Table A-3: Serial Digital Interface (Standard And Option 03 - Tektronix SPG600 User Manual

Table A-2: Analog outputs (standard and Option 02) (cont.)
Characteristic
Timing offset
Range
Resolution
Output signals
NTSC and NTSC No Setup
PAL
ID text
Logo

Table A-3: Serial digital interface (standard and Option 03)

Characteristic
Output connector type
Number of outputs
Standard
Option 03 (SPG600 only)
Output impedance
Return loss
Formats
Signal amplitude, typical
Rise and fall time
Jitter, typical
Embedded audio
Number of channels
Frequency
Level
Preemphasis
Click
Timing offset
Range
Resolution
Output signals
525-270
625-270
ID text
Logo
SPG600 & SPG300 Sync Pulse Generators User Manual
Performance requirement
Full color frame
< 1/27 MHz
Maximum 20 characters
Gray scale, 4 level
Performance requirement
BNC
2
4
75 Ω
> 15 dB
800 mV ± 10%
0.4 ns to 1.5 ns
< 0.2 UI
16 (4 groups)
Silence to 20 kHz
-60 dBFS to 0 dBSF
None, CD, and FCC
1 s, 2 s, 3 s, 4 s, and Off
Full color frame
< 1/27 MHz
Maximum 20 characters
Gray scale, 4 level
Appendix A: Specifications
Reference information
Refer to Table 3-2 on page 3-7.
Refer to Table 3-2 on page 3-7.
Blanking interval: 1 s, 2 s, 3 s, or off
Blanking interval: 1 s, 2 s, 3 s, or off
Reference information
SDI 1 and SDI 2
SDI 1, SDI 2, SDI 3, and SDI 4
525-270, 625-270 (270 Mbps)
20% to 80%
The settings of the channels 9 to 16 are a
copy of those of the channels 1 to 8.
31 descrete settings
1 dB resolution
Refer to Table 3-3 on page 3-10.
Refer to Table 3-3 on page 3-10.
Blanking interval: 1 s, 2 s, 3 s, or off
Blanking interval: 1 s, 2 s, 3 s, or off
A-3
