DOCUMAX 6390
Packaging
Unpacking the printer
Check the following items in the package, if of these items are missing, please
contact your dealer. (As shown below)
Paper Feed Knob
CD ROM
(Including User's Guide
Paper Support Tray
and Print Driver)
Removing protective material
1. Open the shipping carton, unpack the printer and remove the tape from around the front
cover as shown. Save all the original packing materials, so that they can be reused
when transporting the printer.
Remove tape
QUICK START GUIDE
Ribbon Cartridge
AC Power Cord
Quick Start Guide
Part identification
Front cover
Ribbon cartridge
Printhead
Power switch
Paper guide
Front View
Paper feed knob
USB interface
Back View
Parallel interface
Ethernet interface
Gap adjust lever
Paper select lever
Paper feed knob
Paper support tray
Paper tractor
AC power inlet
Bottom View
