Option 34 - Once a Day Pulse Input - Set Duration:
Use the bottom button to scroll between "01-59".
This option allows the user to set the second(s) they want the clock to go
to.
Option 40 - Activating Diagnostic Mode:
Use the bottom button to scroll between "E" and "d".
If the option is set to "d" (disable), pressing the top button will take the
user back to the time. Setting the option to "E" (enable) will enter option
41.
Option 41 - Setting the Diagnostic
Press the bottom button to scroll between "1-5 and 9".
01 = Diagnostic 1 04 = Diagnostic 4
02 = Diagnostic 2 05 = Diagnostic 5
03 = Diagnostic 3
09 = Overrides diagnostic to go to the master clock time
Option 42 - Duration of time Until the Clock Resumes Normal Operation:
Press the bottom button to scroll between "00-99".
This option shows how much time the information on the clock from di-
agnostics 1 or 2 will be displayed before going back to normal operation.
Refer to the specific analog clock's installation manual for diagnostic
information.
