- Page 1 Installation Guide ® RTK Bridge Integration with: ® ® Trimble Intuicom, Inc. 4900 Nautilus Ct. Ste. 100 Boulder, CO 80301 (303) 449-4330 www.intuicom.com...
- Page 2 Intuicom reserves the right to make changes to this document without notice. Unless otherwise agreed to in writing, Intuicom assumes no responsibility or liability for the use of this document or for the infringement of any copyright or other proprietary right and Intuicom shall deem nothing contained in this document a warranty or guarantee.
-
Page 3: Requirements For Installation
1 Requirements for Installation Required Information In order to operate an Intuicom RTK Bridge–X, you are required to have the necessary information to access and log in to the Real-Time Network. This information is entered into the RTK Bridge–X and stored in a profile. More details on setting up an RTK Bridge–X is available in the RTK Bridge-X manual. -
Page 4: Installation Instructions
Section 2: Installation Instructions 2 Installation Instructions Below is the installation Diagram for the recommended installation of the Intuicom RTK Bridge–X utilizing the equipment noted above. Diagram 1 Configuration • Configure the Intuicom RTK Bridge–X to connect to GPS/GNSS Reference network and obtain CMR/CMR+ correction data stream from an appropriate single reference station, or as a VRS. - Page 5 Deutsch connector (DTM06-12S) pinout • Using the Intuicom RTK Bridge–X to FMX data/power cable (XRTKCAB-DD6), connect the RTK Bridge–X data port to the D Port on the FMX. • Apply power and connect to the FMX • Using the touchscreen on the FMX, enter the configuration screen by selecting the “tools”...
- Page 6 • Select the Set-up tab and confirm the GPS is set to receive RTK and then exit back to main configuration page. • If the FMX will not stay in RTK mode, change the correction type to Omnistar, wait for it to time out and then it should be possible to select RTK. Version 1.0 Intuicom, Inc.
- Page 7 • On the main configuration page, select the “diagnostics” button. From the diagnostics screen, select the “AgRemote” button on the lower left. • Once in AgRemote toggle through the screen using the up/down arrows and the right/left arrows. Main Screen on AgRemote Version 1.0 Intuicom, Inc.
- Page 8 Section 2: Installation Instructions • Using AgRemote, configure the D Port on the FMX receiver to receive RTK corrections in the CMR format the data port on the RTK Bridge-X at a baud rate of 38400: Version 1.0 Intuicom, Inc.
- Page 9 Section 2: Installation Instructions • Confirm operation – Confirm the Intuicom RTK Bridge–X is correctly configured and its antennas are connected and within cellular coverage. The main status view in AgRemote should report that it is receiving RTK corrections. The Q:% indicates the percentage of packets being received, and the A: indicates the age of the corrections.
