Technical Specifications - R-Tech I-MIG200 Operation Instructions Manual

The R-Tech I-MIG 200 is a member of our field acclaimed family of welding products.
Premium features include:-
1. Inverter power source – more efficient to operate, provides smoother weld characteristics.
2. Heavy duty 4-Roll geared wire feed unit for long working life and consistent wire feeding.
3. Infinite welding voltage to allow fine tuning of weld characteristics
4. Adjustable arc force – controls splatter – ideal for thin materials
5. Adjustable burnback control
6. Spot welding & stitch welding facilities
7. Digital amp & volts meters
8. Euro type torch fittings for easy torch fitment/replacement
9. 35% Duty cycle at 200 Amps @ 40
Recommended Processes
The R-Tech I-MIG 200 is recommended for the MIG welding processes within its output capacity of
200 Amps DC
Equipment Limitations
The R-Tech I-MIG 200 is protected from overloads beyond the output ratings and duty cycle as per
machine specifications with thermostat protection of the output coils and rectifiers.
Welding Capability – Duty Cycle
The R-Tech I-MIG 200 is rated at 200 Amps at 35% duty cycle on a ten minute basis. If the duty cycle
is exceeded a thermal protector will shut machine off until the machine cools.
Model No.
Input
MIG Operation
Insulation
4
Introduction
º
C

Technical Specifications

R-Tech I-MIG 200
Rated Input Current I-Eff
Rated Output Current
Duty Cycle @ 200 AMPS
Duty Cycle @ 155 AMPS
Output current Range
No Load Voltage
Voltage Adjustment Range
Suitable Wire Diameter - Steel
Suitable Wire Diameter - Alloy
4
240V 1~ AC 50/60Hz
19 AMPS
200 AMPS
º
35% @ 40 C
º
60% @ 40 C
30-200 AMPS
55-75V MAX
14V – 26V +/- 3V
0.6mm, 0.8mm, 1.0mm
0.8mm, 1.0mm, 1.2mm
Class F
