4-4 TRANSMITTER ADJUSTMENT (Continue)
ADJUSTMENT ADJUSTMENT CONDITION
TX OUTPUT 1 • Connect an RF power meter to
POWER (HF) [ANT1] connector.
• Connect an audio generator to
2
[MIC] connector and set as;
Level
3
• Transmitting
4
5
6
7
APC (HF) 1
TX OUTPUT 1 • Connect an RF power meter to
POWER (AM) [ANT1] connector.
• Apply no audio signal to [MIC]
connector.
• Transmitting
TX OUTPUT 1 • Connect an RF power meter to
POWER [ANT1] connector.
(50 MHz) • Connect an audio generator to
2
[MIC] connector and set as;
Level
3
• Transmitting
4
5
6
: 1.5 kHz/30 mV
Po(HF APC Low Volt)
: 1.5 kHz/30 mV
DISPLAY
Po Min(HF) Set the output power to 1 W using [DIAL].
Then push [F-4 (SET)] .
Set the output power to 10 W using
Po Tune(HF)
[DIAL]. Then push [F-4 (SET)].
Po 25%(HF) Set the output power to 25 W using
[DIAL]. Then push [F-4 (SET)].
Po 50%(HF) Set the output power to 50 W using
[DIAL]. Then push [F-4 (SET)].
Set the output power to 75 W using
[DIAL]. Then push [F-4 (SET)].
Po 100%(HF) Set the output power to 95 W using
[DIAL]. Then push [F-4 (SET)].
Set the output power to 105 W using
Po Max(HF)
[DIAL]. Then push [F-4 (SET)] key.
APC(HF) Push [F-4 (SET)].
Set the output power to 35 W using
AM POCV Ratio
[DIAL]. Then push [F-4 (SET)].
Po Min(50 M) Set the output power to 1 W using [DIAL].
Then push [F-4 (SET)].
Po Tune(50 M) Set the output power to 10 W using
[DIAL]. Then push [F-4 (SET)].
Po 25%(50 M) Set the output power to 25 W using
[DIAL]. Then push [F-4 (SET)].
Set the output power to 50 W using
Po 50%(50 M)
[DIAL]. Then push [F-4 (SET)].
Po 100%(50 M) Set the output power to 90 W using
[DIAL]. Then push [F-4 (SET)].
Po Max(50 M) Set the output power to 100 W using
[DIAL]. Then push [F-4 (SET)].
