IBM SPSS Data Collection Installation Manual page 40

32
Chapter 3
Firewall between the IBM SPSS Data Collection Interviewer Server/Accessories server and the
data server
Communication between the Interviewer Server/Accessories server and the data server takes
place using TCP on port 1433. This port must be opened before the installation begins, as the
installation process writes to the data server.
If you have SQL running on a named instance, then the port number is dynamically assigned
and could be something other than 1433. If you know which port number is being used, you
should open this port rather than port 1433. If you do not know which port is being
used (and for more information about named SQL instances in general) refer to
http://groups.google.nl/groups?q=connecting+to+second+SQL+instance+through+firewall&hl=nl&lr=&selm=uGvO
(http://groups.google.nl/groups?q=connecting+to+second+SQL+instance+through+firewall&hl=nl&lr=&selm=u
Firewall between the DPM servers in the cluster
Communication between DPM servers in a cluster takes place using TCP on port 65100.
Note: When implementing a cluster in a Windows Server 2008 environment, you must ensure
that TCP port 65100 is open via the Windows firewall. Refer to you Windows Server 2008
documentation for information on opening ports.
Ports used by IBM SPSS Data Collection products
Default Product\Service
TCP/UDP
Ports
80 (HTTP) All Web Services (Interviewer Server
443 Web Server, Accessories Server)
(HTTPS)
1433 SQL Server (Data Server)
5080 IBM® SPSS® Data Collection Base
Professional(for debugging survey
scripts)
7000 IBM® SPSS® Data Collection Dialer
65100 .NET Remoting for Scriptwriter
Services/DPM Servers
Notes
If your web site runs SSL or uses a different port number, you
can specify this on the Internet Information Services (IIS)
Configuration page during the installation procedure.
If you have SQL running on a named instance, then the port
number is dynamically assigned and could be something other
than 1433.
Refer to your Dialer documentation for instructions on changing
the default port.
If you want to use a different port, you may set it in the
registry key HKEY_LOCAL_MACHINE\SOFTWARE\SPSS
\MRPropertyManagement\2.0\ Remoting\PortNo.
Note: When implementing a cluster in a Windows Server 2008
environment, you must ensure that TCP port 65100 is open
via the Windows firewall. Refer to you Windows Server 2008
documentation for information on opening ports.
