of an automatic test report.
16-Character Display
Description
AUTO RECALL 1017
The test report was sent on Oct. 17.
32-Character Display
Description
MSG 11: 58P 10 / 17
The test report was sent to the central
AUTO R ECALL
station at the date and time shown.
25
