Factory Default Settings

SPG600 & SPG300 Sync Pulse Generators User Manual
Table 3-8 lists the instrument factory default settings. These settings can be
recalled by selecting Factory Default from the PRESET : RECALL menu item
in the System menu.

Table 3-8: Factory default settings

Menu item name
Video menu
ANALOG SYNC (STD)
ANALOG SYNC (OPT)
TEST SIGNAL (ANALOG)
TEST SIGNAL (SDI)
TIMING (ANALOG)
VERTICAL
HORIZONTAL
FINE (Option 01 only)
TIMING (SDI)
VERTICAL
HORIZONTAL
OVERLAY
Blink
OVERLAY: LOGO
Logo
X
Y
OVERLAY: ID TEXT
Status
X
Y
PARAMETER
COMPONENT
PRECISION
EDH
Settings
Black Burst
Black Burst
SMPTE Color Bars
SMPTE Color Bars
0 Line
µ
0.0000 sec
0.0 nsec
0 Line
µ
0.0000 sec
OFF
OFF
0.0 %APH
0.0 %APH
Disable
10.0 %APH
80.0 %APH
Y, Cb, Cr
10-bit
Enable
