Appendix D: OBDII Module Setup and Command
Bit 3,2,1,0: Telltale Status 10
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
#100
Bit 7,6,5,4: Telltale Status 11
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
Bit 3,2,1,0: Telltale Status 12
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
#101
Bit 7,6,5,4: Telltale Status 13
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Bit 3,2,1,0: Telltale Status 14
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
#102
Bit 7,6,5,4: Telltale Status 15
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
76
