Specifications
Output
Variable Voltage Output
Variable Current Output
Voltage Regulation
Load (10 to 100% Load)
Model DCP60
Model DCP60‐220
Current Regulation
Load (10 to 90% rated voltage)
Model DCP60
Model DCP60‐220
Ripple and Noise
Ripple and Noise (RMS) voltage 5mV
Ripple and Noise (P‐P) voltage
Current Ripple and Noise (RMS) 10mA
Input
Input Voltage
Fuse
Full Load Current
Installation category
Other
Efficiency
Switching Frequency
Tracking Over‐Voltage Protections
Transient Response Time (50‐100% load)
Power Factor Control
Cooling method
Protections
Operating %RH
Approvals
Dimensions
Weight
Altitude
Pollution degree
1 to 60VDC
0 to 10ADC
50mV
Line (90 to 130VAC Variation):
Line (170 to 264VAC Variation):
100mA
Line (90 to 130VAC Variation):
Line (170 to 264VAC Variation:
100mv
Model DCP60:
Model DCP60‐220: 220 to 240CVAC 50/60Hz
8A/250V 5x20mm (120V); 4A/250V 5x20mm (220V)
6.2A (120V); 3.25A (220V)
CAT 2
89%
65 to 85 kHz (approx.)
Power Factor correction >0.9 at optimal load
Thermostatic control fan from zero to full speed
Overload, Short Circuit by Constant Current, Output
Tracking Over Voltage, and Over Temperature
10 to 80% Relative Humidity
CE, EMC: EN 55011, 55022, LVD: EN 60950, 61010
7.9 x 3.5 x 8.5" (200 x 90 x 215mm)
5.7lbs. (2.6 kg)
up to 6561 ft. (2000m)
2
Copyright © 2013 FLIR Systems, Inc.
All rights reserved including the right of reproduction in whole or in part in any form
www.extech.com
90 to 130VAC 50/60Hz
O/P 1‐5V: set voltage +2V
O/P 5‐20V: set voltage +3V
O/P 20‐60V: set voltage +4V
1.5ms
21
20mV
20mV
50mA
50mA
DCP60‐EU‐EN V1.4 9/13
