Appendix D: OBDII Module Setup and Command
Bit 3,2,1,0: Telltale Status 2
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
#96
Bit 7,6,5,4: Telltale Status 3
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
Bit 3,2,1,0: Telltale Status 4
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
#97
Bit 7,6,5,4: Telltale Status 5
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Bit 3,2,1,0: Telltale Status 6
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
#98
Bit 7,6,5,4: Telltale Status 7
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
Bit 3,2,1,0: Telltale Status 8
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
#99
Bit 7,6,5,4: Telltale Status 9
1000 = off
1001 = Cond. Red
1010 = Cond. Yellow
1011 = Cond. Info
1100–1110 = Reserved
1111 = not available
