Appendix B: Using the Remote Interface
Launching the Java Applet
B-4
When you launch the Java applet, it is downloaded from the sync pulse generator
and launched. There is no software installation required to use the applet (other
than the Java Run-Time Environment noted previously).
To launch the Java applet:
1. Launch your Web browser and type the network address of the sync pulse
generator into the URL entry box. For example:
http://117.117.898.898
Many web browsers do not correctly interpret leading zeros in IP
NOTE.
addresses. If the IP address shown in the Configuration menu contains leading
zeros, such as in 134.151.037.251, remove the "0" when entering it into the
address line of the browser. For example, 134.151.037.251 should be entered as
134.151.37.251.
Once you type the network address of the sync pulse generator, press Return
to access the Remote Interface.
2. Select Launch Applet on the Web browser window. The Web browser
launches the Java applet and display the screen shown in Figure B-2.

Figure B-2: Java applet

SPG600 & SPG300 Sync Pulse Generators User Manual
