Model 661-2 - Sub-Zero 601R-2 Technical & Service Manual

Built-In
Built-In
WIRING SCHEMATIC
MODEL: 661-2
L1
BLACK
WHITE
GRAY
GRAY
PURPLE
TAN
J5
J6
J7
E2 E7 E10 E6
J3
J2 J1
PINK
GRAY\WHITE
WHITE\RED
ORANGE
REFRIGERATOR
LIGHT SWITCH
YELLOW
ORANGE/BLACK
FREEZER
LIGHT SWITCH
YELLOW
Series
Series
2
2
(600- )
(600- )
NEUT
115 VOLTS
60 CYCLES
REFRIGERATOR
OVERLOAD
PROTECTOR
ICEMAKER
DEFROST
BLUE
TERMINATOR
OPENS ON T-RISE
CONDENSER
FAN MOTOR
LIGHT
ORANGE TERMINATOR
OPENS ON T-RISE
LIGHT
TERMINATOR
ORANGE/BLACK
OPENS ON T-RISE
WHITE\BLUE
10-15
Wiring Diagrams / Schematics
-This wiring information is provided for use by qualified
service personnel only.
-Disconnect appliance from electrical supply before
beginning service.
-Be sure all grounding devices are connected when
service is complete.
-Failure to observe the above warnings may result in
severe electrical shock.
WHITE
REFRIGERATOR
FAN SWITCH
REFRIGERATOR
COMPRESSOR
M
FREEZER
FREEZER
OVERLOAD
COMPRESSOR
PROTECTOR
M
FREEZER
FAN SWITCH
160 OHMS
21 OHMS
1890 OHMS
M
REFRIGERATOR
ORANGE
FREEZER
LIGHTS
FREEZER
LIGHT
2600 OHMS
REFRIGERATOR
FAN MOTOR
RED
M
RUNNING
CAPACITOR
REFRIGERATOR COMPRESSOR
STARTING RELAY
RUNNING
CAPACITOR
FREEZER
COMPRESSOR
STARTING
RELAY
FREEZER
FAN MOTOR
RED
M
WATER
VALVE
DEFROST
HEATER
DRAIN
HEATER
LIGHTS
FILL TUBE
HEATER
PART NUMBER 3758436 REV A
#3758407 - Revision B - August, 2006
