  • Page 1 HD Conference Dome VCD Series Installation Manual...

  • Page 3: Table Of Contents

    Installing the Camera to the Mounting Plate Installing a Pipe Mount Description 7.1.1 Tools/Supplies Required 7.1.2 Preparing the Ceiling for Installation 7.1.3 Installing the Camera to the Mounting Plate Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 4: Table Of Contents

    Configuring the HD Conference Dome Camera 11.4.1 Changing the Network Settings 11.5 The Livepage 11.5.1 Entering a Keyboard Control Command 11.6 Saving Snapshots 11.7 Recording Video Sequences 11.8 Processor Load 11.9 The RECORDINGS Page F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 5: Hd Conference Dome Table Of Contents | En

    Diagnostics 12.26 Preposition and Tours 12.27 Sectors 12.28 Miscellaneous 12.29 Logs 12.30 Audio 12.31 Advanced Mode: Recording 12.32 Storage Management 12.33 Recording Profiles 12.34 Retention Time 12.35 Recording Schedule Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 6: Table Of Contents

    Keyboard Commands by Number Preventive Maintenance Troubleshooting 15.1 HD Conference Dome Operation and Control BVIP Firmware Updates 16.1 Upgrading the HD Conference Dome 16.2 Beginning the Firmware Update Process Index F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 7: Safety

    This will prevent damage to the unit from lightning and power line surges. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 8 – If unsure of the type of power supply to use, contact your dealer or local power company. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 9 16. Attachments, changes, or modifications - Only use attachments/accessories specified by the manufacturer. Any change to or modification of the equipment not expressly approved by Bosch could void the warranty or, in the case of an authorization agreement, authority to operate the equipment.

  • Page 10: Safety Precautions

    NOTICE! This symbol indicates information or a company policy that relates directly or indirectly to the safety of personnel or protection of property. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 11: Important Notices

    Connect equipment to the unit's inputs only after this unit has had its grounding plug connected to a grounded outlet or its ground terminal is properly connected to a ground source. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 12 Please dispose of these units at an environmentally compatible recycling facility, in line with European Directive 2002/96/EC. Environmental statement - Bosch has a strong commitment to the environment. This unit has been designed to respect the environment as much as possible.
  • Page 13 SELV All the input/output ports are Safety Extra Low Voltage (SELV) circuits. SELV circuits should only be connected to other SELV circuits. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 14 Network Voltage (TNV) circuits. Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information. To minimize the risk of lost digital information, Bosch Security Systems recommends multiple, redundant recording systems, and a procedure to back up all analog and digital information.
  • Page 15 The user may find the following booklet, prepared by the Federal Communications Commission, helpful: How to Identify and Resolve Radio-TV Interference Problems. This booklet is available from the U.S. Government Printing Office, Washington, DC 20402, Stock No. 004-000-00345-4. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 16 AVERTISSEMENT: Ce produit est un appareil de Classe A. Son utilisation dans une zone résidentielle risque de provoquer des interférences. Le cas échéant, l’utilisateur devra prendre les mesures nécessaires pour y remédier. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 17 CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING-RELATED FUNCTIONS OF THIS PRODUCT. Copyright This user guide is the intellectual property of Bosch Security Systems, Inc. and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.

  • Page 18: Customer Support And Service

    | Safety HD Conference Dome Customer Support and Service If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. Service Centers Repair Center Telephone: 800-566-2283 Fax: 800-366-1329 E-mail: repair@us.bosch.com...

  • Page 19: Unpacking

    Verify that all the parts listed in the Parts List are included. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative.

  • Page 20: Description

    The following diagram depicts a typical installation: HD Conference Dome HD Conference Dome Coax 75 Ohm Cable Local Area Network CAT-5E Cable DCN Next Generation Conference System Computer HD-SDI Seamless Switcher/Scaler Display F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 21 This installation should be made by qualified service personnel and conform to the National Electrical Code and applicable local codes. NOTICE! A grounded conduit is required in order to meet the EMC Regulation Requirements. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 22: Installing A Surface Mount

    Appropriate tool for cutting a hole in drywall or ceiling tile (if applicable) – 4 in. x 4 in. Junction box with 90 mm (3.54 in.) mount holes (indoor installation) – One (1) ground – T-10 Torx wrench F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 23: Preparing The Surface Mount For An Indoor Installation

    Ensure junction box and mounting screws are capable of supporting a maximum load of 11.33 kg (25 pounds). 90 mm (3.54 in.) Figure 4.2 Install User-supplied Junction Box Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 24: Installing The Camera To The Mounting Plate

    Attach user supplied ground to junction box. Connect the mating connectors with the flying leads to the user supplied wiring (see Section 8 Preparing the Wiring, page 51 for wiring information). F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 25 (item 1, below) into the recessed slot on the top of the camera dome (Item 3) to the right of the safety locking screw (item 2). Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 26 Figure 4.6 Tab/Slot Alignment Detail Vertical Tab (on mounting plate) Locking Screw Recessed Slot (on dome housing) Brass Button (total of three on housing) Slotted Tab (total of three on mounting plate) F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 27 Figure 4.7 Attach Dome to Mounting Plate Vertical tab 10. Secure the safety locking screw with the user supplied locking torx wrench (T-10). Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 28: Installing A Wall Mount

    Additional Tools Required – Appropriate straight slot screwdrivers – No. 2 Phillips screwdriver – Appropriate tool for cutting a hole in drywall or ceiling tile (if applicable) – T-10 Torx wrench F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 29: Preparing The Wall Mount For An Indoor Installation

    Figure 5.1 Wall Mount Dimensions Fit a user-provided metal single-gang junction box to the wall. Attach a grounded metal conduit to the junction box clamp. Figure 5.2 Metal Conduit Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 30 The metal junction box and mounting surface must be capable of supporting a maximum load of 11.33 kg (25 pounds). Skip to Section 5.1.3 Installing the Camera to the Mounting Plate, page 31, to continue the installation. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 31: Installing The Camera To The Mounting Plate

    Attach user supplied ground to junction box. Connect the mating connectors with the flying leads to the user supplied wiring (see the Section 8 Preparing the Wiring, page 51 for wiring information). Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 32 (item 1, below) into the recessed slot on the top of the camera dome (Item 3) to the right of the safety locking screw (item 2). F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 33 Figure 5.7 Tab/Slot Alignment Detail Vertical Tab (on mounting plate) Locking Screw Recessed Slot (on dome housing) Brass Button (total of three on housing) Slotted Tab (total of three on mounting plate) Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 34 11. Secure the safety locking screw with the user supplied locking torx wrench (T-10). 12. Pull excess wire back into the mount tube. 13. Confirm that the housing is electrically grounded. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 35: Installing A Recessed Mount

    Appropriate tool for cutting a hole in drywall or ceiling tile (if applicable) – 4 in. x 4 in. junction box (optional) – T-10 Torx wrench – VJR-A3-SP, support kit for VJR-A3-IC mounting kit Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 36: Preparing The Ceiling For Installation

    Optional: if installing the HD Conference Dome to a suspended ceiling tile or any other surface where additional support is required, the VJR-A3-SP mounting kit is recommended (supplied separately). F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 37 The ceiling/ drywall must have a maximum thickness of 41.7 mm (1.64 in.) and an minimum thickness of 12.7 mm (0.50 in.). Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 38 NOTICE! If you need to install the VJR-A3-SP Support Bracket, refer to the guide included with the bracket. Once the bracket is installed, continue with the next section. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 39: Installing The Camera To The Mounting Plate

    Connect the mating connectors (supplied in the accessory kit) with the flying leads to the user supplied wiring (see the Section 8 Preparing the Wiring, page 51 for wiring information). Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 40 (item 1, below) into the recessed slot on the top of the camera dome (Item 3) to the right of the safety locking screw (item 2). F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 41 Figure 6.6 Tab/Slot Alignment Detail Vertical Tab (on mounting plate) Locking Screw Recessed Slot (on dome housing) Brass Button (total of three on housing) Slotted Tab (total of three on mounting plate) Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 42 (item 3) on the locking clamps. Note: The two (2) sets of raised stand-off tabs (item 4) on each side of the trim ring align with the locking clamps. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 43 Note: Unit should not turn. 13. Use the supplied T-10 Torx wrench to secure the trim ring’s two (2) safety locking screws to the mounting bracket. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 44: Installing A Pipe Mount

    Tools/Supplies Required – Appropriate straight slot screwdrivers – No. 2 Phillips screwdriver – Appropriate tool for cutting a hole in drywall or ceiling tile (if applicable) – T-10 Torx wrench F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 45: Preparing The Ceiling For Installation

    Use the four (4) holes in the flange as a template to mark the position where the holes should be drilled to secure the mount. Figure 7.2 Mark Flange Holes Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 46 Pull the wires from the pipe, starting at the flange end. Figure 7.3 Attach Pendant Pipe Mount to Ceiling CAUTION! Select a rigid mounting location to prevent excessive vibration to the HD Conference Dome Camera. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 47 (3) screws supplied (Figure 1.9). Figure 7.4 Attach Mounting Plate to Dome Cap Crescent Shape Ground Lug Dome Cap Mounting Plate Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 48: Installing The Camera To The Mounting Plate

    (item 1, below) into the recessed slot on the top of the camera dome (Item 3) to the right of the safety locking screw (item 2). F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 49 Figure 7.6 Tab/Slot Alignment Detail Vertical Tab (on mounting plate) Locking Screw Recessed Slot (on dome housing) Brass Button (total of three on housing) Slotted Tab (total of three on mounting plate) Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 50 10. Secure the safety locking screw with the user supplied locking torx wrench (T-10). 11. Pull excess wire back into the mount tube. 12. Confirm that the housing is electrically grounded. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 51: Preparing The Wiring

    24 VAC to HD Conference Dome 670 ft 421 ft 265 ft (204 m) (128 m) (81 m) Table 8.1 Max. Wire Distance from Power Supply to HD Conference Dome Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 52: Power Connections

    Refer to Section 8.5 Ethernet Connection, page 55, for more information about connecting Power over Ethernet. Figure 8.1 Power Cable Ref. # Wire Color 24 VAC 24 VAC Black User-supplied Power Supply F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 53: Video Connection

    Section 12.19 Encoder Profile, page 97. Recommended Coax Specifications Size O.D. between 4.6 mm (0.181 in.) and 7.9 mm (0.312 in.) Shield Copper braid: 95% Central Standard copper center Conductor Terminal Connector Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 54: Connecting The Video

    Terminate the coaxial cable from the head end system with a male BNC connector. Connect the male BNC connector to the Video Out female BNC connector from the base of the camera. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 55: Ethernet Connection

    Cable Type CAT-5E or CAT 6 Ethernet Maximum Distance 100 m (328 ft) Bandwidth 10 Base-T/100 Base-TX PoE+ (indoor models only) IEEE 802.3at, class 4 standard Terminal Connector RJ45, Female Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 56: Audio, Alarms And Relay Connections

    You wire alarms either Normally Open (N.O.) or Normally Closed (N.C.), and must program the alarm inputs N.O. (the default) or N.C. through the HD Conference Dome main menu. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 57: Connecting Alarms (Inputs 1 Through 2)

    Interface>Alarm Inputs. Refer to Section 12 Configuring the HD Conference Dome, page 80, for directions about accessing the Settings page. HD Conference Dome Programmed N.O. Circuit Alarm Indication Open Normal Closed Alarm Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 58: Connecting A Normally Closed Alarm

    Interface>Alarm Inputs. Refer to Section 12 Configuring the HD Conference Dome, page 80, for directions about accessing the Settings page. HD Conference Dome Programmed N.C. Circuit Alarm Indication Open Alarm Closed Normal F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 59: Alarm Outputs

    32 VDC @ 150 ma. Connect the appropriate stripped wire to the open collector of the transistor’s white wire. Connect the appropriate stripped wire to the ground (GND) connector. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 60: Audio Cables

    Internal gain level adjustment is available Wire Specifications Wire Type Coax (recommended) Distance 10 m (33 ft) Gage 22 AWG Shield Bare copper braid: 95% coverage Center conductor Stranded bare copper F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 61: Getting Started

    Refer to Section 11 Using the IP Interface, page 62, for information on configuring the camera. WARNING! Before powering the dome on, remove the clear protective plastic sheet on top of the bubble. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 62: Using The Ip Interface

    (Intranet) or on the Internet. You can also update the firmware, load device configurations, store configuration settings, and copy these settings from one camera to another. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 63: System Requirements

    You can find notes on using Microsoft Internet Explorer in the online Help in Internet Explorer. If you choose to use a computer running Microsoft Internet Explorer or any of the Bosch software, the computer must conform to the following minimum requirements: –...

  • Page 64: Connecting The Hd Conference Dome To The Pc

    The HD Conference Dome can also be connected directly to a PC using an Ethernet crossover cable with RJ45 connectors (see option B below). Figure 11.1 HD Conference Dome System Configuration HD Conference Dome IP Connection Network Switch Computer F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 65: Configuring The Hd Conference Dome Camera

    HD Conference Dome Using the IP Interface | en NOTICE! You can also use the Bosch Configuration Manager utility to configure the network settings for an HD Conference Dome. Go to www.boschsecurity.com to download the Configuration Manager software and Operating Manual.

  • Page 66: Changing The Network Settings

    Subnet Mask, and a Gateway IP Address. Using the Configuration Manager Configuration Manager is an optional network utility provided on the Bosch Security Systems Web site. Use the Configuration Manager Manual to make any configuration changes. NOTICE! Depending on the PC network security settings, the user may have to add the new IP address to the browser’s trusted sites...
  • Page 67 HD Conference Dome Using the IP Interface | en Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 68 Click the Service Settings link, located in the left pane of the Settings window. Click the Network link to open the Network Settings page. Figure 11.2 Network Settings Page F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 69: The Livepage

    Other information may be shown next to live video image on the Livepage. The display depends on the settings on the Livepage Configuration page (see the HD Conference Dome online help). Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 70 While discovery is executed, gaps might be shown in places which the discovery has not yet reached. The gap will automatically be replaced by the true video, as soon as the correct information is available. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 71 Depending on the unit and network configuration, each HD Conference Dome can have up to 25 Web browser connections or up to 50 connections via the Bosch Video Management System. Protected HD Conference Dome If the HD Conference Dome is password protected against...
  • Page 72 To manually pan throughout the image area, move your cursor over any part of the live video. The image area F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 73 Events such as the triggering or end of alarms are shown in the Event Log field. You can save these messages automatically in a file (see the HD Conference Dome online help). Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 74: Entering A Keyboard Control Command

    Keypad (numbers 0-9) Show a preset shot Set a preset shot Initiates a command Deletes a number in the Command Number field Used to select a menu item Stops a command F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 75 Click the Show Shot button. NOTICE! For more information about the HD Conference Dome settings and controls, click the Help on this page? link to open the HD Conference Dome online help. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 76: Saving Snapshots

    Livepage settings on the Settings page. NOTICE! You can play back saved video sequences using the Player from Bosch Security Systems, which can be installed from the product CD supplied. Image Resolution Sequences are saved at the resolution that has been preset in the configuration for the encoder (see Section 12.3 Basic Mode:...

  • Page 77: Processor Load

    Click a list entry. The playback for the selected sequence starts immediately in the video window. Use the arrow buttons below the list to browse the list. Select the number of entries that are displayed simultaneously. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 78 In addition, you can set markers in the sequences, so-called bookmarks, and leap directly to these. These bookmarks are indicated as small yellow arrows above the time interval. Use the bookmarks as follows: F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 79 Bookmarks are only valid while you are in the RECORDINGS page; they are not saved with the sequences. As soon as you leave the page all bookmarks are deleted. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 80: Configuring The Hd Conference Dome

    The Web browser opens a new page with the configuration menu. Navigation Click one of the menu items in the left window margin. The corresponding submenu is displayed. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 81: Basic Mode: Device Access

    The name makes the task of administering multiple units in larger video monitoring systems easier, for example using the Bosch Video Management System programs. The device name is used for the remote identification of a unit, in the event of an alarm for example. For this reason, enter a name that makes it as easy as possible to quickly identify the location.

  • Page 82: Basic Mode: Date/Time

    For example, it is only possible to identify and correctly evaluate simultaneous recordings when all units are operating on the F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 83: Basic Mode: Network

    Dome is rebooted and the changed settings are activated. CAUTION! If you change the IP address, subnet mask or gateway address, the HD Conference Dome is only available under the new addresses after the reboot. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 84: Basic Mode: Encoder

    IP addresses, you can activate acceptance of IP addresses automatically assigned to the HD Conference Dome. Certain applications (VIDOS, Bosch Video Management System, Archive Player, Configuration Manager) use the IP address for the unique assignment of the unit. If you use these applications,...
  • Page 85 Target bit rate: 20 kbps Maximum bit rate: 22 kbps Encoding interval: 15.00 ips – Target bit rate: 7 kbps Maximum bit rate: 8 kbps Encoding interval: 7.50 ips Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 86: Basic Mode: Audio

    Here you can select a storage medium and immediately start the recording. Storage medium Select the required storage medium from the list. Click the Start button to start the recording immediately. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 87: Basic Mode: System Overview

    VIDOS or Bosch Video Management System programs. Enter a unique, unambiguous name for the camera in this field. You can use both lines for this.

  • Page 88: Password

    The highest authorization level is service. After entering the correct password, you can access all the functions of the HD Conference Dome and change all configuration settings. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 89: Date/Time

    – it is added automatically. Enter the current time or click the Sync to PC button to copy your computer's system time to the HD Conference Dome. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 90 Now click the OK button to save and activate the table. Time server IP address The HD Conference Dome can receive the time signal from a time server using various time server protocols, and then use it F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 91: Display Stamping

    Top, at the Bottom or at a position of your choice that you can then specify using the Custom option. Or it can be set to Off for no overlay information. Select the desired option from the list. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 92 Off for no overlay information. Select the desired option from the list. Specify the exact position (Position (XY)). In the Position (XY) fields, enter the values for the desired position. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 93: Advanced Mode: Web Interface

    The image file is not stored in the HD Conference Dome. Website language Select the language for the user interface here. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 94: Livepage Functions

    The audio data are encoded according to G.711 and require an additional bandwidth of approx. 80 kbps for each connection. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 95 Here you can specify whether the icon for saving individual images should be displayed below the live image. Individual images can only be saved if this icon is visible. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 96: Logging

    12.17 Advanced Mode: Camera 12.18 Installer Menu Main Frequency Sets the frequency of the incoming power supply. This setting is made at the factory and should not be changed. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 97: Encoder Profile

    Internet and one for LAN connections. Pre-programmed profiles are available, each giving priority to different perspectives. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 98 Encoding interval: 7.50 ips You can change individual parameter values of a profile and you can also change the name. You can switch between profiles by clicking the appropriate tabs. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 99 This maximum data rate is not exceeded under any circumstances. Depending on the video quality settings for the I- and P-frames, this fact can result in individual images being skipped. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 100 Use the expert settings to adapt the I-frame quality and the P- frame quality to specific requirements, if necessary. The setting is based on the H.264 quantization parameter (QP). F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 101 A value of 51 results in a very high refresh rate and lower image quality. Default Click Default to return the profile to the factory default values. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 102: Encoder Streams

    Click the 1:1 Live View button below the preview screen to open a new window with the original data stream and to check the image quality and the transmission rate. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 103 15, 20, 25, or 30 ips. – Picture quality: his setting allows you to adjust the image quality. Use the slide bar to choose a quality between Low and High. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 104: Privacy Masks

    To hide all masks from an image view, click the Hide Masks check box. Note: If you choose to hide all masks, you must enable each enable each individual mask to show the mask in the scene. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 105: Camera Settings

    Gain Level option. If you select this option, the HD Conference Dome makes the following changes automatically: – Night Mode: switches to Color – Auto Iris: switches to Constant Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 106 Parts outside this area may be underexposed or overexposed. Select On to optimize the video level for the central area of the image. The default setting is Off. Stabilization Turns on video stabilization. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 107: Lens Settings

    Focus Speed Controls how fast the Auto focus will readjust when the focus becomes blurred. Select from the following options: – Super Slow – Slow – Medium – Fast Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 108 Controls the zoom speed. The default setting is Fast. Zoom Polarity Capability to reverse the operation of the zoom button on the controller. – Normal (default): zoom controls operate normally. – Reverse: zoom controls are reversed. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 109: Ptz Settings

    To disable this feature, click Off. Freeze Frame Select On (default) to freeze the image while the HD Conference Dome moves to a predetermined scene position. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 110: Diagnostics

    Click the Add scene (“+”) button to define the preposition. Select a number for the scene, from 1 to 64. Type an optional name for the scene, up to 20 characters long. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 111 Click the Aux Control tab. Type 8 in the input box and click the Aux On button. To stop the tour, type 8 and click the Aux Off button. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 112: Sectors

    Click Download to obtain the log information. Click Save. Navigate to the directory in which you want to store the log information. Type a name for the log file and click Save. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 113: Audio

    Select a format for audio recording. The default value is G.711. Select L16 if you want better audio quality with higher sampling rates. This requires approx. eight times the G.711 bandwidth. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 114: Advanced Mode: Recording

    This is an external program for configuring recording tasks for video servers. For further information please contact your local customer service at Bosch Security Systems, Inc. Device manager If you activate the VRM option in this screen, the VRM Video Recording Manager will manage all recording and you will not be able to configure any further settings here.
  • Page 115 Check the box in the Rec. 1 or Rec. 2 to specify which data stream should be recorded on the storage media selected. Rec. 1 stores Stream 1, Rec. 2 stores Stream 2. This Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 116 Click a storage medium in the Managed storage media list to select it. Click the Remove button below the list. The storage medium is deactivated and removed from the list. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 117: Recording Profiles

    If you select Off, no automatic recording takes place. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 118 Here you can select the alarm sensor that is to trigger a recording. Virtual alarm Here you can select the virtual alarm sensors that are to trigger a recording, via RCP+ commands or alarm scripts, for example. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 119: Retention Time

    The recording scheduler allows you to link the created recording profiles with the days and times at which the camera's images are to be recorded in the event of an alarm. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 120 Assign the individual holidays to the recording profiles, as described above. Deleting Holidays You can delete holidays you have defined yourself at any time. Click the Delete button. A new window will open. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 121: Recording Status

    You can select how the HD Conference Dome responds to an alarm. In the event of an alarm, the unit can automatically connect to a pre-defined IP address. You can enter up to ten IP Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 122 If connections to more than ten remote stations are to be possible, for example when initiating connections via higher-ranking systems such as VIDOS or Bosch Video Management System, you can store a general password here. The HD Conference Dome can use this general password to connect to all remote stations protected with the same password.
  • Page 123 If the destination unit is unknown, it is advisable to select the First available option. In this case, the image is placed on the first free video output. This is an output on which Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 124 Select the On option to automatically re-establish a connection to one of the previously specified IP addresses after each reboot, after a connection breakdown or after a network failure. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 125 Click the Save... button to save the profile settings to another file. A new window is opened, in which you can specify where you want to save the file and what name you want to save it under. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 126 NOTICE! Additional analysis algorithms with comprehensive functions such as IVMD and IVA are available from Bosch Security Systems, inc. If you select one of these algorithms, you can set the corresponding parameters here directly. You can find information on this in the relevant documents on the product CD supplied.
  • Page 127 The sensor reacts to variations in the brightness of the video image. The darker the observation area, the higher the value that must be selected. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 128 You can reveal the tampering of cameras and video cables by means of various options. Run a series of tests at different times of the day and night to ensure that the video sensor is operating as intended. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 129 Set a high value if fewer sensor fields need to change to trigger an alarm. With a low value, it is necessary for changes to occur simultaneously in a large number of sensor fields to trigger an alarm. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 130 Click Select Area to configure the sensor fields. A new window will open. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 131: Audio Alarm

    The name makes it easier to identify the alarm in extensive video monitoring systems, for example with the VIDOS and Bosch Video Management System programs. Enter a unique and clear name here. Furthermore, in the Forensic Search program, you can use the name as a filter option for quick search through the recordings.

  • Page 132: Alarm E-Mail

    (0.0.0.0). SMTP user name Enter a registered user name for the chosen mailserver here. SMTP password Enter the required password for the registered user name here. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 133 This will make it easier to identify the origin of the e-mail. Test e-mail You can test the e-mail function by clicking the Send Now button. An alarm e-mail is immediately created and sent. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 134: Alarm Task Editor

    Next, specify up to two (2) rule outputs, or the camera’s response to the input. Outputs include a physical alarm relay, an AUX command, or a preposition scene. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 135: Advanced Mode: Interfaces

    Alarm Inputs Select the type of input for each physical alarm. Select from either N.O. (Normally Open) or N.C. (Normally Closed) and provide an optional name for each input. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 136: Relay

    Idle State Select Open if you want the relay to operate as an NO contact, or select Closed if the relay is to operate as an NC contact. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 137: Advanced Mode: Network

    Set button changes to Set and Reboot. Make the desired changes. Click the Set and Reboot button. The HD Conference Dome is rebooted and the changed settings are activated. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 138 IP addresses, you can activate acceptance of IP addresses automatically assigned to the HD Conference Dome. Certain applications (VIDOS, Bosch Video Management System, Archive Player, Configuration Manager) use the IP address for the unique assignment of the unit. If you use these applications,...
  • Page 139 To exchange connection data, you can activate the unsecured RCP+ port 1756. If you want connection data to be transmitted only when encrypted, select the Off option to deactivate the port. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 140 DynDNS.org and you must have registered the required host name for the unit on that site. NOTICE! Information about the service, registration process and available host names can be found at DynDNS.org. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 141: Advanced

    The HD Conference Dome supports the SNMP V2 (Simple Network Management Protocol) for managing and monitoring network components, and can send SNMP messages (traps) to IP addresses. The unit supports SNMP MIB II in the unified Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 142 Identity Enter the name that the RADIUS server is to use for identifying the HD Conference Dome. Password Enter the password that is stored in the RADIUS server. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 143 Select a port for NTCIP and the Address from the appropriate drop-down lists. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 144: Multicast

    Enable To enable simultaneous data reception on several receivers you need to activate the multicast function. To do this, check the box. You can then enter the multicast address. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 145: Ftp Posting

    You can then retrieve these images at a later date to reconstruct alarm events if required. File name You can select how file names will be created for the individual images that are transmitted. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 146: Encryption

    You can limit the bit rate for FTP posting. 12.52 Encryption A special license, with which you will receive a corresponding activation key, is required to encrypt user data. You can enter F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 147: Advanced Mode: Service

    Even changing to another page or closing the browser window leads to an interruption. Refer to Section 16 BVIP Firmware Updates, page 154, for firmware upgrade instructions. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 148 In the address bar of your browser, enter /reset after the IP address of the HD Conference Dome (for example 192.168.0.10/reset). The new SSL certificate is valid. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 149: Licenses

    You can select all required text on this page with the mouse and copy it to the clipboard with the [Ctrl]+[C] key combination, for example if you want to send it via e-mail. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 150: Keyboard Commands By Number

    Digital Zoom Turns digital zoom on and off Lock On/Off Sector Enables/Disables Sector Blanking Blanking * denotes a command applicable to the HD Conference Dome PTZ and Fixed cameras. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 151: Preventive Maintenance

    Do not scrape the bubble with razor blades or other sharp instruments. – Do not use Benzene, Gasoline, Acetone, or Carbon Tetrachloride on the bubble. – Do not clean bubbles in direct sunlight or on very hot days. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 152: Troubleshooting

    Set the synchronization mode to INT.NTSC Model power frequency in LL mode: 60 Hz. F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.

  • Page 153: Hd Conference Dome Operation And Control

    Settings window. – Click the Installer Menu, located under the Camera link. – Select either 50 or 60 Hz from the Frequency pull-down list. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 154: Bvip Firmware Updates

    The HD Conference Dome also allows an operator to update the BVIP firmware via the TCP/IP network. The latest BVIP firmware is available on the Bosch Security Systems Web site. To download the service pack from the Web, navigate to www.boschsecurity.us, click the CCTV link, then click Cameras, PTZ and navigate to the product page for the HD Conference Dome.

  • Page 155: Beginning The Firmware Update Process

    Note: Once the progress bar reaches 100% the system opens the reset page. Allow the reset page to complete its action. Once the reset is complete the upgrade is complete. Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...

  • Page 156: Index

    90 cables default profile 101 coaxial 54 default recording profile 117 power 51 default VCA profile 125 camera deleting recordings 116 selection 71 Description 3 camera name 87 F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 157 Aux On 74 homing 61 keypad 74 HTTP port 139 HTTPS port 139 language 93 licenses 149 identification 81 Livepage 68 IEE 802.3af 55 livepage 94 IEEE 802.1x 142 IGMP 144 Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 158 118 SSL certificate 148 pre-alarm time 118 SSL encryption 124 preparing standard recording profile values drywall ceiling 23 preset shot 75 storage media 115 processor load 77 F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 159 81 unit time 83 user name 81 UTP CAT-5 55 video content analysis 125 video sensor 125 video transmission 153 VRM 114 watermarking 93 wires power 51 Bosch Security Systems, Inc. Installation Manual F.01U.265.806 | 1.0 | 2012.03...
  • Page 160 160 en | Index HD Conference Dome F.01U.265.806 | 1.0 | 2012.03 Installation Manual Bosch Security Systems, Inc.
  • Page 162 Bosch Security Systems, Inc. 850 Greenfield Road Lancaster, PA 17601 U.S.A. www.boschsecurity.com © Bosch Security Systems, Inc., 2012...

Table of Contents
