Icom IC-7000 Service Manual page 43

[PA UNIT]
REF ORDER
NO. NO.
S.RES MCR10EZHJ 10 Ω
R417 7030000140
R418 7030000010 S.RES MCR10EZHJ JPW
R451 7030003470 S.RES ERJ3GEYJ 182 V (1.8 kΩ)
S.RES ERJ3GEYJ 4R7 V (4.7 Ω)
R452 7030004040
S.RES ERJ3GEYJ 330 V (33 Ω)
R453 7030003260
R454 7030003860 S.RES ERJ3GE JPW V
R455 7030003640 S.RES ERJ3GEYJ 473 V (47 kΩ)
R456 7030003700 S.RES ERJ3GEYJ 154 V (150 kΩ)
R457 7030003750 S.RES ERJ3GEYJ 394 V (390 kΩ)
R458 7030003710 S.RES ERJ3GEYJ 184 V (180 kΩ)
R459 7030003740 S.RES ERJ3GEYJ 334 V (330 kΩ)
R460 7030003740 S.RES ERJ3GEYJ 334 V (330 kΩ)
S.RES ERJ3GEYJ 390 V (39 Ω)
R461 7030003270
R462 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R463 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
S.RES ERJ3GEYJ 120 V (12 Ω)
R464 7030003210
R465 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R466 7030003860 S.RES ERJ3GE JPW V
R467 7030003640 S.RES ERJ3GEYJ 473 V (47 kΩ)
R468 7030008240 S.RES ERJ12YJ0R00U
S.RES ERJ3GEYJ 101 V (100 Ω)
R470 7030003320
S.RES ERJ3GEYJ 390 V (39 Ω)
R471 7030003270
S.RES ERJ3GEYJ 151 V (150 Ω)
R472 7030003340
S.RES ERJ3GEYJ 151 V (150 Ω)
R473 7030003340
S.RES ERJ3GEYJ 151 V (150 Ω)
R474 7030003340
S.RES ERJ3GEYJ 151 V (150 Ω)
R475 7030003340
S.RES ERJ3GEYJ 390 V (39 Ω)
R476 7030003270
S.RES ERJ3GEYJ 221 V (220 Ω)
R477 7030003360
S.RES ERJ3GEYJ 101 V (100 Ω)
R502 7030003320
R503 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
S.RES MCR10EZHJ 100 Ω
R504 7030000260
R505 7030003540 S.RES ERJ3GEYJ 682 V (6.8 kΩ)
R507 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R508 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R510 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R511 7030003540 S.RES ERJ3GEYJ 682 V (6.8 kΩ)
R512 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
S.RES ERJ1TYJ 101U (100 Ω)
R513 7030010520
S.RES ERJ12YJ100U (10 Ω)
R515 7030006060
R516 7030003860 S.RES ERJ3GE JPW V
S.RES ERJ1TYJ 101U (100 Ω)
R517 7030010520
R518 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R519 7030000010 S.RES MCR10EZHJ JPW
R551 7030003470 S.RES ERJ3GEYJ 182 V (1.8 kΩ)
S.RES ERJ3GEYJ 4R7 V (4.7 Ω)
R552 7030004040
S.RES ERJ3GEYJ 330 V (33 Ω)
R553 7030003260
R554 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R555 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R556 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R557 7030003740 S.RES ERJ3GEYJ 334 V (330 kΩ)
R558 7030003710 S.RES ERJ3GEYJ 184 V (180 kΩ)
R559 7030003720 S.RES ERJ3GEYJ 224 V (220 kΩ)
R560 7030003720 S.RES ERJ3GEYJ 224 V (220 kΩ)
R561 7030003740 S.RES ERJ3GEYJ 334 V (330 kΩ)
S.RES ERJ3GEYJ 390 V (39 Ω)
R562 7030003270
S.RES ERJ3GEYJ 681 V (680 Ω)
R563 7030003420
S.RES ERJ3GEYJ 120 V (12 Ω)
R564 7030003210
R565 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R567 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
R568 7030003680 S.RES ERJ3GEYJ 104 V (100 kΩ)
S.RES ERJ3GEYJ 331 V (330 Ω)
R570 7030003380
R575 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R576 7030003540 S.RES ERJ3GEYJ 682 V (6.8 kΩ)
R577 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R578 7030003540 S.RES ERJ3GEYJ 682 V (6.8 kΩ)
R701 7030003500 S.RES ERJ3GEYJ 332 V (3.3 kΩ)
R702 7030003500 S.RES ERJ3GEYJ 332 V (3.3 kΩ)
R703 7030003500 S.RES ERJ3GEYJ 332 V (3.3 kΩ)
R704 7030003500 S.RES ERJ3GEYJ 332 V (3.3 kΩ)
R705 7030009300 S.RES ERJ1WY0R00U
R721 7030011240 S.RES LRF3W-LF-01-R020F
R722 7030011240 S.RES LRF3W-LF-01-R020F
S.RES ERJ3GEYJ 4R7 V (4.7 Ω)
R723 7030004040
R733 7030009591 S.RES ERA3YED 472V (4.7 kΩ)
R734 7510001470 S.TMR NTCG20 4AG 473JT
R735 7030009591 S.RES ERA3YED 472V (4.7 kΩ)
R736 7510001470 S.TMR NTCG20 4AG 473JT
R742 7030003640 S.RES ERJ3GEYJ 473 V (47 kΩ)
R743 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R744 7030003860 S.RES ERJ3GE JPW V
R749 7030003860 S.RES ERJ3GE JPW V
R750 7030003860 S.RES ERJ3GE JPW V
R773 7030003860 S.RES ERJ3GE JPW V
R960 7030003860 S.RES ERJ3GE JPW V
S.RES ERJ3GEYJ 331 V (330 Ω)
R961 7030003380
R962 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R963 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R964 7030003860 S.RES ERJ3GE JPW V
R965 7030003640 S.RES ERJ3GEYJ 473 V (47 kΩ)
S.RES ERJ12YJ330U (33 Ω)
R966 7030008190
R967 7030003640 S.RES ERJ3GEYJ 473 V (47 kΩ)
DESCRIPTION M.
LOCATION
B 95.5/132.5
B 99.3/133.9
B 81.5/121.7
B 85.5/119.3
B 81.6/118.4
B 77.3/116
B 73.2/117.5
B 72/114.4
B 71.2/111.9
B 73.8/112.4
B 69.6/111.3
B 76.6/112.1
B 77.7/103.3
B 72.9/99.6
B 74.4/102.4
B 74.2/105.7
B 66.5/101.7
B 62.1/100.2
B 75/118.9
B 89.1/121.9
B 67.7/98.8
B 69.6/98.3
B 69.6/99.5
B 69.6/100.7
B 63.5/96.9
B 64.9/96.7
B 64.8/94.9
B 61.8/97.6
T 112.1/87.9
T 112.6/86
T 114.2/86.2
B 119.9/124.8
B 110.2/123.1
B 107.1/121.9
B 110.3/125.7
B 112.1/133.9
B 107.1/123.1
B 103.7/114.2
T 92.1/108.9
T 90.6/114.3
B 103.7/118.4
B 97.5/112.7
B 111.1/119.5
T 78.2/117.8
T 76.7/119.1
T 73/118.9
T 66.8/120.4
T 68.1/114.7
T 69.9/116.6
T 65.7/112.9
T 70.5/111.2
T 65.7/111.7
T 65.6/110.5
T 68.3/112.4
T 70.1/106.6
T 65.4/107.3
T 63.5/103
B 65.8/108.1
T 70.1/104
T 69.7/100.7
T 62.8/100.3
T 68.4/100.7
T 71.8/100
T 68/120.4
T 69.9/119
B 82.2/16.9
B 83/14.5
B 80.6/16.9
B 79.7/14.5
B 134.6/23.8
B 83/22.3
B 83/29.6
B 140.5/14.7
B 138.6/10.4
T 111.9/58.2
B 140.2/12.5
T 153.3/77.1
B 86.4/6.5
B 82.5/10.5
T 67.8/9.6
B 65/5.2
B 66.6/5.2
T 103.4/9.5
B 43.2/125.7
B 42/138.3
B 37.4/137.8
B 40.3/126.3
B 24.8/131.2
B 32.6/130.5
B 11.1/129.6
B 34.2/130.5
[PA UNIT]
H/V REF ORDER
NO. NO.
R968 7030003860
R969 7030003600
R970 7030003680
R971 7540000130
R972 7030003620
R973 7030003620
R974 7030003620
R994 7030003560
R995 7030003560
R996 7030003560
R997 7030003560
R998 7030003320
R999 7030003320
R1000 7030003320
R1001 7030003320
R1002 7030000280
R1003 7030000290
C101 4030011600
C102 4030011600
C103 4030011340
C104 4030011600
C105 4510004591
C106 4030011600
C107 4030011600
C108 4030011600
C109 4030007130
C112 4030011600
C113 4030011600
C114 4030011600
C116 4030007060
C118 4030007130
C119 4030007130
C120 4030007020
C122 4510008500
C151 4030011600
C152 4030006880
C153 4030011600
C154 4030006860
C201 4030006860
C202 4030006860
C204 4030011600
C205 4030006860
C206 4030017810
C207 4030017810
C208 4030011600
C209 4030007170
C214 4030018940
C215 4030018930
C217 4030011600
C218 4030018930
C219 4030018930
C251 4030011180
C252 4030011180
C253 4030011080
C254 4030011160
C261 4030012480
C262 4030018940
C263 4030018770
C266 4030018950
C267 4030018930
C301 4030001100
C302 4030001020
C303 4030011600
C304 4030017320
C305 4510004591
C306 4030006860
C307 4030006860
C308 4030006860
C309 4030011600
C311 4030018750
C312 4030018750
C313 4030011600
C314 4030018750
C315 4030018750
C319 4030011730
C320 4030011730
C323 4030003810
C324 4320001050
C325 4320001070
C327 4030011790
C331 4030011600
C332 4030011600
C333 4030018940
C340 4030006860
C341 4030006860
C342 4030006860
C404 4030006860
C405 4030011740
C406 4030006860
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
