Remote Control Operation - Extech Instruments DCP60 User Manual

Remote Control Operation
There are two methods for remotely controlling current and voltage adjustments. Current must be
controlled for both methods otherwise the unit will default to CC mode.
REMOTE CONTROL – METHOD 1: Using two external DC voltage sources
Remote Socket Pin Assignment for external variable voltage source
PIN
1
2
3
4
5
6
7
8
Check the output voltage range of the power supply by varying the external voltage source.
Short circuit the main output with 10AWG wire to check the CC setting on the display while
varying the external voltage source.
REMOTE CONTROL – METHOD 2: Using two 0 to 5K Ohm variable resistors
PIN
1
2
3
4
5
6
7
8
Check the output voltage range of the power supply by adjusting the 5Kohm variable resistor.
Short circuit the main output with 10AWG wire to check the CC setting on the display while
adjusting the variable resistor.
FUNCTIONS
Internal DC +5V
Voltage adjust
Current adjust
Ground
Output OFF
N.A.
N.A.
N.A.
Remote Socket Pin Assignment for external variable resistor
FUNCTIONS
Internal DC +5V
Voltage adjust
Current adjust
Ground
Output OFF
N.A.
N.A.
N.A.
REMARKS
Lower than 50mA
0 to 5V External VDC
0 to 5V External VDC
Short to ground for OFF
REMARKS
One end of resistor
Variable leg of resistor
Variable leg of resistor
Other end of resistor
Short to ground for OFF
9 DCP60‐EU‐EN V1.4 9/13
