10.0 EXTERNAL CONNECTOR AND PIN ASSIGNMENTS

Pin Assignments of RS232 Interface :
Pin No.
1
2
3
4
5
Pin Assignments of Centronics Parallel Interface:
Pin No.
Signal
1
STROBE
2
DATA 1
3
DATA 2
4
DATA 3
5
DATA 4
Signal
Pin No.
N/C
RXD
TXD
DTR
GND
Pin No.
Signal
6
DATA 5
7
DATA 6
8
DATA 7
9
DATA 8
10
AKNLG
Signal
6
DSR
7
RTS
8
N/C
9
N/C
Pin No.
11
12
13
14-17
18-30
Signal
BUSY
PE
SEL
N/C
GND
25
