Sub-Zero 601R-2 Technical & Service Manual page 171

Built-In
Built-In
WIRING SCHEMATIC
MODEL: 601R-2
HIGH VOLTAGE WIRING SCHEMATIC
BLACK
WHITE
J5
J7
E2 E7 E10 E6
J3
J2 J1
REFRIGERATOR
YELLOW
LIGHT SWITCH
2
2
(600- )
(600- )
L1 NEUT
115 VOLTS
60 CYCLES
J6
GRAY
ORANGE
LIGHT
ORANGE
TERMINATOR
Series
Series
Wiring Diagrams / Schematics
WHITE
REFRIGERATOR
OVERLOAD
PROTECTOR
REFRIGERATOR
FAN SWITCH
10-3
-This wiring information is provided for use by qualified
service personnel only.
-Disconnect appliance from electrical supply before
beginning service.
-Be sure all grounding devices are connected when
service is complete.
-Failure to observe the above warnings may result in
severe electrical shock.
REFRIGERATOR
REFRIGERATOR COMPRESSOR
COMPRESSOR STARTING
M
RELAY
REFRIGERATOR
RED
M
CONDENSER
FAN MOTOR
M
REFRIGERATOR
LIGHTS
#3758407 - Revision B - August, 2006
FAN MOTOR
PART NUMBER 3756711
