HITACHI INVERTER
J300 SERIES

INSTRUCTION MANUAL

Three phase input 200/400V class
J300 U
: USA version
After reading this manual, keep it at hand for future reference.
NB506XC
Hitachi, Ltd.
Tokyo Japan
CTi Automation - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.ctiautomation.net - Email: info@ctiautomation.net

Advertisement

Troubleshooting

   Summary of Contents for Hitachi J300 Series

  • Page 1: Instruction Manual

    HITACHI INVERTER J300 SERIES INSTRUCTION MANUAL Three phase input 200/400V class J300 U : USA version After reading this manual, keep it at hand for future reference. NB506XC Hitachi, Ltd. Tokyo Japan CTi Automation - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.ctiautomation.net - Email: info@ctiautomation.net...

  • Page 2

    SAFETY For the Best Results with J300 Series inverter, read this manual and all of the warning sign attached to the inverter carefully before installing and operating it, and follow the instructions exactly. Keep this manual handy for your quick reference.

  • Page 3

    Hitachi, Ltd. CAUTION: Be sure to connect a motor thermal switch or overload device to the J300 series controller to assure that the inverter will shut down in the event of an overload or an overheated motor.

  • Page 4

    NOTE : POLLUTION DEGREE 2 The inverter must be used in environment of the degree 2. Typical constructions that reduce the possibility of conductive pollution are; 1) The use of an un-ventilated enclosure 2) The use of a filtered ventilated enclosure when the ventilation is fan forced that is, ventilation is accomplished by one or more blowers within the enclosure that provide a positive intake and exhaust.

  • Page 5

    Revision History Table The Date Operation Revision Contents of Issue Manual No. Page iii : Pollution degree Aug. 1997 NB506XA Page 2-1 : Description of inverter model Page4-2 : Change of note Page 5-8, 5-9 : Addition of 750 to 1100H Page 5-10 : Terminal description Page 11-1,11-2,11-3 : addition of 750 to 1100H Page iii : Enclosure size...

  • Page 6: Table Of Contents

    TABLE OF CONTENTS Page SAFETY PRECAUTIONS ..................INSPECTION UPON UNPACKING ................ APPEARANCE AND NAMES OF PARTS ............. INSTALLATION ......................WIRING ......................... OPERATION ......................... OPERATION OF THE DIGITAL OPERATOR ............PROTECTION FUNCTIONS ..................TROUBLESHOOTING ....................MAINTENANCE AND INSPECTION ..............10-1 STANDARD SPECIFICATIONS ................11-1 FUNCTIONS WHEN USING THE OPTIONAL REMOTE OPERATOR ..

  • Page 7: Safety Precautions

    1. SAFETY PRECAUTIONS Installation CAUTION Be sure to install the unit on flame resistant material such as metal..... p. 4-1 Otherwise, there is a danger of fire. Be sure not to place anything inflammable in the vicinity.... p. 4-1 Otherwise, there is a danger of fire.

  • Page 8: Operation

    CAUTION Make sure that the input voltage is: .... p. 5-2 Three phase 200 to 220 V/50 Hz, 200 to 230 V/60 Hz Three phase 380 to 415 V/50 Hz, 400 to 460 V/60 Hz .... p. 5-2 Be sure not to input a single phase to a 3 phase type. Otherwise, there is a danger of fire.

  • Page 9

    CAUTION .... p. 5-4 External or remote over load protection required, if multiple motors to be connected. For models J300-450LFU and -550LFU only , connect to branch circuit protected at maximum 300% of output current rating. Suitable for use on a circuit capable of delivering not more than 10,000 rms symmetrical amperes,*** volts maximum, (where *** = input voltage) ....

  • Page 10

    Control and operation WARNING .... p. 6-1 Be sure to turn on the input power supply after mounting the surface cover. While being energized, be sure not to remove the cover. Otherwise, there is a danger of electric shock..... p. 6-1 Be sure not to operate the switches with wet hands.

  • Page 11: Maintenance And Inspection

    CAUTION .... p. 6-2 Radiating fin and discharging resistor will have high temperature. Be sure not to touch them. Otherwise, there is a danger of getting burned..... p. 6-2 Low to high speed operation of the inverter can be easily set. Be sure to operate it after checking the tolerance of the motor and machine.

  • Page 12

    CAUTION When removing connectors, never pull the wires. (Wires for cooling ... p. 10-1 fan and thermal relay) Otherwise, there is a danger of fire due to wire breakage and/or injury. Appendix WARNING ... p. A-15 When the inverter stops due to a trip with retry mode selected, the motor restarts suddenly.

  • Page 13

    Others WARNING Never modify the unit. Otherwise, there is a danger of electric shock and/or injury. CAUTION Withstand voltage tests and insulation resistance tests (megger tests) are executed before the units are shipped, so that there is no need to conduct these tests before operation.

  • Page 14

    CAUTION Do not insert leading power factor capacitors or surge absorbers between the output terminals of the inverter and the motor. Earth Surge absorber leakage breaker (L1) (L2) (L3) (T1) (T2) (T3) Power Motor supply Leading power factor capacitor Be sure to ground the grounding terminal, When inspecting the unit, after turning the power supply off be sure to wait unitl the CHARGE lamp beside the control terminal is off before opening the cover.

  • Page 15

    CAUTION EMI filter Inverter Noise Power Motor Motor L1(L1) (T1) source L2(L2) (T2) Power source L3(L3) (T3) Inverter Terminal filter Ground the grounding frame. Piping Noise (to be grounded) or shielded wire Completely ground the shield made of metal screen, enclosed panel, etc. with as short a wire as possible.

  • Page 16: Inspection Upon Unpacking

    Production year Production number DATE 1995 MFG. NO. J300U-055H251L and factory control symbol NE15390 Hitachi, Ltd. Made in Japan Contents of Specifications Label If you discover any problems, contact your sales agent immediately. Description of Inverter Model J300 Version number...

  • Page 17: Appearance And Names Of Parts

    3. APPEARANCE AND NAMES OF PARTS Names of Parts Blind cover Front cover A set screw Charge lamp (LED) Control circuit Digital Main circuit terminals operator terminals Wiring holes Cover Case CTi Automation - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.ctiautomation.net - Email: info@ctiautomation.net...

  • Page 18

    4. INSTALLATION CAUTION Be sure to install the unit on flame resistant material such as metal. Otherwise, there is a danger of fire. Be sure not to place anything inflammable in the vicinity. Otherwise, there is a danger of fire. Be sure not to let the foreign matter enter such as cut wire refuse, spatter from welding, iron refuse, wire, dust, etc.

  • Page 19

    For cooling purposes, be sure that the inverter is installed vertically. In addition, be sure that it is separated from other components and walls. If foreign matter is introduced into the interior of the inverter, this may cause malfunctions, so make sure that no foreign matter can enter it. Flow of air 10 cm or more (30cm or more)

  • Page 20

    Precaution for installation and wiring When executing the wiring work or another work, attach a cover on the vent hole (slit) on the top of the inverter to prevent wire chips, weld spatters, iron scraps, or dust from falling into the inverter. 15 cm or more Cover (a nonflammable Vent hole...

  • Page 21

    5. WIRING WARNING * Be sure to ground the unit. Otherwise, there is a danger of electric shock and/or fire. * Wiring work shall be carried out by electrical experts. Otherwise, there is a danger of electric shock and/or fire. * Implement wiring after checking that the power supply is off.

  • Page 22

    CAUTION * Make sure that the input voltage is: Three phase 200 to 220 V/50 Hz, 200 to 230 V/60 Hz Three phase 380 to 415 V/50 Hz, 400 to 460 V/60 Hz * Be sure not to input a single phase to a 3 phase type. Otherwise, there is a danger of fire.

  • Page 23

    The terminal board will be exposed when the front cover or terminal cover (450L/HF, 550L/HF) is removed. Wire the inverter in this state. Wiring the Power Supply and Motor (L1) (L2) (L3) (RB) (T1) (T2) (T3) (PE) (PE) MOTOR Dynamic braking resistor Braking Units...

  • Page 24

    NOTE 3: Be sure that the specified grounding is carried out. Be sure to separate the unit’s grounding pole from those of other heavy electric machinery, and avoid using common grounding poles. If multiple inverters are used, make sure that the grounding connections do not create a loop.

  • Page 25

    Wiring of Control Circuit Terminals SINK TYPE wiring (Factory settings) FM CM1 PLC P24 FW L CM2 12 AL2 AL1 AL0 Fault alarm Frequency setting Input intelligent terminal (500 Ω to 2 kΩ) For output Intelligent terminal Current input 27 VDC 50 mA DC 4 to 20 mA 50 mA max Frequency meter...

  • Page 26

    Insulate No grounding necessary Connect FG (frame ground) of the inverter. NOTE 3: When the frequency setting signal is turned on and off with a contact, use a relay which will not cause contact malfunctions, even with the extremely weak currents and voltages, such as crossbar twin contacts, etc.

  • Page 27

    Note: Make sure of the short-circuit bar or wire Note: Make sure of the short-circuit bar or wire between the terminals PLC and P24. between the terminals CM1 and PLC. J300 series J300 series 24V DC 24V DC Inverter...

  • Page 28

    Wiring Equipment, Options (EMI filter, etc.) (200V class) Standard equipment Applicable equipment Wiring (AWG or Kcmil) Power Signal Signal Earth leakage Electro- Constant torqe Variable torqe Inverter lines lines lines breaker (ELB) magnetic Power supply Power Power Motor Motor model External contactor FM,CM1,PCL P24,AL0,AL1...

  • Page 29

    Motor NOTE 1: The applicable equipment is for Hitachi standard four pole squirrel-cage motor NOTE 2: Be sure to consider the capacity of the circuit breaker to be used. NOTE 3: Be sure to use bigger wires for power lines if the distance exceeds 20m.

  • Page 30

    Width Terminal (1) Main circuit terminal Screw Width Terminal layout Type diameter (mm) 055, 075LF (L1) (RB) (PE) (L2) (L3) (Ð) (T1) (T1) (T1) (PE) 055,075HF 011, 150LF 17.5 011, 150HF 220 to 370LF (L1) (PE) (L2) (L3) (Ð) (T1) (T1) (T1) (PE)

  • Page 31

    Control circuit Terminal Standard setting of Remarks Terminal description and function symbol intelligent terminal Frequency monitor Dry contact Close: ON (run) Common for monitor Open: OFF (stop) Common terminal for the external power Min. ON time: source of the sequencer (PLC) 20 ms or more Internal power source for the frequency monitor and intelligent input terminal...

  • Page 32: Control Circuit Terminals

    Control Circuit Terminals Terminal symbol Terminal name Description Monitor terminal Analog: Output frequency, current, torque Digital: Output frequency x frequency converted value (Set in the remote operator monitor mode), max. pulse: 3.6 kHz Common terminal 1 Common terminal for the monitor terminal Internal interface common Common terminal for the external power source of the sequencer Input signal power source...

  • Page 33

    Terminal symbol Terminal name Description Frequency command power • Initialization of a voltage signal by an external command terminal is between 0 and 10 VDC. (Switching from 0 to 5V is executed by A48.) When inputting 4 - 20 mA, turn the input terminal at Frequency command H O OI L H O OI L...

  • Page 34

    Terminal Connection Diagram Power supply Inverter (T1) U R (L1) Three phase S (L2) (T2) V Motor power supply (T3) W T (L3) 24 VDC (+) P Dynamic braking resistor 055, 075LF: RB1,RB2 or RB3 055, 075HF: RB2, two each in series. Fault alarm signal (Normal: AL0-AL1 ON) 10 VDC...

  • Page 35

    6. OPERATION Before Starting Operation Prior to the test run, check the following. WARNING Be sure to turn on the input power supply after mounting the surface cover. While being energized, be sure not to remove the cover. Otherwise, there is a danger of electric shock. Be sure not to operate the switches with wet hands.

  • Page 36

    CAUTION Radiating fin and discharging resistor will have high temperature. Be sure not to touch them. Otherwise, there is a danger of getting burned. Low to high speed operation of the inverter can be easily set. Be sure to operate it after checking the tolerance of the motor and machine.

  • Page 37

    Test Run CAUTION Check the following before and during the test run. Otherwise, there is a danger of machine breakage. • Was the direction of the motor correct? • Was the inverter tripped during acceleration or deceleration? • Were the SPEED (rpm) and frequency meter correct? •...

  • Page 38

    Operating with digital operator: Runnign from external command: Procedure (1) Turn on ELB to supply power to the inverter. Make sure that the POWER LED on the digital operator turns ON. (2) Press the key once to display FUNC (3) Press of the digital operator four times to display (4) Press the key and then press the...

  • Page 39

    • The failure alarm signal is generated from the terminal AL0 and AL1 when a failure hap- pens. At this time the contents of the failure are displayed on the digital operator. • Whether the alarm terminal output is to be turned on or off during normal run can be selected by the extension function The alarm output terminals at initial setting are as follows (1).

  • Page 40

    Resetting (Any one of A, B and C is possible) A) Turn control terminal 1 on. (In the initialization at factory before ship- CM1 PLC ment, intelligent input terminal 1 is allocated to the reset RS terminal.) B) Press on the digital STOP/RESET When the internal interface power source P24-CM1 is used (Source type wiring)

  • Page 41: Operation Of The Digital Operator

    7. OPERATION OF THE DIGITAL OPERATOR The standard type digital operator is modified so as to be used easily by minimizing key opera- tions. Data can be set simply. Names of Parts POWER Lamp Monitor (LED display) Power lamp of control circuit This display shows frequency, motor current, motor revolution speed, and...

  • Page 42

    Key Description Data display The key are used to select the code and change the data. When Code display key is pressed once, the monitor mode is displayed UP/DOWN key first and then are one by one. If the •••• key is pressed once again when is displayed, the display is returned to...

  • Page 43

    Explanation of Screen Display • When the inverter is turned on, the latest display appears. However, when the display unit for data of the commands F2 to F14 is turned off, the commands (F2 to F14) are displayed. (d10 and d11 excluded) •...

  • Page 44

    Transition of Each Code <Monitor mode> To extension function code setting <Extension function mode> Output frequency monitor Reduced voltage soft Control method setting start setting Motor revolution speed monitor Running mode Motor capacity setting selection Output current Jogging frequency Motor poles setting monitor setting Speed control response...

  • Page 45

    Digital Operator Initialization List (1) Monitor mode, function mode • The standard set value of each code number is displayed. • The extension functions shown on page 7-6 can be set by the extension function setting function. Screen display Settable Initial Display for 2nd...

  • Page 46

    (2) Extension function mode • Each function name and settable range to the extension function mode are shown below. • Set the extension function code to be changed by Screen display Settable Display Externsion function name Remarks Settable Code order value during Setting range...

  • Page 47

    Explanation of Modes (1) Monitor mode contents Monitor mode Contents and display contents The frequency outputted by the inverter is monitored. The display is as shown below. Display when stopped A frequency between 0.01 Hz Output and 9.99 Hz is displayed in units frequency of 0.01 Hz.

  • Page 48

    Monitor mode Contents and display contents The product of the value of frequency converted value setting (A47) and that of output frequency (d0) is displayed on the monitor. FUNC 0.0 to 9.99 Frequency 10.00 to 99.99 FUNC converted value monitor 100.00 to 999.99 1000.00 to 9999.99 10000.00 to 39960.00...

  • Page 49

    (2) Function mode Monitor mode Contents and display contents Methods for setting the output frequency are as follows: 1. Digital operator Refer to this setting. 2. Control circuit terminal Refer to this setting. (multistage speed command) 3. External analog input Refer to page 6-2.

  • Page 50

    Monitor mode Contents and display contents Set the motor direction. Set the motor direction when running by pressing the key. NOTE: The setting during run is impossible. FUNC Initial set value Running Forward run direction Switching can be done by pressing FUNC key.

  • Page 51

    Monitor mode Contents and display contents These commands set and display Acc. time and Dec. time Setting range Period FUNC FUNC Initial value 0.01 to 9.99s Every 0.01s Accelera- 10.0 to 99.9s Every 0.1s tion time 1 100 to 999s Every 1s and 2 Decelera-...

  • Page 52

    Monitor mode Contents and display contents Switching the run command and frequency command setting modes Set the run command and frequency command sending destinations. The standard specification selection range is from 00 to 03. Set value Run command to Frequency command to command- Digital operator Digital operator...

  • Page 53

    Monitor mode Contents and display contents Adjust the analog meter connected to the frequency monitor terminal. (Initial setting of the [FM] terminal: Analog frequency monitor) Sink type wiring Refer to page 5-3 When operation starts, t/T output between FM and CM1 terminals is proportional to the output data.

  • Page 54

    Returning to the initialization (State set at factory before shipment) When returning the equipment to the initial state set at factory before shipment for some reason, follow the following procedure. 1) Allocate STN (set value ) to one of the input intelligent terminals. (Use in the extension function mode to set the intelligent terminals.) (However, cannot be used since resetting RS is initially set.)

  • Page 55

    (3) Extension function mode contents Extension function Contents and display code Set the control method. Select one of the following control codes. FUNC Initial value V/f control (VC) Control Constant torque characteristics method FUNC setting V/f control (VP1) Reduced torque characteristics, 1.5 power NOTE : set torque boost in 70 to 90.

  • Page 56

    Extension function Contents and display code Set the response speed (ASR system gain) between the inverter and motor. When increasing or decreasing the current motor response speed, adjust the ASR system gain. When the set value is decreased, the response speed is increased. When the set value is increased, the response speed is decreased.

  • Page 57

    Extension function Contents and display code Set the limits of frequency setting within the start frequency adjustment range and maximum frequency setting range. When a value beyond the limits is inputted from the operator, it will not be stored. Even if a value beyond the limits is inputted as external analog input, the set value will not be changed.

  • Page 58

    Extension function Contents and display code Set the switching frequency of the power module. Carrier frequency initial value (NOTE 1) FUNC FUNC initial value Initial value model type 055 to 150 L/HF 16 kHz 8 kHz Carrier frequency 220 L/HF 6 kHz 12 kHz setting...

  • Page 59

    Extension function Contents and display code Set the electronic thermal level. Set the thermal level in accordance with the rated current of the motor in units of 1 (%). Motor rated current Adjustment level = Inverter rated current Electronic Time(s) 120% thermal Setting method...

  • Page 60

    Extension function Contents and display code   Set the frequency for starting output for an external frequency command (0 to 10 V, 0 to 5 V, 4 to 20 mA) and the frequency for ending output. When 0 Hz is set, this function will be canceled. NOTE 1: The standard setting is 0 Hz.

  • Page 61

    Extension function Contents and display code Set the usage ratio (%) for 100 seconds of BRD. When the BRD operation exceeds this setting, NOTE 1: The internal BRD circuit is not mounted in an inverter other than the types 055L/HF, the operation will be stopped.

  • Page 62

    Extension function Contents and display code Select the output monitors signal at the control circuit terminal FM from the table indicated below. Set value Function Setting method Analog output frequency monitor Initial value Monitor Analog current monitor signal FUNC FUNC selection Analog torque monitor (Note) Digital output frequency monitor...

  • Page 63

    Extension function Contents and display code When selecting the frequency arrival signal at the output terminal, select the arrival signal output method. Output Setting method 0.5Hz setting frequency (Hz) 1.5Hz Frequency FUNC FUNC arrival signal output Initial value 60 ms Time Arrival method...

  • Page 64

    Extension function Contents and display code Adjust reduced voltage start. NOTE: How to set FUNC FUNC Initial value There is no reduced voltage. The rush current at the start of the inverter is ¥ Reduced increased but the motor reaction time is ¥...

  • Page 65

    Extension function Contents and display code Set the base frequency and maximum frequency. Setting example Setting method 100% 100% FUNC FUNC Base Initial value frequency 60 Hz 60 Hz 120 Hz setting (A62) base frequency (A62) base frequency: 60 Hz and (A63) maximum (A63) maximum frequency: Maximum...

  • Page 66

    Extension function Contents and display code         Possible to select a performance of a release timing of alarm signal when giving reset signal from [RS] terminal Set value Performance FUNC FUNC Reset signal Initial value from [RS] terminal...

  • Page 67

    (For details of auto tuning, see Appendix 1.) Select the motor constant used for sensorless vectror control (SLV). Set value Data used Initial Motor FUNC Old Hitachi general- FUNC value data purpose motor data selection New Hitachi general Initial value purpose motor data (ÒThe MotorÓ)

  • Page 68

    Extension function Contents and display code Unusable Ro-T- option selection 7-28 CTi Automation - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.ctiautomation.net - Email: info@ctiautomation.net...

  • Page 69

    Extension function Contents and display code A terminal function is allocated to each of the input intelligent terminals 1 to 8. When using a function other than the standard set functions or changing the terminal order, set the function for each terminal. The minimum input signal acceptance time of the input intelligent terminals is about 20 ms.

  • Page 70

    Extension function Contents and display code A terminal function is allocated to each of the output intelligent terminals 11 and 12. When using a function other than the standard set functions or changing the terminal order, set the function for each terminal.

  • Page 71

    Extension function Contents and display code The input intelligent terminals 4 to 1 can be changed individually to the a contact or b contact specification. Select the set value by pressing the keys by combining the contacts a and b with reference to the table indicated below. Example: When the set value is A: Contact a: Input terminals 3, 1 Input...

  • Page 72: Protection Functions

    8. PROTECTION FUNCTIONS The J300 series inverters are equipped with protection functions against overcurrent, overvoltage, and undervoltage which protect the inverter. If the protection functions are engaged, the output is shut down, motor runs free and holds that condition until it is reset.

  • Page 73

    Description Display Contents Option 1 Optional An error occurs in the optional connection (connector, etc.). connection error Option 2 Option 1 Optional An error message outputted from the optional PCB NOTE 5 PCB error Option 2 Phase failure When a phase failure is detected on the receiving side {R(L1), S(L2), T(L3)} protection error of the inverter, the output is cut off.

  • Page 74: Troubleshooting

    9. TROUBLESHOOTING Error Messages and Diagnosis When the inverter goes wrong, it operates as indicated below. Find the cause and take contermeasures. Error Messages and Diagnosis Symptom Display on the digital operator Cause Check Countermeasure (display on the LCD of the (explanation remote operator) of message)

  • Page 75

    Symptom Display on the digital operator Cause Check Countermeasure (display on the LCD of the (explanation remote operator) of message) E 0 6 The regenerative Check the braking resistor • Set a longer deceleration braking time is longer time. use ratio set in A 38 . ( O L .

  • Page 76

    Symptom Display on the digital operator Cause Check Countermeasure (display on the LCD of the (explanation remote operator) of message) Ground fault on the Check the wiring between the Correct the portions having E 1 4 output side of the inverter and motor and also a ground fault.

  • Page 77

    Symptom Display on the digital operator Cause Check Countermeasure (display on the LCD of the (explanation remote operator) of message) E 3 3 (NOTE 1) Check whether the speed was Set a longer acceleration Failure detected by a increased rapidly. time.

  • Page 78

    Symptom Display on the digital operator Cause Check Countermeasure (display on the LCD of the (explanation remote operator) of message) — — — Check for an overload. Lower the load ratio. Check whether the thermal Set the thermal relay to an relay is set to an appropriate appropriate value.

  • Page 79: Trouble Shooting

    Trouble shooting Symptom Probable cause Countermeasure The inverter • Is power being supplied to terminals • Check terminals R(L1), S(L2), T(L3), U(T1), motor outputs R(L1), S(L2) and T(L3)? V(T2), and W(T3). will not U(T1), V(T2) If it is, the POWER lamp should be on. •...

  • Page 80

    Symptom Probable cause Countermeasure The rpm After checking the wiring of Replace the frequency setter. of the the frequency setter, the rpm still motor does not increase when the setter will not is turned. increase. Are terminals 7 and CM1, terminal 6 Turn off terminal 7 and 6.

  • Page 81

    Symptom Probable cause Countermeasure Overload Is the torque boost too high ? Decrease the torque boost. (Electronic Reset the electronic thermal characteristics Do the electronic thermal characteristics thermal and level. match the set characteristics of the trip) motor ? (Low frequency zone) The input...

  • Page 82: Maintenance And Inspection

    10. MAINTENANCE AND INSPECTION 10.1 Maintenance and Inspection Precautions WARNING * Be sure to turn off the power supply during maintenance and inspection. * After the power supply has been turned off, you must always wait 10 minutes so that DC bus capacitors can discharge then start maintenance and inspection after the CHARGE lamp on the printed-circuit board has gone out.

  • Page 83

    Conduct these tests by short-circuiting the terminals as shown below, and by following the conditions described. • In regard to insulation resistance tests, measure the terminals below and the grounding at 500 VDC, and make sure that 5 Megohms or greater is indicated. •...

  • Page 84

    Daily Inspection and Periodic Inspection (1/3) Inspection cycle Standard Inspection Inspection item Inspection content Inspection method Criteria Instruments replacement location Daily Periodic period Overall Ambient Check ambient temperature, Ambient temperature Thermometer environment humidity, dust, corrosive between -10 to +50˚C; gases, oil mist, etc. no icing.

  • Page 85

    Daily Inspection and Periodic Inspection (2/3) Inspection cycle Standard Inspection Inspection item Inspection content Inspection method Criteria Instruments replacement location period Regularly Periodic Terminal board No damage. Visual inspection No abnormalities. Main circuit Smoothing (1) Check for leaking Visual inspection of No abnormalities in (1) and 5 years capacitor...

  • Page 86

    Daily Inspection and Periodic Inspection (3/3) Standard Inspection cycle Inspection Inspection item Inspection content Inspection method Criteria Instruments replacement location Regularly Periodic period Control Operation check (1) Check the balance of the (1) Measure the (1) Within 2% voltage circuit output voltage of voltage between difference between...

  • Page 87

    10.3 Measurement Method for I/O Voltage, Current, and Power General measuring instruments for I/O voltage, current, and power are indicated below. The voltage to be measured is the fundamental wave effective voltage and the power to be meas- ured is the total effective value. U(T1) (L1) General...

  • Page 88

    Measurement method for output voltage (L1) (T1) (L2) (T2) Motor (L3) (T3) Diode 600 V 0.1 A min. (200 V class) 1000 V 0.1 A min. (400 V class) 220 kΩ 300 V (200 V class) Fundamental wave effective value: 600 V (400 V class) VAC=1.1×VDC moving-coil type...

  • Page 89: Standard Specifications

    11. STANDARD SPECIFICATIONS 11.1 Common Standarsd Specifications Item Description Input voltage 200 V class 400 V class 2200 1100 1320 1600 Model Name (Type) Semienclosed Semienclosed Open type (IP00) Enclosure (NOTE 1) Open type (IP00) type (IP20) type (IP20) Three-phase (3 wires), 380 to 415 or Three-phase (3 wires), 200 to 220 or Rated AC input power supply (V) 400 to 460 V±10%, 50 or 60 Hz±5%...

  • Page 90

    Item Description Input voltage 200 V class 400 V class 1100 1320 2200 1600 Model Name (Type) Fault alarm contact (AL0-AL1) OFF when an inverter alarm occurs AVR function, data batch setting, V/F characteristic switching, curve acceleration and deceleration, upper and lower limiters, 8-stage speed, Other characteristics start frequency fine adjustment, trip history monitor (up to three times stored), fuzzeleration and deceleration, autotuning, etc.

  • Page 91

    Humidity 20 to 90% RH NOTE 1: The applicable motor is a Hitachi standard four-pole motor. When using another motor, make sure that the rated motor current does not exceed the rated inverter current. NOTE 2: Applicable motor rating at variable torque is valid with the condition that output current does not exceed the rating at variable torque.

  • Page 92: Functions When Using The Optional Remote Operator

    12. FUNCTIONS WHEN USING THE OPTIONAL REMOTE OPERATOR 12.1 Connecting the remote operator Be sure to turn the power supply off when connecting the connector. High performance remote operator (HOP) High performance copy unit (HRW) Digital operator Remote operator (DOP) Copy unit (DRW) (1) Insert the connector straight into the remote operator and inverter unit printed-circuit board.

  • Page 93

    Set as below (When setting status do not match model, the correct function can not be attained.) Switch Model J300 series (Same as VWA, J100) 12-2 CTi Automation - Phone: 800.894.0412 - Fax: 208.368.0415 - Web: www.ctiautomation.net - Email: info@ctiautomation.net...

  • Page 94: Monitor Mode

    12.2 Monitor mode : Setting can be changed Monitor mode list when the remote operator (DOP) and copy unit (DRW) are used during operation • Monitor mode initial values and display contents : Setting can not be changed Initial display contents, initialization, and change ranges are displayed during operation in the table indicated below.

  • Page 95

    Setting and Display Setting change are Monitor name Display content Initial value Remarks sequence range possible? Manual torque boost V-Boost F 10.0% 10.0% 0 to 50.0 frequency adjustment Output voltage 100% V-Gain 100% 20 to 100 gain adjustment Jogging frequency A trip occurs easily Jogging 1.00 Hz...

  • Page 96: Function Mode

    AUT/NRT is set, the constant autotuning measurement (NOTE 1) operation is executed. Motor data AUX DATA NOR: Old Hitachi • The autotuning motor data selection general purpose before starting autotuning TMO: New measurement is data Hitachi general equivalent to NOR.

  • Page 97

    (Function mode 1) (Function mode 2) Display Setting, change Function Function Initialization display Initialization Setting contents sequence contents name contents F-05 Motor AUX M 123.60 mH Rated capacity 0 to 655.35 • Primary self inductance per Motor M setting of each inverter phase.

  • Page 98

    (Function mode 1) (Function mode 2) Display Setting, change Function Function Initialization display Initialization Setting contents sequence contents name contents F-08 Accelera- Fsp F 0000.0 Hz 0 Hz 0 to 400.0 • The frequency at which the Accelera- tion stop acceleration operation is tion halt frequency...

  • Page 99

    (Function mode 1) (Function mode 2) Display Setting, change Function Function Initialization display Initialization Setting contents sequence contents name contents F-20 DC braking DCB SW ON/OFF • DC braking selection ON: DC braking available injection OFF: DC braking unavailable braking DC braking DCB KIND LVL/EDG •...

  • Page 100

    (Function mode 1) (Function mode 2) Display Setting, change Function Function Initialization display Initialization Setting contents sequence contents name contents F-23 Electronic E-THM A1 8.5A Rated capacity of 0 to 600.0 A Electronic thermal each inverter thermal characteristic (NOTE 2) free setting current (1) Electronic E-THM F1 0000 Hz...

  • Page 101

    (Function mode 1) (Function mode 2) Display Setting, change Function Function Initialization display Initialization Setting contents sequence contents name contents F-26 Frequency LIMIT L 0000.0 Hz 0 Hz 0 to 120.0 The lower limit of the frequency Frequency lower limiter (400) Hz to be set is set.

  • Page 102

    (Function mode 1) (Function mode 2) Display Setting, change Function Function Initialization display Initialization Setting contents sequence contents name contents Frequency IN F-SAMP 1 to 8 command sampling frequency setting F-32 Arrival ARV PTN CST/PAT/ANY CST: Output at constant Frequency signal output frequency arrival arrival pattern...

  • Page 103

    (Function mode 1) (Function mode 2) Display Setting, change Function Function Initialization display Initialization Setting contents sequence contents name contents F-34 Input IN-TM 6 USP and 17 Intelligent terminal 6 Power-ON other terminals terminal setting restart input preventionl terminal Input IN-TM 7 CF1 and 17 setting...

  • Page 104

    (Function mode 1) (Function mode 2) Display Setting, change Function Function Initialization display Initialization Setting contents sequence contents name contents F-37 Monitor MONITOR A-F/A/T/D-F • The FM terminal monitor signal signal output is selected. selection A-F: Analog frequency T: Torque monitor A: Current monitor D-F: Digital frequency F-38...

  • Page 105

    (Function mode 1) (Function mode 2) Display Setting, change Function Function Initialization display Initialization Setting contents sequence contents name contents F-41 Position PO EGRP FB/REF Effective with option board Electronic setting (J-FB) gear switching setting Numerator PO EGR-N 00001 1 to 9999 of ratio Denominator PO EGR-D...

  • Page 106

    (Function mode 1) (Function mode 2) Display Setting, change Function Function Initialization display Initialization Setting contents sequence contents name contents F-47 Main body OP-ERR1 STP/RUN Effective with option board Option operation PCB error selection for setting option PCB error 1 Main body OP-ERR2 STP/RUN...

  • Page 107: Other Displays

    12.4 Protection function display list when the remote operator is used There are protection functions for overcurrent, overvoltage, and undervoltage provided to protect the inverter. When one of the functions is performed, the output is cut off, and the motor is put into the free run state, and the status is kept until the inverter is forced to reset. Remote operator(DOP) Remote operator(DOP) copy unit(DRW)display...

  • Page 108

    12.5 Warning Error List The following warning errors are displayed on the warning monitor in the monitor mode. Check the set value. When an attempt is made to set a value larger than the set range, the set value may be rewritten as shown below. Alarm Recovery Warning error display...

  • Page 109

    12.6 Dimensions Remote operator, copy unit Dimensional drawing (Unit: mm) Remote operator (DOP-OA) Copy unit (DRW-OA) 2 - 45 2 - 45 2 - M4 2 - M4 Mounting perforation diagram Mounting perforation diagram J300 cable High performance remote operator (HOP-OJ) Copy unit (HRW-OJ) 12.5 13.5...

  • Page 110

    12.7 Copy Unit Function Operation example (Procedure to transfer the data of inverter A to B,C, and D inverters) Operation Operation result quence Set data is read out from the READ inverter A (It is stored into the Inverter A Copy unit memory.

  • Page 111

    12.8 Data to be copied by the copy unit Precautions for copying The copy units, DRW and HRW cannot copy some of parameters. For the details, see Appendix 7. Do not carry out data copy and transfer between different version (ex. J300-E1 J300-E4).

  • Page 112: Service

    13. SERVICE When inquiring about inverter trouble, please be ready to inform the distributor where you purchased your unit or the nearest service station the following . Type Purchased date Production No. (MFG. No.) Malfunction symptoms If the contents are unclear due to an old nameplate, give only the clear items. To reduce the non- operation time, it is recommended to stock a spare inverter.

  • Page 113: Appendix 1

    1 Hz can generate a torque of 150%. An Hitachi general purpose motor is given a constant which is a default value. Therefore, in every case, the characteristics will be obtained without trouble. When the characteristics cannot be obtained, measure the motor circuit constant by the autotuning function.

  • Page 114

    Autotuning start [Setting method] (1) Digital operator FUNC Display the software switch and set it to the data (01) for starting autotuning setting. When the equipment starts running after the data FUNC is set, the autotuning measurement is executed. (2) Remote operator F-05 motor constant setting is displayed.

  • Page 115

    (3) New remote operator First hierarchy Select “3 Function” in the first hierarchy. 1 Command × 2 2 Initial 3 Function 4 Option Second hierarchy Select “1 Control” in the second hierarchy. Control 2 Acc/Dec 3 Run 4 Braking Third hierarchy Select “2 Motor”...

  • Page 116

    Display when the autotuning terminates [Display in the normal state] • When the autotuning terminates normally, the following is displayed. When one of the keys is pressed, the original screen is displayed. •Digital operator Normal termination display •Remote operator Tuning END •New remote operator Function Normal termination display...

  • Page 117

    Running method by autotuning data When running the inverter using the autotuning data: 1. A-0 : The control method is set at SLV (sensorless vector control). 2. A-98 : The motor data is set on the autotuning side by the software switch. Make the above two settings.

  • Page 118

    (3) New remote operator First hierarchy Select “3 Function” in the first hierarchy. 1 Command × 2 2 Initial 3 Function 4 Option Second hierarchy Select “1 Control” in the second hierarchy. 1 Control 2 Acc/Dec 3 Run 4 Braking Third hierarchy Select “1 V/f”...

  • Page 119

    [NOTES] *1: If the desired characteristic cannot be obtained in a sensorless vector control operation with auto tuning measured data, adjust the motor constant according to the detected symptom shown below. (DOP, DRW, HOP, and HRW functions of the remote operator are needed for this adjustment.) Operation Symptom Adjustment...

  • Page 120

    Energy conservation running [Outline of the function] This is a function for automatically setting the output voltage corresponding to the load during the V/F control running and suppressing useless power. The function is effective for a load of reduced torque characteristics such as a fan and pump. Large load When the load of an induction motor is constant as shown in the...

  • Page 121

    [Setting method] (1) Digital operator Select 1 by running mode selec- tion. FUNC Running mode selection 0: Normal running 1: Energy conservation running 2: Fuzzy most suitable acceleration and FUNC deceleration running When the running starts after the data is set, the energy conservation running is performed.

  • Page 122

    (3) New remote operator First hierarchy Select “3 Function” in the first hierarchy. 1 Command × 2 2 Initial 3 Function 4 Option Second hierarchy Select “3 Run” in the second hierarchy. 1 Control × 2 2 Acc/Dec 3 Run 4 Braking Third hierarchy Select “2 Pattern”...

  • Page 123

    Fuzzy most suitable acceleration and deceleration [Outline of the function] The fuzzy most suitable acceleration and deceleration function realizes acceleration and decelera- tion characteristics using the inverter capability at its maximum under fuzzy control to eliminate troublesome setting of the acceleration and deceleration time. The acceleration time is a time for acceleration at the current specified by the overload restriction constant.

  • Page 124

    [Principle] The acceleration and deceleration ratio or acceleration and deceleration are set in accordance with the fuzzy rule from the distance to the overload restriction level and the start slopes of current and voltage. Overload restriction level Restriction angle Setting process The current grows.

  • Page 125

    [Setting method] (1) Digital operator Select 2 by running mode selec- tion. FUNC Running mode selection 0: Normal running 1: Energy conservation running 2: Fuzzy most suitable acceleration and FUNC deceleration running When the running starts after the data is set, the most suitable acceleration and deceleration running is performed.

  • Page 126

    (3) New remote operator First hierarchy Select “3 Function” in the first hierarchy. 1 Command × 2 2 Initial 3 Function 4 Option Second hierarchy Select “3 Run” in the second hierarchy. 1 Control × 2 2 Acc/Dec 3 Run 4 Braking Third hierarchy Select “2 Pattern”...

  • Page 127: Appendix 2

    Appendix 2 Instantaneous Power Failure Restart and Commercial Power Source Switching 1. Instantaneous power failure restart [Function Outline] This function allows an inverter operation to be selected according to the subject system as follows when an instantaneous power failure occurs. •...

  • Page 128

    WARNING If the retry mode is selected, do not approach the inverter unnecessarily. It will be restarted suddenly after it trips/stops. (Design the inverter so that the safety can be assured even in such a restart.) Otherwise, bodily injury will result. NOTE: Since the retry mode is selected, the equipment restarts for trips of overcurrent, overvoltage, or undervoltage.

  • Page 129

    2. Commercial power source switching Data set for commercial power source switching Set value Run command to Frequency command to Function code Set the terminal mode. Terminal Terminal Function name Terminal rating plate Set value Extension Select the CS terminal. Input terminal setting 3 function code NOTE: Allocate the commercial power source switching input terminal CS to one of the input terminal settings...

  • Page 130

    ELBC THRY R(L1) (T1)U S(L2) (T2)V T(L3) (T3)W NOTE 1: When the ELB trips due to a ground-fault, the commercial power source circuit will not operate. Therefore, when a backup is necessary, take a commercial power source circuit from the ELBC. NOTE 2: Use weak current relays for FWY, RVY, and CSY.

  • Page 131: Appendix 3

    Appendix 3 Capacitor Life Curve Ambient (˚C) temperature 12 hours Operation/day Capacitor life (year) * The ambient temperature herein means the temperature around the inverter body. If the inverter is housed in a panel, the ambient temperature corresponds to the temperature in the panel.

  • Page 132: Appendix 4

    Appendix 4 Acceleration/Deceleration Curve Constants This function can vary the curvature when the acceleration curve pattern (or deceleration curve pat- tern) is selected to S curve, U curve or RU (reverse U) curve in the function mode (F-06). If the acceleration curve pattern or deceleration curve pattern is selected, the selected pattern applies to both acceleration and deceleration.

  • Page 133

    NOTE: The setting methods shown below Operation conditions Phenomena Improvements Display, etc. apply to DOP and DRW operations. Trial running of motor The motor runs unsmoothly, 1. When V/f control or sensor-less vector only and the revolution fails to increase. control is selected The motor current pulsates.

  • Page 134

    NOTE: The setting methods shown below Operation conditions Phenomena Improvements Display, etc. apply to DOP and DRW operations. Quickly varying load When sensor-less vector control is selected Load Function mode • F-04 NOTE: Select AUT if CONTROL SLV the automatic •...

  • Page 135

    NOTE: The setting methods shown below Operation conditions Phenomena Improvements Display, etc. apply to DOP and DRW operations. Parallel motor operation Operation cannot be started at high 1. When sensor-less vector control is selected torque, since the inverter does not Function mode know the load sharing of the •...

  • Page 136: Appendix 5

    Appendix 6 Supplementaly Explanation of the Function Mode • The explanation of the function mode is displayed on the DOP or DRW type of the remote operator. As for the operating methods with other remote operators, refer to the corresponding table of the operator display.

  • Page 137: Appendix 7

    Appendix 7 List for display and data read/copy with each operators (1) Monitor mode Y: Possible N: Not possible Data read/copy Function No. with digital operator Display with Display with Monitor name value HOP, HRW DOP, DRW Alterability No. Data HRW DRW Frequency setting First setting 0.00 Hz FS0000.0...

  • Page 138

    Data read/copy Function No. with digital operator Display with Display with Monitor name HOP, HRW DOP, DRW value Alterability No. Data HRW DRW Trip cause factor 1 ERR1 # ERR1 - - - Trip frequency 1 ERR1 0.0 Hz ERR1 0.0 Hz —...

  • Page 139

    Display with HOP, HRW Display with DOP, DRW Data read/copy Function No. with digital operator Function mode value Layer Data display Data display Alterability No. Data HRW DRW Control method First setting 3-1-1 6 MODE 0: VC F-04 CONTROL VC Second setting 6 MODE 0: VC CONTROL VC...

  • Page 140

    Display with HOP, HRW Display with DOP, DRW Data read/copy Function No. with digital operator Function mode value Layer Data display Data display Alterability No. Data HRW DRW Deceleration time setting First setting 3-2-2 1 D1 30.00 s F-07 DEC 1 0030.00 s 30.0 Second setting 1 D1...

  • Page 141

    Display with HOP, HRW Display with DOP, DRW Data read/copy Function No. with digital operator Function mode value Layer Data display Data display Alterability No. Data HRW DRW Electronic thermal characteristics 3-5-1 6 F2 0 Hz F-23 E-THM F2 0000 Hz —...

  • Page 142

    Display with HOP, HRW Display with DOP, DRW Data read/copy Function No. with digital operator Function mode value Layer Data display Data display Alterability No. Data HRW DRW Input terminal 1 setting 3-6-3 1 I-1 18:RS F-34 IN-TM 1 RS Input terminal 2 setting 2 I-2 16:AT...

  • Page 143

    Display with HOP, HRW Display with DOP, DRW Data read/copy Function No. with digital operator Function mode value Layer Data display Data display Alterability No. Data HRW DRW Transmission speed selection 1 BAUD 1:600 bps F-46 COM BAUD 0600 bps —...

  • Page 144: Appendix 8

    Appendix 8 PID Function Function The PID (Proportional, Integral, Differential) control functions can apply to controlling of the air (water) amount of a fan pump, etc., as well as controlling of pressure within a fixed value. Set the reference signal according to the frequency setting method or the internal level. Set the feed-back signal according to the analog voltage input (0 to 5V or 0 to 10V) or analog current input (4 to 20 mA).

  • Page 145

    Data Setting Method (1) Digital operator Refer to of the extended funciton mode contents (pages 7-26 and 7-27). Remote operator Setting item Setting range PID IN-SEL IN The PID LVL set value is assumed as the target value. The target value depends on the frequency setting method. PID LVL 0 to 200% PID P...
