• CONNECTION

• Microphone connector (Rear panel view)

NOTE! Connect the test equipment to the
micropho0ne connector on the rear panel,
otherwise the transmitter adjustment will not
adjusted properly.
Pin 5
MIC GND
Pin 6
MIC INPUT
1 8
Pin 7
GND
DC power supply
AA13.8 V/30 A
–
Audio
+
generator
to [MIC]
+
– Millivoltmerter
Pin 4
PTT
to [DC 13.8 V]
Ammeter
5 A, 30 A
to [EXT SP]
to [ANT 1/2]
4 - 2
AC
millivoltmeter
Speaker
RF power meter
A200 W/50 Ω
Frequency counter
Standard signal
aagenerator
CAUTION!
DO NOT connect the
signal generator while
transmitting.
