2.0 INITIAL SETUP

2.1

Assembly and Setup Procedure

The 5106 printer provides various output modes which will correspond to the various
customer requirements.
application.
2.2

Selection of Media Output Mode

Output Mode under printer parameters provides the selection. Refer to the next section
when choosing parameter settings.
Output Mode
Non-spooled
Spooled
Presentation
Optional Cutter
Assemble and setup the printer according to the customer
Function
The label is issued with the liner.
(The printer does not rewind the
label and liner). Attaching the
Tear Bar instead of the
Presentation Sensor, the label
and liner can then be torn off
together (manually)
The label is issued with liner, and
the printer rewinds both the
issued label and liner on the
Take-Up Roller (as an external
rewinder).
The labels are issued with liner
and peeled off at the dispenser
and present Label Holder. The
printer rewinds only the liner,
inside the printer.
The labels are issued with liner
and separated in the specified
timing by the Optional Cutter.
Remark
Remove label Presentation
Sensor and then attach the
Tear Bar.
Position the Take-Up
Roller on the outside of the
printer (as an external
rewinder).
Set the Take-Up Roller on
the inside of the printer.
Optional cutter mechanism
is required.
3
