2.3.4 Control Panel
Button
FEED Button
Press the FEED button to feed the label to the beginning of the next label.
Indicators
READY Indicator
When the power is activated and label properly loaded, the READY indicator
will turn on.
ERROR indicator
The ERROR indicator will light on if the label is not properly loaded or when the
printer is out of labels.
Fig. 5 Control panel
- 6 -
ERROR Indicator
READY Indicator
FEED Button
