12.0 MAIN PCB BOARD

Check
Terminal
Vcc
V-
V+
V
TH
V
SP
NOTE:
Check the voltage of V
both voltages simultaneously.
Typ.
Voltage
For logic circuit
No adjustment volume
+ 5.0
For RS-232 interface
- 12.0
No adjustment volume
For RS-232 interface
+ 12.5
No adjustment volume
For Thermal Head, DC motor and ribbon
+ 24.0
solenoid
RV1 on switching power supply unit
(PTR637-30)
For Stepping Motor
+ 36.0
RV1 on switching power supply unit
(PTR637-30)
and V
before you adjust the voltages by RV1. RV1 adjusts
SP
T H
Usage and
Adjusted By
27
