Chapter 2: External Connectors Pinout Description
Chapter 2: External Connectors Pinout Description
Power Button
Connector Number: 1
1
2
2
1
4
3
4
3
A1
C1
A1
C1
MH2
MH1
MH1
MH2
Pin
Definition
1
GND
3
+V3.3ALW
A1
VCC5_S
Copyright © 2012 NEXCOM International Co., Ltd. All Rights Reserved.
Pin
Definition
2
NC
4
NC
C1
GND
Power On & SSD or HD Active LED
Connector Number: 2
T1
B1
Pin
Function Description
T1
POWER LED
B1
HD LED
6
VTC 7120-BK Series User Manual
