TSC TDP-245 Service Manual

Direct thermal bar code printer
Hide thumbs Also See for TDP-245:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Programming Manual, User Manual
TDP-245
DIRECT THERMAL BAR CODE PRINTER
SERVICE
MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDP-245 and is the answer not in the manual?

Questions and answers

Related Manuals for TSC TDP-245

Summary of Contents for TSC TDP-245

  • Page 1 TDP-245 DIRECT THERMAL BAR CODE PRINTER SERVICE MANUAL...

  • Page 2: Table Of Contents

    TDP-245 1. OVERVIEW ............................1 1.1 Front View ...................... 1 1.2 Rear View ....................... 1 1.3. Specification ....................2 1.3.1. Printer ......................2 1.3.2. LED ....................... 3 1.3.3. Button Operation .................... 3 1.4. Supply Specification ..................7 1.4.1. Paper ......................7 2.
  • Page 3 TDP-245 3.8. Replacing Head Open Micro Switch ............48 3.9. Replacing Feed Button and Feed Button PCB......... 49 3.10. Set Up Memory Card ................50 3.11. Peel-Off Installation (Option) Assembly ..........51 3.11.1 Loading Label for Peel-off Mode (Option) ...........53 3.12.

  • Page 4: Overview

    TDP-245 1. OVERVIEW 1.1 Front View Clear Window Power LED Feed Button Top Cover Open Lever 1.2 Rear View 1. USB Interface 2. Centronics Interface 3. RS-232 Interface 4. Power Jack 5. Power Switch Rear Paper Guide...

  • Page 5: Specification

    TDP-245 1.3. Specification 1.3.1. Printer Item Description Mechanism Head Density 203 dpi Max. Print Width 108 mm Max. Print Length 1000 mm ( 39” ) Printing Speed 2, 3, 4 and 5 ips selectable 2, 3 ips selectable for peel-off function...

  • Page 6: Led

    TDP-245 Command Sets TSPL2, EPL2, DPL and ZPL Environment Temperature: 5℃ ~ 40℃ Operation Relative Humidity: 25% ~ 85% (Non Condensing) Temperature: -40℃ ~ 60℃ Storage Relative Humidity: 10% ~ 90% (Non Condensing) Others Dealer Option Peel-off panel assembly, memory card (2, 4, 6 and 8M bytes).
  • Page 7 TDP-245  Pause Press the feed button during printing.  The printing job is suspended. Gap/Black Mark 1.Turn off the power switch. Sensor Calibration 2. Hold on the button then turn on the power switch. 3 Release the button when LED becomes red and blinking.
  • Page 8 TDP-245 Printer 1. Turn off the power switch. Initialization 2. Hold on the button then turn on the power switch. 3. Release the button when LED turns green after 5 amber blinks. (Any green will do during the 5 blinks).
  • Page 9 TDP-245 Skip AUTO.BAS 1. Turn off printer power. 2. Press the FEED button and then turn on power. 3. Release the FEED button when LED becomes solid green.  The LED color will be changed as following: Amber  red (5 blinks)  amber (5 blinks)  green (5 blinks) ...

  • Page 10: Supply Specification

    TDP-245 1.4. Supply Specification 1.4.1. Paper Item Specification Type Label (Continuous , Die-cut , Fan-fold) Wound Type Outside wound Width 20mm ~ 112mm (0.79” ~ 4.4”) Length 10mm ~ 1000mm (0.4” ~ 39”) (Peel-off and cutter mode) 25.4mm ~ 1000mm (1” ~ 39”) Thickness 0.06mm ~ 0.19mm (max.

  • Page 11: Electronics

    TDP-245 2. ELECTRONICS 2.1. Circuit Description Fig. 2.1 Circuit Diagram The main board of printer includes 9 system blocks: MCU. Memory System. Decoder System. Print Head System. Motor System. Power System. Communication Interface System. Sensor System. Cutter System.
  • Page 12 TDP-245 The following figure shows the PCB system Memory System Motor System Sensor System Cutter System Print Head System Decoder System Communication USB System Power System Interface System...

  • Page 13: Mcu Circuit And Mcu Pin Description

    TDP-245 2.2. MCU Circuit and MCU PIN Description Fig. 2.2 MCU PIN Description Diagram...

  • Page 14: Mcu Pin Description

    TDP-245 2.2.1. MCU PIN Description:...
  • Page 15 TDP-245...
  • Page 16 TDP-245...
  • Page 17 TDP-245...
  • Page 18 TDP-245...

  • Page 19: Reset Circuit

    TDP-245 2.3. Reset Circuit Fig. 2.3 Reset Circuit Diagram 80945 reset IC is used to detect the voltage. When the driving voltage is lower than 4.5VDC, reset will be enabled.

  • Page 20: Memory Circuit

    TDP-245 2.4. Memory Circuit Fig. 2.4 Memory Circuit Diagram This is the memory circuit. The U6 & U7 are 2M Byte FLASH ROM and U8 is 2M Byte DRAM.

  • Page 21: Decoder Circuit

    TDP-245 2.5. Decoder Circuit Fig. 2.5 Decode Circuit Diagram...

  • Page 22: Memory Map

    TDP-245 2.6. Memory Map FFFF FFFF ON-CHIP RAM FFFF F000 RESERVED FFFF 8800 FFFF 87FF REGISTER FFFF 81A0 FFFF 8000 RESERVED 00FF FFFF 0200 0000 DRAM SPACE 0100 0000 00E0 0000 TPH STB 00D8 0003 Motor Phase2 00D8 0002 Motor Phase1...
  • Page 23 TDP-245 00C8 0002 Reserved 00C8 0001 Mem_load signal 0040 0000 00C8 0000 Cutter Control 00C0 0003 Motor Current 00C0 0002 USB Data 0010 0000 ROM2 00C0 0001 Centronic Control 0000 0000 ROM1 00C0 0000 Centronic Data...

  • Page 24: Print Head Circuit

    TDP-245 2.7. Print Head Circuit Fig. 2.7 Print Head Circuit Diagram CLK and LAT connect to thermal head control clock and data latch respectively. TPH_EN signal controls the DC24V voltage of the thermal head. When TPH_EN is high, the thermal head will be separated from 24V (V ).

  • Page 25: Stepping Motor Drive / Protection Circuit

    TDP-245 2.8. Stepping Motor Drive / Protection Circuit Fig. 2.8 Stepping Motor Drive/ Protection Circuit Diagram Connector, JP8, sends the pattern as shown in table1. The status of I0 & I1 determines the stepping motor power level. The power level pattern is shown in table2.
  • Page 26 TDP-245 Table 1 Stepping Motor Pattern Pin on Step Phase JP12 Table 2 Stepping motor power pattern Motor Current Current percentage High Level 100% Medium Level Low Level Zero Current...

  • Page 27: Power Circuit

    TDP-245 2.9. Power Circuit Fig. 2.9 Power Circuit Diagram The U3 SI-8050JD converts 24Vdc to 5Vdc. the limit current protest is 1.6A.

  • Page 28: Parallel Interface Circuit

    TDP-245 2.10. Parallel Interface Circuit Fig. 2.10 Parallel Interface Circuit Diagram The Centronic interface supports one-way transmission, SPP mode or nibble mode. The parallel interface circuit is used with the externally connected personal computer parallel interface through the printer cable. When PC’s strobe signal comes in, the printer responds busy status until it reads the data from parallel interface.
  • Page 29 TDP-245 The pin assignments for nibble mode parallel interface connector is as following: Table 3 Pin Assignments For nibble mode Parallel Interface Connector SPP Mode Nibble Mode In/Out Function A low on this line indicates that there are valid data at...

  • Page 30: Serial Interface Circuit

    TDP-245 2.11. Serial Interface Circuit Fig. 2.11 Serial Interface Circuit Diagram RS-232 is an asynchronous transfer interface, which used with externally connected personal computer and keyboard unit. JP15 connects to PC serial interface through the RS-232 cable. RxD is a data receive pin of MCU. CTS is clear to send of MCU, which sends a signal from the external device.

  • Page 31: Usb Circuit

    TDP-245 2.12. USB Circuit Fig. 2.12 USB Circuit Diagram...

  • Page 32: Usb Pin Function

    TDP-245 2.12.1. USB PIN Function The standard USB 1.1. PIN function is as following:...
  • Page 33 TDP-245...

  • Page 34: Sensor Circuit

    TDP-245 2.13. Sensor Circuit 2.13.1. Gap and Black Mark Sensor Fig. 2.13.1 Gap / Black Mark Sensor Circuit Diagram The gap sensor is a penetrable sensor with 64 levels. Black mark sensor is a reflecting sensor with 64 levels. The gap sensor activates when gap and black mark SW signal is high. The...

  • Page 35: Head Open Micro Switch

    TDP-245 2.13.2. Head Open Micro Switch Fig. 2.13.2 Head Open Micro Switch Circuit Diagram The head open micro switch is a micro-switch. The voltage is low when the print head opens; otherwise, it is high.

  • Page 36: Peel-Off Sensor

    TDP-245 2.13.3. Peel-off Sensor Fig. 2.13.3 Peel-off Sensor Circuit Diagram This is a reflecting sensor. The peel-off sensor signal voltage is high when the paper is detected; otherwise, it is low.

  • Page 37: Cutter Drive / Protection Circuit

    TDP-245 2.14. Cutter Drive / Protection Circuit Fig. 2.14 Cutter Drive / Protection Circuit Diagram RESET signal is high when the printer is turned on. The cutter is activated when CTEN signal is low. CT Phase signal controls the rotated direction. U15B 74HC123 controls the breaking of the DC motor of the cutter.

  • Page 38: Summary Of Pcb Connectors

    TDP-245 2.15 Summary of PCB connectors Connector Description Remark Reserved Internal Ethernet connector Pin 1 with red wire Internal Ethernet connector DC power jack JTAG connector For CPLD program update For firmware update card At the back side of PCB Button &...
  • Page 39 TDP-245 JP27 Hardware ID Top side of Main PCB JP14 Power switch JP25 JP11 JP20 JP16 JP19 JP21 JP27 JP18 JP10 JP17 JP26...
  • Page 40 TDP-245 Bottom side of PCB JP6 Memory U14 Cutter driver chip card connector...

  • Page 41: Replace And Install Important Parts

    TDP-245 3. REPLACE and INSTALL IMPORTANT PARTS Please turn off the power switch and unplug the power adapter before replacing parts. 3.1. Replacing Top Cover 1. Open the printer top cover by pushing forward the top cover open levers. 2. Use a screwdriver to remove 6 screws on the top inner cover.

  • Page 42: Replacing Lower Cover And Main Pcb

    TDP-245 3.2. Replacing Lower Cover and main PCB 1. Upside down the printer. 2. Remove 3 screws on lower cover. Screw Screws 3. Remove 6 screws on lower inner cover. Screws Top Cover Top Inner Cover Lower inner cover Screws...
  • Page 43 TDP-245 Lower Cover 4. Remove all the harness connected to main board. 5. Remove 4 screws on PCB. Main Board Lower Cover Screws Screws 6. Replace the PCB or replace a new lower cover. 7. Reassemble parts in reverse procedures.

  • Page 44: Replacing Platen Assembly

    TDP-245 3.3. Replacing Platen Assembly 1. Squeeze two sides of platen assembly and take it out. Squeeze Here Lower Inner Cover Platen Assem Squeeze Here 2. Replace a platen. 3. Reassemble parts in reverse procedures.

  • Page 45: Replacing The Stepping Motor Assembly And Stepping Motor

    TDP-245 3.4. Replacing the Stepping Motor Assembly and Stepping Motor 1. Please refer to 3.2 for disassembling the lower cover. 2. Upside down the lower inner cover. 3. Remove 7 screws of the stepping motor assembly. Screws Lower Inner Cover...
  • Page 46 TDP-245 Stepping Motor Assembly 6. Remove 2 screws from the stepping motor assembly; disconnect the stepping motor from stepping motor bracket. Stepping Motor bracket Stepping Motor Screws 7. Replace the stepping motor. 8. Reassemble parts in reverse procedures.

  • Page 47: Replacing Label Guide Adjustment Knob Assembly

    TDP-245 3.5. Replacing Label Guide Adjustment Knob Assembly 1. Please refer to 3.2 for disassembling the lower cover. 2. Shift the label guide to the center by rotating the label guide adjustment knob. 3. Use a flat screwdriver to press the nub to remove the label guide adjustment knob.
  • Page 48 TDP-245 4. Remove the plastic laminate. nate Plastic Lami Label Guide Adjustment Assembly 5. Replace the label guide assembly. Make sure the label guides are on the center of the printer. Label Guide Adjustment Assembly Label Guide 5. Reassemble parts in reverse procedures.

  • Page 49: Replacing Gap/Black Mark Sensor Assembly

    TDP-245 3.6. Replacing Gap/Black Mark Sensor Assembly 1. Please refer to 3.2 for disassembling the lower cover. 2. Turn over the lower inner cover. 3. Remove the plastic laminate. (refer to 3.5) 4. Remove 1 screw from the gap / black mark sensor fixing plate,...

  • Page 50: Replacing Print Head Module Assembly

    TDP-245 3.7. Replacing Print Head Module Assembly 1. Press right slot of the print head bracket and use a flat screwdriver to stick left side of the printer head bracket then pick up the print head assembly. Stick Flat Screwdriver Here...

  • Page 51: Replacing Head Open Micro Switch

    TDP-245 3.8. Replacing Head Open Micro Switch Please refer to 3.1 for disassembling the top cover and top inner cover. Remove JP16 harness from the PCB. Remove 2 screws and remove the head open micro switch. Top Inner Cover Screw...

  • Page 52: Replacing Feed Button And Feed Button Pcb

    TDP-245 3.9. Replacing Feed Button and Feed Button PCB Please refer to 3.1 for disassembling the top cover and top inner cover. Remove the feed button from top cover. Top Cover Feed Button Disconnect the JP5 hardness from the PCB Remove 2 screws from the top inner cover and replace the feed button PCB.

  • Page 53: Set Up Memory Card

    TDP-245 3.10. Set Up Memory Card Upside down the printer. Remove 1 screw and open the memory card cover. Memory Card Cover Plug in a memory card, pin to pin, on main board. Memory Card Memory Card Cover Revert the memory card cover.

  • Page 54: Peel-Off Installation (Option) Assembly

    TDP-245 3.11. Peel-Off Installation (Option) Assembly Open the top cover. Remove two screws in lower cover for hinge holder. Insert the screw of hinge holder Insert the here screw of hinge holder here Remove 6 screws on the lower inner cover.
  • Page 55 TDP-245 Use a screwdriver to screw off 1 screw on the bottom. Screw Hold the lower cover and lift up the top cover open levers to separate the lower inner cover and the lower cover. Lower inner cover Lower cover 1.

  • Page 56: Loading Label For Peel-Off Mode (Option)

    TDP-245 Gently push peel-off panel to lock to the lower inner cover. Reassemble parts in reverse procedures. 3.11.1 Loading Label for Peel-off Mode (Option) Open the peel-off panel 1. Feed the label, printing side facing up, through the label guide and pass over the platen.

  • Page 57: Cutter Module Installation (Option)

    TDP-245 Adjustment Knob Roller Peel-off panel Loading label for peel-off mode 4. Push the peeler back to the printer. 5. Close the top cover. Label loaded completely in peel-off mode 3.12. Cutter Module Installation (Option) 2. Pull the top cover open levers to open the top cover.
  • Page 58 TDP-245 Screws Screws Remove 6 screws from lower inner cover 5. Turn the printer upside down. 6. Use a screwdriver to screw off 1 screw on the bottom. Screw Remove 1 screw from bottom 7. Hold the lower cover and lift up the top cover open levers to separate the lower inner cover and the lower cover.
  • Page 59 TDP-245 Slot Socket Cutter module harness arrangement 9. Arrange the lower inner cover back to the lower cover. 10. Orient the cutter into the niches of the printer. Niche Cutter module installation 11. Use a screwdriver to screw down 6 screws on the lower inner case and 1 screw on the back bottom of the printer.

  • Page 60: Loading Label In Cutter Mode

    TDP-245 3.12.1 Loading Label in Cutter Mode 1. Open the printer top cover. 2. Insert a paper roller into a paper roll 3. Place a label roll to label roll mount. 4. Feed the paper, printing side face up, through the label guide and pass over the platen.

  • Page 61: Internal Ethernet Print Server Module Installation (Option)

    TDP-245 3.13 Internal Ethernet Print Server Module Installation (Option) 1. Break through the plastic partial tab at the rear side of lower cover to get the RJ45 interface opening. RJ45 interface opening Remove the screw 2. Remove the screw from the main board. Fasten the copper pillar and plastic pillar.
  • Page 62 TDP-245 Ground wire Screws RJ45 connector daughter board 4. Connect the print server module interface cable (36PIN) and RJ45 interface cable to print server module. Print server module interface cable RJ45 interface cable 5. Remove the 2 screws from the motor bracket and 1 screw from the lower inner cover to install the internal print server.
  • Page 63 TDP-245 6. Install the print server module in printer lower inner cover with the above 3 screws. Screw Screws Internal Print Server Module 7. Plug the RJ45 white connector to the RJ45 daughter board connector. 8. Plug the print server module interface cable to connector J1A and J1B on the PCB, the left side harness (with red wire at the left side) is for J1A, the right side harness location is for J1B.

  • Page 64: Parts List

    TDP-245 4. PARTS LIST 4.1 Cover Spare Item Part No. Description Remark Parts 98-0260007-00LF TOP COVER ASS’Y (Clear window included) 37-1403008-34LF SCREW TP3*8 (For top cover ASS’Y & 6 pcs top inner cover ASS’Y) 30-0260002-30LF LOWER COVER 30-0260002-50LF 30-0250008-20LF MEMORY CARD COVER 37-1403020-31LF SCREW TP3*20 (For lower cover &...

  • Page 65: Cover Drawing

    TDP-245 4.1 Cover Drawing...

  • Page 66: Main Board

    TDP-245 4.2. Main Board Spare Item Part No. Description Remark Parts 98-0260123-20LF MAIN BOARD ASS’Y 98-0260123-24LF MAIN BOARD ASS’Y Factory (Main Board + RTC) Option 98-0500025-00 2MB MEMORY CARD OPTION 98-0500026-10LF 37-1403006-34LF SCREW TP3*6 (For main board & lower 3 pcs cover) 37-1403008-74LF SCREW TP3*8 (For main board &...

  • Page 67: Main Board Drawing

    TDP-245 4.2. Main Board Drawing...

  • Page 68: Top Inner Cover

    TDP-245 4.3. Top Inner Cover Spare Item Part No. Description Remark Parts 30-0260006-30 TOP INNER COVER ASSY includes 98-0260045-00LF 30-0260006-30 Top inner cover*1 30-0260006-40LF 36-0260002-00LF Media loading instruction label 36-0500011-00LF High temp. Warning label 36-0500006-00LF Non-reflective label*1 36-0500014-00LF Adhesive backed mount*2...

  • Page 69: Top Inner Cover Drawing

    TDP-245 4.3. Top Inner Cover Drawing...

  • Page 70: Lower Inner Cover

    TDP-245 4.4 Lower Inner Cover Spare Item Part No. Description Remark Parts 98-0260046-00LF LOWER INNER COVER ASSY includes 30-0260007-60LF Lower inner cover*1 36-0500014-00LF Adhesive backed mount*2 36-0130043-00LF Cable tie*2 32-0260004-10LF PEELER BAR( 26 degree) 32-0500010-10LF GROUND PLATE FOR PEELER BAR...
  • Page 71 TDP-245 bracket & lower inner cover x 6 pcs, Ground plate for peeler bar x 1 pc)

  • Page 72: Lower Inner Cover

    TDP-245 4.4 Lower Inner Cover...

  • Page 73: Stepping Motor Fixing Assembly

    TDP-245 4.5 Stepping Motor Fixing Assembly Spare Item Part No. Description Remark Parts 98-0260012-00LF STEPPING MOTOR ASS’Y 65-0030006-00LF STEPPING MOTOR 32-0260001-00LF STEPPING MOTOR BRACKET / METAL 37-1503006-74LF SCREW M3*6 + WASHER (For stepping motor bracket & stepping motor) 32-0500019-00LF GEAR SHAFT...
  • Page 74 TDP-245...

  • Page 75: Stepping Motor Fixing Assembly

    TDP-245 4.5 Stepping Motor Fixing Assembly...

  • Page 76: Option & Accessories

    TDP-245 4.6 Option & Accessories Spare Item Part No. Description Remark Parts 62-0010017-03LF POWER SUPPLY/CEC Standard 72-0010017-00 72-0010017-10LF POWER CORD/AU 72-0010018-00LF POWER CORD/UK Option 72-0010019-00LF POWER CORD/US 72-0010020-00LF POWER CORD/EU 90D 72-0010021-00LF POWER CORD/EU 180D 72-0010032-00LF POWER CORD/CN 72-0010033-00LF POWER CORD/IT...
  • Page 77 TDP-245 98-1000005-00 EXTERNAL WIRELESS PRINT SERVER /EU 98-1000012-00LF REAL TIME CLOCK ASS'Y Factory 98-0500032-00LF Option 98-0500026-00LF 2MB MEMORY CARD Option 98-0500026-10LF 98-0500028-00LF 4MB MEMORY CARD 98-0500028-10LF 98-0500029-00LF 6MB MEMORY CARD 98-0500029-10LF 98-0500030-00LF 8MB MEMORY CARD 98-0500030-10LF 49-OKPE156-20LF BUZZER Factory option...

  • Page 78: Option & Accessories Drawing

    TDP-245 4.6 Option & Accessories Drawing...

  • Page 79: Power On Utilities

    TDP-245 5. POWER ON UTILITIES There are six power-on utilities to set up and test printer hardware. These utilities are activated by pressing FEED button and by turning on the printer power simultaneously. The utilities are listed as below: Gap/Black Mark sensor calibration...

  • Page 80: Gap/Black Mark Sensor Calibration；Self-Test；Dump Mode

    TDP-245 5.2. Gap/Black Mark Sensor Calibration；Self-test；Dump mode While calibrate the gap/black mark sensor, printer will measure the label length, print the internal configuration (self-test) and then enter the dump mode. Please follow the steps as below. 1.Turn off the power switch.
  • Page 81 TDP-245 Self-test Printer will print the printer configuration after gap/black mark sensor calibration. Self-test printout can be used to check if there is any dot damage on the heater element, printer configurations and available memory space. Print head check pattern...
  • Page 82 TDP-245 Dump mode Printer will enter dump mode after printing printer configuration. In the dump mode, all characters will be printed in 2 columns as following. The left side characters are received from your system and right side data are the corresponding hexadecimal value of the characters.

  • Page 83: Printer Initialization

    (5 blinks)  red/amber (5 blinks)  solid green Printer configuration will be restore to defaults as below after initialization. Parameter Default setting Speed TDP-245, 127 mm/sec (5 ips) Density 4.25” (108.0 mm) Label Width 2.5” (63.4 mm) Label Height...

  • Page 84: Black Mark Sensor Calibration

    TDP-245 5.4 Black Mark Sensor Calibration Set black mark sensor as media sensor and calibrate the black mark sensor. Please follow the steps as below. 1. Turn off the power switch. 2. Hold on the button then turn on the power switch.
  • Page 85 TDP-245 4. Printer will be interrupted to run the AUTO.BAS program.

  • Page 86: Gap And Black Mark Sensor Selection

    TDP-245 6. GAP AND BLACK MARK SENSOR SELECTION Both gap sensor and black mark sensor are available in TDP-245. Gap sensor is set as default, so there is no extra setting for gap sensor. Gap Sensor Default setting. No extra action necessary.

  • Page 87: Troubleshooting

    TDP-245 7. TROUBLESHOOTING This section lists the common problems that you may encounter when operating the printer. LED does not light on.  Turn the power switch on.  Measure if there is 24V DC from the power supply output plug. Call the service center if 24V DC is not been measured.
  • Page 88 TDP-245 calibrate the gap sensor with proper sensitivity setting by try and error method. Example: C:\>COPY CON LPT1 <Enter> SET GAP 1 <Ctrl> <Z> Main board, gap sensor or black sensor failure.  Measure the current of pin3 of Q8. It is 5V DC when the label is detected and 0V DC for gap.
  • Page 89 TDP-245 C:\> Poor print quality  The dust or glue from label may stuck onto the print head. Wipe the thermal print head by the soft cloth soaked with Ethanol.  Adjust the print density setting. 9. Stepping motor does not feed label ...

  • Page 90: Maintenance

    TDP-245 8. MAINTENANCE This session presents the cleaning tools and methods to maintain your printer. Use one or more of the following supplies that meets your needs:  Cleaning pens  Cleaning swabs  Lint-free cloth. The cleaning process is described as following...

  • Page 91: Update History

    Camille Pao part no. 2007/3/19 1.Add the MAIN BOARD ASS’Y (Main Board + RTC) Camille Pao part no. 2007/4/14 1.Update TSC e-mail address. Camille Pao 2007/5/11 1.Modify 4.5 item 10/11 : TOP COVER OPEN LEVER Camille Pao part no. 2007/8/1 1.Company information update...
  • Page 92 (Z)/US, 98-1000020-00LF External Ethernet print server (Z)/EU, 98-1000011-00LF EXTERNAL WIRELESS PRINT SERVER /US(C) and 98-1000012-00LF EXTERNAL WIRELESS PRINT SERVER /EU(C) 2009/2/27 Revise description for 30-0500019-00LF Camille Pao Camille Pao 2009/10/28 Add spare parts % for power supply Camille Pao 2011/1/25 Modify TSC address...
  • Page 93 9F., No.95, Minquan Rd., Xindian Dist., No.35, Sec. 2, Ligong 1st Rd., Wujie Township, New Taipei City 23141, Taiwan (R.O.C.) Yilan County 26841, Taiwan (R.O.C.) TEL: +886-2-2218-6789 TEL: +886-3-990-6677 FAX: +886-2-2218-5678 FAX: +886-3-990-5577 Web site: www.tscprinters.com E-mail: printer_sales@tscprinters.com TSC Auto ID Technology Co., Ltd. tech_support@tscprinters.com...
