Icom IC-7000 Service Manual page 54

[HM-151]
REF ORDER
NO. NO.
IC1 1140011490 S.IC µPD789071MC-041-5A4-E1
IC3 1110006310 S.IC BD5245G-TR
Q1 1530001941 S.TR 2SC2712-BL (TE85R,F)
Q2 1590000680 S.TR DTC114EUA T106
Q3 1590001330 S.TR DTA114EUA T106
Q5 1510000771 S.TR 2SA1586-GR (TE85R,F)
D1 1790000950 S.ZEN MA8056-M (TX)
D3 1750000940 S.DIO ISS400 TE61
D4 1750000940 S.DIO ISS400 TE61
D6 1750000940 S.DIO ISS400 TE61
D7 1750000940 S.DIO ISS400 TE61
D9 1750000940 S.DIO ISS400 TE61
D10 1750000940 S.DIO ISS400 TE61
D11 1750000940 S.DIO ISS400 TE61
D16 1730002280 S.ZEN MA8091-M (TX)
D17 1730002280 S.ZEN MA8091-M (TX)
D18 1730002280 S.ZEN MA8091-M (TX)
X1 6060000610 S.CER EFOS4914E3
L1 6200005051 S.COL NLV25T-330J
L2 6200005011 S.COL NLV25T-100J
R2 7030000400 S.RES MCR10EZHJ 1.5 kΩ
R3 7030000400 S.RES MCR10EZHJ 1.5 kΩ
R4 7030000400 S.RES MCR10EZHJ 1.5 kΩ
R5 7030003400 S.RES ERJ3GEYJ 471 V (470Ω)
R6 7030003620 S.RES ERJ3GEYJ 333 V (33 kΩ)
R7 7030003620 S.RES ERJ3GEYJ 333 V (33 kΩ)
R8 7030003550 S.RES ERJ3GEYJ 822 V (8.2 kΩ)
R11 7030003480 S.RES ERJ3GEYJ 222 V (2.2 kΩ)
R12 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R14 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R18 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R19 7030003640 S.RES ERJ3GEYJ 473 V (47 kΩ)
R22 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R23 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R24 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R25 7030003520 S.RES ERJ3GEYJ 472 V (4.7 kΩ)
R27 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R35 7030000400 S.RES MCR10EZHJ 1.5 kΩ
R36 7030003560 S.RES ERJ3GEYJ 103 V (10 kΩ)
R37 7030003460 S.RES ERJ3GEYJ 152 V (1.5 kΩ)
R39 7030003480 S.RES ERJ3GEYJ 222 V (2.2 kΩ)
R40 7030003480 S.RES ERJ3GEYJ 222 V (2.2 kΩ)
R41 7030003580 S.RES ERJ3GEYJ 153 V (15 kΩ)
R42 7030003860 S.RES ERJ3GE JPW V
R44 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R45 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R46 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R47 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R48 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R49 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
R50 7030003440 S.RES ERJ3GEYJ 102 V (1 kΩ)
C1 4030006850 S.CER C1608 JB 1H 471K-T
C2 4510008500 S.ELE EEE1CA101WP
C5 4030007050 S.CER C1608 CH 1H 220J-T
C9 4030007050 S.CER C1608 CH 1H 220J-T
C10 4030007050 S.CER C1608 CH 1H 220J-T
C11 4030007050 S.CER C1608 CH 1H 220J-T
C12 4030011600 S.CER C1608 JB 1E 104K-T
C13 4030011600 S.CER C1608 JB 1E 104K-T
C14 4030006900 S.CER C1608 JB 1H 103K-T
C16 4030006860 S.CER C1608 JB 1H 102K-T
C17 4030006880 S.CER C1608 JB 1H 472K-T
C18 4030006880 S.CER C1608 JB 1H 472K-T
C19 4030011600 S.CER C1608 JB 1E 104K-T
C21 4030011600 S.CER C1608 JB 1E 104K-T
C22 4030011600 S.CER C1608 JB 1E 104K-T
C23 4030011600 S.CER C1608 JB 1E 104K-T
C24 4030011600 S.CER C1608 JB 1E 104K-T
C25 4030011600 S.CER C1608 JB 1E 104K-T
C26 4030011600 S.CER C1608 JB 1E 104K-T
C27 4030011600 S.CER C1608 JB 1E 104K-T
C29 4510008540 S.ELE EEE1CA100SR
C30 4030010210 S.CER C3216 JB 1C 105M-T
C31 4510008540 S.ELE EEE1CA100SR
C32 4030011600 S.CER C1608 JB 1E 104K-T
J1 6510023110 CNR 3008L-8P8C
DESCRIPTION M.
LOCATION
B 51.1/24.5
B 67.3/34.8
B 26.1/11
B 21.6/34.8
B 24.7/34.8
B 54.8/37.7
B 23.1/17
B 64.7/23.2
B 64.7/29.2
B 58.7/20.8
B 42.8/16.7
B 34.1/16.3
B 34.9/17.8
B 38.8/14.5
B 55.2/14.5
B 48.8/14.5
B 13.1/13.7
B 42.6/22.3
B 12.3/28.9
B 11/13.9
B 24.2/8.3
B 41.9/8.3
B 57.3/8.2
B 28.6/11.2
B 26.8/34.7
B 23.3/36.8
B 19.1/33.7
B
B 55/34.2
B 47.2/6.1
B 41.6/33.6
B 38.4/34.5
B 37.9/18.7
B 56.1/18.1
B 58/18.6
B 59.8/18.9
B 68.1/32.5
B 69.1/11.9
B 20.5/30.6
B 19.1/30.6
B 24.4/5.7
B 24.4/3
B 17/32.7
B 68.4/21.6
B 57.3/22.1
B 53.9/18
B 37.8/15.8
B 37.6/17.1
B 45.3/17.6
B 57.3/26.2
B 58.1/23.4
B 52/16.9
B 35.5/5.8
B 14.9/30.4
B 20.8/16.8
B 19.8/11.6
B 17/5.6
B 64.9/34.4
B 44.3/27.6
B 67.5/37.2
B 14.7/13.6
B 11.7/17.4
B 10.4/17.4
B 13/25.8
B 11.7/25.8
B 10.4/28.5
B 23.1/14
B 67.2/12.1
B 25.6/32.2
B 44.5/6.1
B 51.7/35
B 26.4/16
B 19.8/4.6
B 28.3/4.9
B 55/35.7
[HM-151]
H/V REF ORDER
NO. NO.
DS1 5010000120
DS2 5010000120
DS3 5010000120
DS4 5010000120
DS5 5010000120
DS6 5010000120
DS7 5010000120
DS8 5010000120
DS10 5040002890
DS11 5040002620
MC1 7700002310
S1 2260000980
W1 8900011270
EP1 6910012350
EP2 6910012350
EP3 6910012350
EP4 6910012350
EP5 6910012350
53/35
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
5 - 25
DESCRIPTION
S.LED LN1371G-(TR)
S.LED LN1371G-(TR)
S.LED LN1371G-(TR)
S.LED LN1371G-(TR)
S.LED LN1371G-(TR)
S.LED LN1371G-(TR)
S.LED LN1371G-(TR)
S.LED LN1371G-(TR)
S.LED SML-310FT T86
S.LED SML-311UT T86
MIC EM-140
SW SKHHLP014A
WIR OPC-1153
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
S.BEA MMZ1608Y 102BT
H/V
M.
LOCATION
T 21.9/11
T 21.9/32
T 39.3/11
T 39.3/32
T 55.9/2.5
T 56.2/26.8
T 71.7/14.8
T 72.2/33.8
T 51.6/5
T 51.6/38
B 10.4/25.8
B 14.3/17.4
B 13/17.4
B 14.7/11
B 15/25
S.=Surface mount
