Ribbon running condition within Part C does not normally cause problems. However,
ribbon running condition within Part C can help find the solution. Examining the ribbon
running condition at the bottom edge of the ribbon applicator can indicate adjustments
that may need to be performed.
6.2
Running Condition
Make sure of the following prior to the adjustment:
Use full width media (5.2 in./132 mm) when checking.
Rotate the head pressure screw clockwise completely.
Set up the printer with factory default parameters.
1.
Select the print data which exhibits even horizontal contrast. Feed a few blank
labels, then issue about ten media (labels) for inspection of running conditions.
2.
Check the ribbon for wrinkles. If wrinkles are present, stop the media (labels) by
[PAUSE]. See Figure 13 as an example of wrinkles produced on the bottom right
side of the ribbon.
Figure 13. Wrinkle On Ribbon
19
