Flush Mount Installation
Figure 1
Front View:
H = 4.65"
W = 10.3"
Figure 2
Front View:
Front view:
Flush Mount Picture 2.5"
Flush Mount Angled View:
Flush Mount Picture 4.0"
Flush Mount Angled View:
Valcom, Inc.
5614 Hollins Road
Roanoke, VA 24019
Side View
D3 = .28"
D4 = 3.5"
H = 4.65"
Side View
D3 = .28"
D4 = 3.5"
H = 7.5"
