Mechanical Parts And Disassembly - Icom IC-7000 Service Manual

SECTION 6
[FRONT UNIT]
REF. ORDER
NO. NO.
W1 8900013940 Cable OPC-1447 (N=10, L=30)
W2 8900013990 Cable OPC-1445
DS1 5030002820 LCD LTA025A161A
EP1 0880001670 Encoder EX-2832
MP1 8210021760 2427 front panel
MP2 8210021770 2427 rear panel
MP4 8310063800 2427 window plate
MP5 8930069540 2427 A-window sheet
MP11 8610012370 Knob N328
MP12 8610012380 Knob N328 (A)
MP13 8610012390 Knob N329
MP14 8610012400 Knob N330
MP18 8930065660 2427 brake button
MP19 8930065541 2427 power button-1
MP20 8930065550 2427 release button
MP21 8610012340 Knob K246
MP22 8610012330 Knob K247
MP23 8610012320 Knob K248
MP24 8610012311 Knob K249-1
MP25 8610012300 Knob K250
MP26 8610012290 Knob K251
MP27 8610012280 Knob K252
MP28 8610012270 Knob K253
MP29 8610012260 Knob K254
MP30 8610012250 Knob K255
MP31 8610012240 Knob K255 (A)
MP32 8610012210 Knob K256
MP33 8610012220 Knob K257
MP34 8610012230 Knob K258
MP35 8930065530 2427 TS lock button
MP41 8930065590 2427 LCD holder
MP42 8210021790 2427 reflector
MP43 8850002610 Plain washer (AI)
MP44 8830002440 2427 nut
MP51 8930065570 2427 A-release button
MP52 8930065580 2427 B-release button
MP61 8950006480 2427 B-contact base
MP64 8930065610 2427 LCD filter
MP65 8930069670 2427 A-LCD sheet
MP67 8930065600 Coil spring (AI)
MP72 8830001010 Hex nut (A)
MP74 8930036740 1691 brake pad
Screw PH B0 M2 × 8 ZK (BT)
MP81 8810009220
Screw PH B0 M2 × 8 ZK (BT)
MP82 8810009220
MP83 8930066680 Coil spring (AJ)
MP84 8850000110 Flat washer M2 NI BS
Screw FH BT M2 × 4 NI-ZU
MP85 8810008640
MP86 8930065560 2427 slide button
MP87 8010020110 2427 LCD frame
MP88 8930066450 2427 A-prism sheet
MP89 8930066440 2427 B-prism sheet
MP90 8930062190 Double side tape (AJ)
MP91 8610012551 Knob N331 assembly -1
(incl: Base, Cover, Finger reset, etc)
MP101 8930066760 2427 A-sponge
MP102 8930066750 2427 B-sponge
MP103 8930066740 2427 C-sponge
MP104 8930066730 2427 D-sponge
MP106 8930067580 Insulation sheet (LG)
MP107 8930049260 Himelon sheet CA
MP108 8930067710 2427 A-sheet
MP109 8930067720 2427 B-sheet
MP110 8930067700 2427 B.P. sheet
MP111 8930067960 Sponge (IQ)

MECHANICAL PARTS AND DISASSEMBLY

DESCRIPTION QTY.
[DISPLAY UNIT]
REF. ORDER
NO. NO.
1 MP1 8510016980
1
MP2 8510016970
[VR UNIT]
1
REF. ORDER
1
NO. NO.
R1 7210003230
1
1
S1 2250000170
1
1
[MAIN UNIT]
1
1
REF. ORDER
1
NO. NO.
1
MP1 8510017200
1
MP2 8930067510
1
MP3 8930030380
1
MP4 8930068000
1
MP101 8510017330
1
MP102* 8930068000
1
MP201 8510017210
1
MP501* 8510017620
1
MP802 8930067500
1
MP1951 8510017200
1
MP2001 8510017170
1
MP2002 8930068240
1
1
[LOGIC UNIT]
1
1
REF. ORDER
1 NO. NO.
1
BT1301 3020000330
1
1
MP1 8510017000
1
MP2 8510016990
1
MP3 8930068080
1
MP5 8930068370
1
MP6 8930056010
1
MP7 8930068370
1
MP201 8930055051
1
MP301 8930062210
1
MP1301 8930052770
2
MP2221 8930055051
2
2
[DDS UNIT]
3
REF. ORDER
2
NO. NO.
2
J1051 6450001790
2
J1101 6450001640
2
1 J1151 6450001840
1
1 MP201 8510017200
1 MP202* 8510017440
2 MP301* 8510017230
1
MP302 8930024170
MP321* 8510017250
2
MP451 8510017500
1
MP452* 8510017240
1
MP453* 8930063970
1
MP601 8930067520
1
MP801* 8930024170
2
MP851 8510017260
1
MP1101 8930067530
1
MP1102 8930067520
1
*: Refer to SEC 8 BOARD LAYOUTS.
1
6 - 1
DESCRIPTION
2427 shield case
2427 shield plate
DESCRIPTION
Variable resistor TP96D00A-17F-10KBX2
Encoder TP90D96AE20-17F (1352)
DESCRIPTION
2427 A-shield plate
2427 B-earth spring
Ferrite sheet (C) 15 × 8 × 2
Shield sponge (AT)
2427 LPF case Y807
Shield sponge (AT)
2427 B-shield plate
2427 mix shield plate
2427 A-earth spring
2427 A-shield plate
2427 mic plate
2427 C-earth spring
DESCRIPTION
Lithium battery ML920S/F9D
2427 logic case
2427 logic cover
Thermally sheet (AU)
2427 A-magnetic shield
Enboss tape (K)
2427 A-magnetic shield
Thermally sheet (V)-1
Thermally sheet (AL)
Double coated tape (Y)
Thermally sheet (V)-1
DESCRIPTION
Connector HLJ7000-01-3010
Connector TCS5044-01-4111
Connector TCS7568-43-201
2427 A-shield plate
2427 B-DDS plate
2427 DDS case
Earth spring (G)
2427 DDS plate
2427 C-shield plate
2427 A-DDS case
Shield sponge (AM)
2427 DDS spring
Earth spring (G)
2427 A-DDS plate
Sponge (IP)
2427 DDS springe
QTY.
1
1
QTY.
1
1
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
QTY.
1
1
1
1
1
2
1
1
1
1
1
QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
