4. Maintenance

Periodically clean the printer external cover by wiping it with a soft cloth that has been

dampened with water. Never use abrasive cleaners or solvents to clean the printer, as

it will cause damage by these ways.

Once a week, clean the printer head by carefully wiping it with a soft cloth soaked with

alcohol. Following the maintenance procedures below will ensure longer service life

with higher printing quality.

The problem that frequently happens is that the label is jammed or stuck in the print

head or the feeder mechanism. The easiest way to avoid it is to make sure the label

is closely adhered to the liner paper.

Note : Before you start the maintenance procedures, make sure the power is off

and remove the interface cable and plug from the printer.

Before starting to take care of the problem inside the printer, follow the steps below

to remove the upper cover.

1. Remove the label roll or tag roll and spindle.

2. Open the Front Cover.

3. Remove the Top cover:

Top cover

Front cover

Fig. 11 Remove top cover

- 16 -
