Appendix D: Rackmounting the Instrument
(SPG600 Option 1R Only)

Minimum Tool and Equipment List

SPG600 & SPG300 Sync Pulse Generators User Manual
This section provides instructions for installing the SPG600 into a standard 19-inch
equipment rack.
For information on how to install the SPG300 into a standard 19-inch
NOTE.
equipment rack, refer to the Instructions included in each of the rackmounting kits.
The following tools are required to install the rackmounting hardware into the
equipment rack. All tools are standard tools that are readily available.
Table D-1: Tools required for rackmount installation
Item
no. Name
1 Screwdriver handle
(magnetic)
2 No.2 Phillips tip
3 No.2 Pozidrive tip
To prevent the rackmounted instrument from tipping forward onto the
WARNING.
operator, install the instrument so that the operator will be able to access all of its
rear-panel connectors without pushing down on the instrument
Verify that the rack does not become unstable with the instrument fully extended.
Do not leave the instrument extended when finished accessing the rear panel.
Description
Accepts 1/4 inch hex-head driver tips
Phillips-driver tip for M3 size screw heads
Pozidrive-driver tip for number 2 size screw heads
