Sub-Zero 601R-2 Technical & Service Manual page 179

Built-In
Built-In
WIRING SCHEMATIC
MODELS 611G-2 & 650G-2
BLACK
WHITE
J5
J7
E2 E7 E10 E6
J3
J1
J2
REFRIGERATOR
LIGHT SWITCH
YELLOW
LIGHT SWITCH
YELLOW
2
2
(600- )
(600- )
L1 NEUT
115 VOLTS
60 CYCLES
RED
PURPLE
GRAY
TAN
J6
ICEMAKER
PINK
GRAY/WHITE
DEFROST
BLUE TERMINATOR
CONDENSER
WHITE/RED
FAN MOTOR
LIGHT
ORANGE TERMINATOR
ORANGE
WHITE/BLUE
FREEZER
ORANGE W/BLACK
ORANGE W/BLACK
Series
Series
Wiring Diagrams / Schematics
WHITE
REFRIGERATOR
FAN SWITCH
REFRIGERATOR
OVERLOAD
PROTECTOR
FREEZER
OVERLOAD
PROTECTOR
FAN SWITCH
PURPLE
TAN
ICEMAKER
SWITCH
2700-3700 Ohms
PINK
2300-3000 Ohms
WHITE/RED
M
10-11
-This wiring information is provided for use by qualified
service personnel only.
-Disconnect appliance from electrical supply before
beginning service.
-Be sure all grounding devices are connected when
service is complete.
-Failure to observe the above warnings may result in
severe electrical shock.
RED
M
REFRIGERATOR
REFRIGERATOR
COMPRESSOR
COMPRESSOR
STARTING
M
RELAY
FREEZER
COMPRESSOR
COMPRESSOR
M
FREEZER
RED
M
WATER
160 Ohms
VALVE
FILL TUBE
HEATER
DEFROST
20-22 Ohms
HEATER
DOOR HEATER
TERMINATOR
REFRIGERATOR
LIGHTS
ACCENT
LIGHTS
FREEZER
LIGHTS
PART NUMBER 3757920 REV A
#3758407 - Revision B - August, 2006
REFRIGERATOR
FAN MOTOR
RUNNING
CAPACITOR
FREEZER
STARTING
RELAY
FREEZER
FAN MOTOR
LIGHT
