IMB200 LGA775 ATX MB User Manual
1.2

Specifications

Processor: Intel
North Bridge: Intel
South Bridge: Intel
CPU Socket: LGA775
FSB: 533/800 Mhz
L2 Cache: Integrated in CPU(Depend on CPU)
BIOS: Phoenix Award BIOS Rev.6.00
System Memory: Support Dual Channel DDR
266/333/400 memory and the maximum capacity up to
4GB.
CPU FSB DDR Type
800MHz PC3200/PC2700/PC2100
533MHz PC2700/PC2100
*Because limited of chipset, when using FSB800Mhz CPU,
PC2700 DDR (333 MHz) only supports 320 MHz.
IDE Interface: Two IDE connector and up to four devices,
Ultra DMA 100 supported
FDD Interface: Supports up to 2 drives
Serial Ports: RS232 Portx4
Parallel Ports: One parallel port with ECP/EPP/SPP
supported
VGA Controller:
Chipset Integrated VGA Controller and Supports up to
2048x1536 at 75 Hz resolution on non-interlaced CRT
monitors
Ethernet: Intel82547GI/Intel82562ET
SATA: Two Channel and support the maximum data
transfer rate could up to 150MB/s
2
®
Pentium D/Pentium4/Celeron
®
82865G
®
82801EB(ICH5)
400/333*/266MHz
333/266MHz
DDR Frequency
Introduction
