Accessories - Intuicom RTK Bridge User Manual

5 Accessories

RTK Bridge KITS and Accessories - Typical Survey and Machine control
Product
RTK Bridge
Transceiver Kit with
Verizon modem
RTK Bridge
Transceiver Kit with
AT&T modem
RTK Bridge
Transceiver-Ethernet
Kit
RTK Bridge
Transceiver-Ethernet
Kit (no radio)
RTK Bridge Kit with
Verizon modem (no
radio)
RTK Bridge Kit with
AT&T modem (no
radio)
Base Antenna kit
GPS Antenna kit
Auto Power Adapter
Cable Assembly-RTK
Bridge to 35W Pacific
Crest
Cable Assembly-RTK
Bridge to Trimble
SNB-XXX
Cable Assembly-RTK
Bridge to Satel XXXXX
Revision 1.4
Part Number(s)
Intuicom RTK Bridge with Internal CDMA Modem in Waterproof
Enclosure. Verizon Modem, L1 GPS, 902-928 MHz transceiver, TNC
FIP1-900RTK-VKT antenna connectors, two serial interfaces (lemo). Power and data
cables (AC and DC) included with GPS Antenna, Modem Antenna,
Radio Antenna
Intuicom RTK Bridge with Internal GSM Modem in Waterproof
Enclosure. AT&T Modem, L1 GPS, 902-928 MHz transceiver, TNC
FIP1-900RTK-A2KT antenna connectors, two serial interfaces (lemo). Power and data
cables (AC and DC) included with GPS Antenna, Modem Antenna,
Radio Antenna
Intuicom Bridge & Transceiver for Network RTK Corrections, 902-928
MHz, Embedded GPS, Ethernet interface plus dual serial ports, N-type
FIP1-900RTK-EKT
RF connector, TNC GPS connector. Kit includes GPS and 900 MHz
antenna.
Intuicom Bridge & Transceiver for Network RTK Corrections,
Embedded GPS, Ethernet interface plus dual serial ports, N-type RF
FIP1-101RTK-EKT
connector, TNC GPS connector. Kit includes GPS antenna.
Intuicom RTK Bridge with Internal CDMA Modem in Waterproof
Enclosure. Verizon Modem, L1 GPS, TNC antenna connectors, two
FIP1-101RTK-VKT serial interfaces (lemo). Power and data cables (AC and DC) included
with GPS Antenna, Modem Antenna.
Intuicom RTK Bridge with Internal GSM Modem in Waterproof
Enclosure. AT&T Modem, L1 GPS, TNC antenna connectors, two serial
FIP1-101RTK-AKT
interfaces (lemo). Power and data cables (AC and DC) included with
GPS Antenna, Modem Antenna.
General Accessories
900 Mhz 5 dB Antenna Kit w/ 5/8-11 mount, 20' cable
FIP4-900BAK-NN20
L1 GPS antenna and cable (tnc) with 15 foot cable
FIP4-GPSL1-KT
Standard Auto ligher adapter to ASE power plug
FIP4-SAECIG
Cable assembly to connect RTK Bridge C to a Pacific Crest 35W PDL,
includes power inputs to both units, Lemo to Lemo connection
FIP4-RTKCAB-PC35
Cable assembly to connect RTK Bridge C to a Trimble SNB-XXX,
includes power input (SAE) to RTK Bridge. Lemo to Lemo connection.
FIP4-RTKCAB-SNB
Cable assembly to connect RTK Bridge C to Satel UHF radio; includes
FIP4-XXXX-XXX
power inputs to both units, Lemo to Lemo connection
Description
39
Section 5: Accessories
© 2009 Intuicom, Inc.
