EVAPORATOR TEMPERATURE / SEALED SYSTEM LOW-SIDE PRESSURE CORRELATION
NOTE: The temperature/pressure table at right is for refer-
ence only. A unit's temperature/pressure correlation may
differ from those listed due to: variations in evaporator ther-
mistor location, set-points, where the sealed system is in
the refrigeration cycle, ambient temperature, etc.
If a unit is experiencing temperature problems, it is recom-
mended that you reference the General Troubleshooting
Guide before accessing the sealed system. After all
mechanical and electrical components have been ruled
out, sealed system pressures can be checked by applying
solder-on process valves and referencing the preceding
page. Do NOT use bolt-on process valves as they are
prone to leak.
This table should only be used as a last quick check before
entering the sealed system.
If low side pressure is
NORMAL
LOW
LOW
HIGH
HIGH
Series
Series
2
2
(600-
)
(600-
)
PRESSURE INDICATIONS
& high side pressure is
NORMAL
LOW
HIGH
LOW
HIGH
8-17
Troubleshooting Guides
Temperature
Pressure
-30°F (-34°C)
10" Vac
-25°F (-32°C)
7" Vac
-20°F (-29°C)
4" Vac
-15°F (-26°C)
0" Vac
-10°F (-23°C)
2 Psi
-5°F (-21°C)
4 Psi
0°F (-18°C)
7 Psi
5°F (-15°C)
9 Psi
10°F (-12°C)
12 Psi
15°F (-9°C)
15 Psi
20°F (-7°C)
18 Psi
25°F (-4°C)
22 Psi
30°F (-1°C)
26 Psi
35°F (2°C)
30 Psi
40°F (4°C)
35 Psi
45°F (7°C)
40 Psi
50°F (10°C)
45 Psi
55°F (13°C)
51 Psi
60°F (16°C)
57 Psi
65°F (18°C)
64 Psi
70°F (21°C)
71 Psi
75°F (24°C)
78 Psi
possible problem is
MECHANICAL
(see General Troubleshooting Guide)
RESTRICTION
INEFFICIENT COMPRESSOR
OVER CHARGE
#3758407 - Revision B - August, 2006
LEAK
