• BOTTOM VIEW (LOGIC UNIT)

J651
60 1DST VDL 1
MMDK
3DST
PDT SQSS
PCK DOTK
DASK
1CN0
1CN1 WFML
PRES# LTXD
LRXD
LOST
RS_RXD CIV
RS_TXD CIVE
MST START
MDT KEY
MCK MUDL
NC FORL
SNDS REFL
SDSS ALCL
2T8V SNDL
4T8V DPTL
TXS THML
RXS CPU_P12
POWS RTKI
VOUT CPU_P22
PWRK CPU_P94
GND CPU_P95
BT1301
GND IMR
GND CPU_PF6
GND MMSL
GND NC
GND IMR2
31 GND NC 30
to MAIN unit J2252
H85 H80 H75 H70 H65 H60 H55 H50 H45 H40 H35 H30 H25 H20 H15 H10 H5
8 - 10
V45
V40
V35
V30
J701
15 GND AFMS 16
DSPO2 MOSI
GND SCK
DSPO1 VSTB
V25
GND NC
DOUT NC
GND NC
NC 24M
GND HV
V20
GND 8V
GND 8V
GND 5V
DSPI1 5V
GND 3V
V15
1 DSPI2 3V 30
to MAIN unit J2251
V10
V5
V0
H0
