  • Page 1 Installation Guide ® RTK Bridge Integration with: ® ® Trimble CFX-750 Intuicom, Inc. 4900 Nautilus Ct. Ste. 100 Boulder, CO 80301 (303) 449-4330 www.intuicom.com...
  • Page 2 Intuicom reserves the right to make changes to this document without notice. Unless otherwise agreed to in writing, Intuicom assumes no responsibility or liability for the use of this document or for the infringement of any copyright or other proprietary right and Intuicom shall deem nothing contained in this document a warranty or guarantee.

  • Page 3: Requirements For Installation

    In order to operate an Intuicom RTK Bridge-X, you are required to have the necessary information to access and log in to the Real-Time Network. This information is entered into the RTK Bridge-X and stored in a profile. More details on setting up an RTK Bridge-X is available in the RTK Bridge-X manual.

  • Page 4: Installation Instructions

    Section 2: Installation Instructions 2 Installation Instructions Below is a diagram for the recommended installation of the Intuicom RTK Bridge-X utilizing the equipment noted above. Diagram 1 Configuration • Configure the Intuicom RTK Bridge-X to connect to GPS/GNSS Reference network and obtain CMR/CMR+ correction data stream from an appropriate single reference station, such as a VRS.
  • Page 5 • Using the Intuicom RTK Bridge-X to CFX 750 data/power cable (XRTKCAB-DD6) connect the RTK Bridge-X data port to the B Port on the CFX 750. • Power on 750 unit using power button on the upper right back of the display.
  • Page 6 Section 2: Installation Instructions • The Welcome screen appears. Select the green check box. • Select “Units” – “Meters” or “US/Imperial” then select the green arrow. • “Display Quick Start Wizard” screen appears Version 1.0 Intuicom, Inc.
  • Page 7 Section 2: Installation Instructions • Select the “Settings” icon from the Main Menu (looks like a wrench) • The “Settings” menu appears. Select “System” • Select “Advanced” Version 1.0 Intuicom, Inc.
  • Page 8 Section 2: Installation Instructions • Select “Advanced User Config” • Bypass the warning screen by selecting the green “check” icon • The “Advanced User Config” menu appears. Select “Advanced Port Setup” Version 1.0 Intuicom, Inc.
  • Page 9 • Select “Serial Port B” • Select “Input Protocol” • Select the type of correction data format that will be received from the NTRIP Caster, either “CMR” or “RTCM”. In this case, choose “CMR” and select the green check icon. Version 1.0 Intuicom, Inc.
  • Page 10 Data bits = 8 o Data parity = none o Stop bits = 1. • Then, using the yellow “back” arrow, return to the main “Settings” screen. • From the “Settings screen, select “GPS” • Now select “GPS Setup” Version 1.0 Intuicom, Inc.
  • Page 11 Section 2: Installation Instructions • “GPS Correction Source” screen appears. Verify that “RTK” is selected, then select the green forward arrow • “Correction Delivery” screen appears. Select “Generic CMR Radio”, then select the green forward arrow Version 1.0 Intuicom, Inc.
  • Page 12 Accuracy”). When finished, select the green check icon • This should return to the “GPS” screen. From here, select the yellow arrow “back” arrow to return to the “Main” screen (tractor/arrow icon centered in green field, icons along the left and right borders) Version 1.0 Intuicom, Inc.
  • Page 13 GPS data. From this screen, verify the GPS Status is “RTK” • Configuration is now complete. If it is desired to send GPS data from the Trimble® CFX/Case IH FM-750 to the RTK Bridge-X to send to the network, then proceed to Section 2.2. Version 1.0...
  • Page 14 It may be desired to send the corrected position of the receiver to the network in order to view the position quality on the network. The RTK Bridge-X can be configured to accept a GGA position on the serial port and use that position to send to the network. To be able to send the GGA position from the receiver: •...
  • Page 15 • Verify GGA is set to 1 Hz, then proceed to next screen. • Verify the NMEA GGA output decimal places is set to “8” – this should be the default setting. • Use the yellow back arrows to return to the Main screen Version 1.0 Intuicom, Inc.
  • Page 16 • Verify GPS Status is “RTK” • Configuration is now complete. You should be sending GPS/GNSS positioning data from the Trimble® CFX/Case IH FM-750 to the Intuicom RTK Bridge–X. For Technical Support of the RTK Bridge-X, Intuicom recommends “Intuicom Remote Support”, please contact Intuicom for details on this real- time support program.
