Chapter 3: Jumpers and Switches
Pin Definition
A71 LVDS_A0+
A73 LVDS_A1+
A75 LVDS_A2+
A77 LVDS_VDD_EN
A79 LVDS_A3+
A81 LVDS_A_CK+
A83 LVDS_I2C_CK
A85 NC
A87 NC
A89 PCIE0_CK_REF-
A91 RSVD
A93 NC
A95 RSVD
A97 VCC_12V
A99 VCC_12V
A101 VCC_12V
A103 VCC_12V
A105 VCC_12V
A107 VCC_12V
A109 VCC_12V
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Pin Definition
A72 LVDS_A0-
A74 LVDS_A1+
A76 LVDS_A2+
A78 LVDS_A3+
A80 GND
A82 LVDS_A_CK-
A84 LVDS_I2C_DAT
A86 NC
A88 PCIE0_CK_REF+
A90 GND
A92 RSVD
A94 RSVD
A96 GND
A98 VCC_12V
A100 GND
A102 VCC_12V
A104 VCC_12V
A106 VCC_12V
A108 VCC_12V
A110 GND
Pin Definition
B71 NC
B73 NC
B75 NC
B77 NC
B79 LVDS_BKLT_EN
B81 NC
B83 LVDS_BKLT_CTRL
B85 VCC_5V_SBY
B87 VCC_5V_SBY
B89 NC
B91 NC
B93 NC
B95 NC
B97 NC
B99 NC
B101 VCC_12V
B103 VCC_12V
B105 VCC_12V
B107 VCC_12V
B109 VCC_12V
36
Pin Definition
B72 NC
B74 NC
B76 NC
B78 NC
B80 GND
B82 NC
B84 VCC_5V_SBY
B86 VCC_5V_SBY
B88 RSVD
B90 GND
B92 NC
B94 NC
B96 NC
B98 NC
B100 GND
B102 VCC_12V
B104 VCC_12V
B106 VCC_12V
B108 VCC_12V
B110 GND
