Network Interfaces - IBM BladeCenter Management Module User Manual

Table 2. User configurable management-module ports (continued)
Default port
Port name number
SSH 22
SNMP Agent 161
SNMP Traps 162
Other ports used by the management module are listed in Table 3. These ports are
fixed and can not be modified by the user.
Table 3. Fixed management-module ports
Port number (fixed) Description
25 Port used for TCP e-mail alerts
53 Port used for the UDP Domain Name Server (DNS) resolver
68 Port used for DHCP client connection using UDP
427 Port used for the UDP Service Location Protocol (SLP) connection
1044 Port used for remote disk function
1045 Port used for persistent remote disk (disk on card).
5900 Port used for the TCP VNC server applet
6090 Port used for IBM Director commands using TCP/IP
13991 Port used for IBM Director alerts using UDP
Click on View Configuration Summary to display the configuration settings for all
BladeCenter users and components.

Network Interfaces

30
BladeCenter Management Module: User's Guide
Description
Port used for the Secure Shell (SSH) command-line interface connection
Port used for SNMP get/set commands using UDP
Port used for SNMP traps using UDP
