Introduction
Congratulations on your purchase of the Extech DC Regulated Power Supply. These units are solid
state, compact, regulated supplies suitable for many applications including bench testing, field service,
hobby and telecommunication equipment use. This meter is shipped fully tested and calibrated and,
with proper use, will provide years of reliable service. . Please visit the Extech Instruments website
(www.extech.com) to check for the latest version of this User Guide. Extech Instruments is an ISO-
9001 certified company.

Specifications

Model
Display
Display Accuracy (V)
Display Accuracy (A)
Voltage Output, DC
Current Output, DC
Ripple and Noise
Line Regulation
Load Regulation
Power
Dimensions
Weight

Meter Description

1. Voltage display
2. Current display
3. Negative (-) output terminal
4. Positive (+) output terminal
5. Illuminated On/Off switch
6. Current adjustment
7. Voltage adjustment
382200
±(1.5%rdg +5D)
±(2.0%rdg + 5D)
30.0 Volts
0 – 1.00 Amp
<0.5mV/<3mA
< 0.01% + 3mV/< 0.2% + 3mA
< 0.01% + 2mV/< 0.2% + 3mA
115/230VAC (50/60Hz)
9.4 x 4.25 x 6" (240 x 108 x 154mm) (WxHxD)
4.4lbs. (2 kg)
2
382202
Dual LCD
18.0 Volts
0 – 3.00 Amps
6.6lbs. (3kg)
382200 and 382202 v3.6 5/14
