Top View - Icom IC-7000 Service Manual

8-3 MAIN UNIT

• TOP VIEW

J2002
1 MIC
MICE 2
GND
AFO
NC
PWK
NC
F8V
9 LRXD
LTXD 10
to CONNECT
unit J1
J2005
GND 28
27 FDAT
PRES
MCK
GND
MST
HFOR
3R3V
HREF
GND
P2R8
NC
P4R8
AT13
PR4S
THER
PR3S
TB1V
2M8L
TB2V
VUFOR
PHT8
PT8V
PT8V
P4T8
ID4V
P2T8 2
1 IDRV
to PA
unit J980
J2004
ID1V 28
27 ID3V
H6CR8
ID2V
ICH
POWS
ICL
HV
GND
GND
GND
GND
GND
GND
GND
GND
GND
GND
8V
8V
14V
14V
14V
14V
14V
14V
14V 2
1 14V
to PA
unit J2
J2403
3 FANG
NC
FANV
1
to CHASSIS
MF1
J2406
1
to DDS unit J952
P4
1LO
from DDS unit J851
P101
YGR
from PA unit J101
J2405
30 1
to DDS unit J951
8 - 3
P6
2LO
from DDS unit J151
30
J2251
1
30
to LOGIC unit J701
30
16
J2252
31
15
to LOGIC unit J651
J2003
1 8VM
U/DM
MAFM
SENM
MCEM
MICM
GND
8 SQSM
to Microphone
J2601
2 ESPE
1 ISPO
to CHASSIS SP1
J2231
2 YGND
1 YY-VIDEO
to CONNECT
unit W1
1
60
