Setting Up Your Saw

9. Table Insert Installation:

Your saw is shipped with a high-quality, zero-clearance table insert. The insert is factory-adjusted to fit securely
in the table opening and below the table surface. If you wish to perform additional adjustment on the insert, see
page 61 for instructions.
To install the table insert, hold it at a
slight angle, with the rear of the insert
lower than the front. Slide the rear of the
insert around the spreader and against
the back of the table opening so that the
heads of the rear lock-down screws in
the bottom of the insert slide under the
heads of the lock-down screws in the
table opening (see Figs. 15 and 16)
Then lower the front end of the insert into
the table opening and use the included
3 mm hex L-wrench to tighten the front
lock-down screw.
Note: when the blade guard is installed, it
may be necessary to raise the elevation
of the blade to allow the anti-kick pawls
to clear the opening in the table and rest
against the wear plates.
WARNING! Never operate the saw without the table insert in place.
CAUTION! Do not use table inserts made of metal or other electrically-conductive
materials. This can cause the brake to be activated unnecessarily.
hold insert at a slight angle to table
when installing or removing
Fig. 15
rear lock down
screw in insert
Fig. 16
SawStop 10" Professional Cabinet Saw
rear lock down screw
in table opening
