Figure 3-2: Video Menu Diagram - Tektronix SPG600 User Manual

Press the VIDEO button
ANALOG SYNC (STD)
Black Burst
ANALOG SYNC (OPT)
Black Burst
TEST SIGNAL (ANALOG)
Standard
TEST SIGNAL (SDI)
Standard
TIMING (ANALOG)
CH-1
TIMING (SDI)
SDI-1
OVERLAY
Analog (STD)
PARAMETER
SDI (STD)

Figure 3-2: Video menu diagram

SPG600 & SPG300 Sync Pulse Generators User Manual
Black Burst
Black with CF (for NTSC or NTSC No Setup)
↵
Black without CF (for PAL)
Black Burst
Black with CF (for NTSC or NTSC No Setup)
↵
Black without CF (for PAL)
Standard
1
Option
Standard
2
Option
CH-1
CH-2
CH-3
CH-4
SDI-1 SDI-3
SDI-2 SDI-4
Analog (STD) Analog (OPT)
SDI (STD)
SDI (STD)
SDI (OPT)
ENTER
To Test signal (analog) submenu
(page 3-6)
CANCEL
ENTER
To Test signal (SDI) submenu
(page 3-9)
CANCEL
1
ENTER
CH-5
1 To Timing (analog) submenu
CH-6
(page 3-11)
1
CH-7
1
CANCEL
CH-8
ENTER
2 To Timing (SDI) submenu
(page 3-12)
2
CANCEL
ENTER
1
2
SDI (OPT)
CANCEL
ENTER
To SDI Parameters submenu
(page 3-16)
2
CANCEL
SPG600 Option 02 only
To Overlay submenu
(page 3-13)
1 SPG600 Option 02 only
2 SPG600 Option 03 only
