Intuicom RTK Bridge-X Installation Manual

Integration with: ag leader geosteer
Hide thumbs Also See for RTK Bridge-X:

Advertisement

Quick Links

Download this manual See also: Installation Manual
Installation Guide
®
RTK Bridge
-X
Integration with:
®
®
Ag Leader
GeoSteer
Intuicom, Inc.
4900 Nautilus Ct. Ste. 100
Boulder, CO 80301
(303) 449-4330
www.intuicom.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the RTK Bridge-X and is the answer not in the manual?

Questions and answers

Related Manuals for Intuicom RTK Bridge-X

Summary of Contents for Intuicom RTK Bridge-X

  • Page 1 Installation Guide ® RTK Bridge Integration with: ® ® Ag Leader GeoSteer Intuicom, Inc. 4900 Nautilus Ct. Ste. 100 Boulder, CO 80301 (303) 449-4330 www.intuicom.com...
  • Page 2 Intuicom reserves the right to make changes to this document without notice. Unless otherwise agreed to in writing, Intuicom assumes no responsibility or liability for the use of this document or for the infringement of any copyright or other proprietary right and Intuicom shall deem nothing contained in this document a warranty or guarantee.

  • Page 3: Requirements For Installation

    GPS/GNSS reference network. The intended audience for this document is a dealer or integrator familiar with the Ag Leader GeoSteer and generally familiar with the Intuicom RTK Bridge-X. The Intuicom RTK Bridge-X User Guide covers the steps necessary for its configuration.

  • Page 4: Installation Instructions

    Section 2: Installation Instructions 2 Installation Instructions Below is the Installation Diagram for the recommended installation of the Intuicom RTK Bridge–X utilizing the equipment noted above. Diagram 1 Configuration • Configure the Intuicom RTK Bridge–X to connect to GPS/GNSS Reference network and obtain CMR/CMR+ correction data stream from an appropriate single reference station, or as a VRS.
  • Page 5 • Connect the SAE power connector to the supplied DC power adapter which is connected to Battery power. • The RTK Bridge-X should be configured to receive the GPS position from the data port. In the Profiles page, in the profile that is to be used, under GPS Source, select Serial.
  • Page 6 Section 2: Installation Instructions • Configure the GeoSteer according to the following screens: From the Integra Home Screen – Press the wrench button: • Integra Setup – Press the wrench next to “GeoSteer Steering”: Version 1.0 Intuicom, Inc.
  • Page 7 Section 2: Installation Instructions • GeoSteer Steering – Press the “GPS” button and then “RTK”: • RTK Connection Type – Set to “External Radio” – Press the back arrow to return to GPS setup: Version 1.0 Intuicom, Inc.
  • Page 8 • GPS Setup – Press the “NMEA Out” button – set GGA to 1 Hz – press back arrow to go to GPS Setup or press the “Port A Configuration” to access Baud Rate configuration: • GPS Setup–Port A Configuration–Baud Rate Setup–Press the back arrow to return to GPS setup: Version 1.0 Intuicom, Inc.
  • Page 9 Section 2: Installation Instructions • GPS Setup – Press the “Precision Settings” button to change the Precision Mode. “Flex High” or “RTK only” are recommended for best accuracy: • Diagnostics – Under RTK button in GPS Setup: Version 1.0 Intuicom, Inc.
  • Page 10 • Diagnostics – Under RTK button in GPS Setup: • Diagnostics – Under RTK button in GPS Setup: • The GeoSteer should now be configured to send the GGA string to the RTK Bridge–X and receive an RTK correction stream. Version 1.0 Intuicom, Inc.
  • Page 11 Section 2: Installation Instructions For Technical Support of the RTK Bridge-X, Intuicom recommends “Intuicom Remote Support”, please contact Intuicom for details on this real- time support program. For general technical support, please contact us at support@intuicom.com call us at 303.449.4330.
